Forssell Technologies MADA-2 User Manual

2 channel analog to digital and digital to analog converter

Advertisement

Quick Links

F(t) Forssell Technologies Inc
MADA-2
2 Channel Analog to Digital and Digital to Analog Converter
User Manual
72311

Advertisement

loading

Summary of Contents for Forssell Technologies MADA-2

  • Page 1 F(t) Forssell Technologies Inc MADA-2 2 Channel Analog to Digital and Digital to Analog Converter User Manual 72311...
  • Page 2: General Description

    The MADA-2 has AES3 and SPDIF digital inputs and outputs, as well as a Word Clock input and output. Analog inputs and outputs are balanced and floating so that they can used with either balanced or unbalanced signals.
  • Page 3: Analog Inputs

    Each time you power up the MADA-2, the “Over” LED will light up. Press the reset switch to turn-off the Over LED.
  • Page 4 MDAC board inside the MADA-2 that will allow you to change the level calibration for the DA section. Digital inputs There are two digital inputs on the MADA-2. One is configured as an AES-3 or AES/EBU input, and the other is an SPDIF input. The AES-3 input is a 110 ohm, transformer isolated, and balanced XLR input.
  • Page 5 DAC Specifications: Noise <= -120 dBFs A-weighted Quantization Noise <= -117 dBFs 400 to 22 KHz unweighted Dynamic Range > = 123 dB THD+N (%) = 0.0009% @ 1Khz 0 dBu output (-18 dBFs input) 600 ohm load THD+N (%) = 0.001% @ 1Khz +18 dBu output (0 dBFS input) 600 ohm load IMD (SMPTE) = 0.001% @ 0 dBu output (-18 dBFs input) 600 ohm load IMD (SMPTE) = 0.003% @ +18 dBu output (0 dBFs input) 600 ohm load DAC Latency...
  • Page 6 DAC Measurements -100 -105 -110 -115 -120 -125 -130 -135 -140 D-A FFT HiRes Stereo.at2c DA FFT (linear scale) of 2 KHz signal at 0 dBu output level with a 600 load. Red = Ch1 Blue= Ch2 -100 -105 -110 -115 -120 -125...
  • Page 7 -100 -105 -110 -115 -120 -125 -130 -135 -140 D-A FFT HiRes Stereo.at2c DA FFT (linear scale) 2 KHz signal at -100 dBu output level. Red = Ch1 Blue= Ch2 -100 -105 -110 -115 -120 -125 -130 -135 -140 D-A FFT HiRes Stereo.at2c DA FFT (log scale) of 2 KHz signal at -100 dBu output level with a 600 load.
  • Page 8 -100 -105 -110 -115 -120 -125 -130 -135 -140 D-A FFT HiRes Stereo dual freq.at2c DA FFT (linear scale) of Dual Freq (19 and 19.5 KHz) signal at 0 dBu Output Level. -100 -105 -110 -115 -120 -125 -130 -135 -140 D-A FFT HiRes Stereo dual freq.at2c DA FFT (log scale) of Dual Freq (19 and 19.5 KHz) signal at 0 dBu Output Level.
  • Page 9 +0.8 +0.6 +0.4 +0.2 -0.2 -0.4 -0.6 -0.8 -1.2 -1.4 -1.6 -1.8 -2.2 -2.4 -2.6 -2.8 D-A FREQ RESP.at2c DA Frequency Response at 96 KHz sample Rate -100 -110 -120 -130 -140 -150 -160 D_A Jitter Spectrum 0.at27 DA Jitter FFT (44.1k Fs) with 1 KHz 0 dBFs sine wave signal and 500 Hz sine wave jitter at 1 UI (177 ns) amplitude...
  • Page 10 +2.8 +2.6 +2.4 +2.2 +1.8 +1.6 +1.4 +1.2 +0.8 +0.6 +0.4 +0.2 -0.2 -0.4 -0.6 -0.8 -1.2 -1.4 -1.6 -1.8 -2.2 -2.4 -100 -2.6 -105 -2.8 -110 -130 -120 -110 -100 dBFS D-A LINEARITY.at2c Deviation from Linearity (Right scale) with 0 dBFs to –130 dBFs (Input). ADC Measurements -100 -105...
  • Page 11 -100 -105 -110 -115 -120 -125 -130 -135 -140 -145 -150 -155 -160 A-D FFT.at2c AD FFT (log scale) with 0 dBu 5 KHz input (-18 dBFs digital output). -100 -105 -110 -115 -120 -125 -130 -135 -140 -145 -150 -155 -160 2.5k...
  • Page 12 -100 -105 -110 -115 -120 -125 -130 -135 -140 -145 -150 -155 -160 A-D FFT Dual Freq.at2c AD FFT (log scale) with dual frequency (19 and 19.5 KHz) 0 dBu signal +0.8 +0.6 +0.4 +0.2 -0.2 -0.4 -0.6 -0.8 -1.2 -1.4 -1.6 -1.8...
  • Page 13 +2.8 +2.6 +2.4 +2.2 +1.8 +1.6 +1.4 +1.2 +0.8 +0.6 +0.4 +0.2 -0.2 -0.4 -0.6 -0.8 -1.2 -1.4 -1.6 -1.8 -2.2 -2.4 -2.6 -2.8 AD Low Frequency Freq Resp +2.8 +2.6 +2.4 +2.2 +1.8 +1.6 +1.4 +1.2 +0.8 +0.6 +0.4 +0.2 -0.2 -0.4...
  • Page 14 -0.8 -1.2 -1.4 -1.6 -1.8 -2.2 -2.4 -2.6 -2.8 100k Freq Resp Lo.at2c MADA-2 Freq Resp at 44.1k, 48k, 88.2k, 96k, 176.2k, 196k Sample Rates -100 -105 -110 -115 -120 -125 -130 -135 -140 Mic Pre FFT.at2c Analog to Analog FFT (linear scale) 96k Sample Rate 0 dBu Input/Output...
  • Page 15 -100 -105 -110 -115 -120 -125 -130 -135 -140 Mic Pre FFT.at2c Analog to Analog FFT (log scale) 96k Sample Rate 0 dBu Input/Output (-18 dBFs) -100 -105 -110 -115 -120 -125 -130 -135 -140 Mic Pre FFT.at2c Analog to Analog FFT (linear scale) 96k Sample Rate +18 dBu Input/Output ( 0 dBFs)
  • Page 16 -100 -105 -110 -115 -120 -125 -130 -135 -140 Mic Pre FFT.at2c Analog to Analog FFT (linear scale) 96k Sample Rate -100 dBu Input/Output (-118 dBFs) -100 -105 -110 -115 -120 -125 -130 -135 -140 A-A FFT Dual Tone.at2c A-A FFT (linear scale) with dual frequency (19 and 19.5 KHz) 0 dBu output signal...
  • Page 17 -100 -105 -110 -115 -120 -125 -130 -135 -140 A-A FFT Dual Tone.at2c A-A FFT (linear scale) with dual frequency (19 and 19.5 KHz) 0 dBu output signal +0.8 +0.6 +0.4 +0.2 -0.2 -0.4 -0.6 -0.8 -1.2 -1.4 -1.6 -1.8 -2.2 -2.4 -2.6...
  • Page 18 Freq Resp Lo.at2c A-A Frequency Response showing full response at 96k Fs...
  • Page 19 Word Clock Jitter Measurements Measured at WC output BNC at 96 KHz sample rate Measurement calibration is… 1 millivolt = 100 picoseconds pk-pk jitter. 100 microvolt= 10 picoseconds pk-pk. For peak jitter, divide by 2. For RMS multiply by 0.3535 1.9m 1.8m 1.7m...
