UNIVERSAL INSTRUCTIONS

BRACELESS OVAL POOLS

PLEASE READ THESE INSTRUCTIONS CAREFULLY AND THOROUGHLY BEFORE

STARTING GROUND PREPARATION AND POOL ASSEMBLY.

DOING SO WILL PREVENT PROBLEMS.

Oval Pool: General informaition -----------------------------------

1) Selection of pool site --------------------------------------------

2) Ground preparation ----------------------------------------------

3) Assembling side structual component -----------------------

4) Drawing pool shape ----------------------------------------------

5) Connecting tension straps --------------------------------------

6) Positioning assembled oval parts -----------------------------

7) Assembling bottom rail ------------------------------------------

8) Installing wall -------------------------------------------------------

9) Build an earth mound(Cove) -----------------------------------

10) Through the wall skimmer --------------------------------------

11) Liner installation ---------------------------------------------------

Please refer to "Assemble TopSeat , Vertical and Cover" of an attached sheet.

12) Filling the pool -----------------------------------------------------

13) Helpful information -----------------------------------------------

14) SAFETY RULES --------------------------------------------------

BRACELESS OVAL Parts List -------------------------------------

Meijer.com

Page.

Table of Contents

Need help?

Do you have a question about the BRACELESS OVAL POOLS and is the answer not in the manual?

Questions and answers

Summary of Contents for Mighty sun BRACELESS OVAL POOLS

Page 1: Table Of Contents
Meijer.com UNIVERSAL INSTRUCTIONS BRACELESS OVAL POOLS PLEASE READ THESE INSTRUCTIONS CAREFULLY AND THOROUGHLY BEFORE STARTING GROUND PREPARATION AND POOL ASSEMBLY. DOING SO WILL PREVENT PROBLEMS. Page. Oval Pool: General informaition ----------------------------------- 1) Selection of pool site -------------------------------------------- 2) Ground preparation ----------------------------------------------...
Page 2: Oval Pool: General Informaition
Meijer.com GENERAL INFORMATION 1) SELECTION OF POOL SITE Before attempting to set up the pool, read the entire Before starting the installation, the following points are instructions. There are certain areas in the instructions that are important; extremely important to follow exactly as written and/or pictured. a) The site must be large enough to accommodate the pool with Any deviation from these instructions voids warranty of the pool plenty of area around it for pool accessaries, chairs, tables etc.
Page 3: Ground Preparation
Meijer.com 2) GROUND PREPARATION The preparation of the ground is the most important step in the installation of the pool. a) Mark off your pool area by driving stakes. Have a helper hold a tape measure or a string and mark off the pool perimeter using flour 41x21 or chalk.
Page 4: Assembling Side Structual Component
Meijer.com 3) ASSEMBLING BRACELESS OVAL STRUCTUAL COMPONENT. P.No.5712 Side Vertical for 52in P.No.5713 Side Vertical for 54in P.No.5617 Side Vertical Skin for 52,54in Use #0109PACK Braceless Oval frame bolt package. Use #0105(#0106)PACK Strap bolt package. NOTE; Side vertical skin was attached to side vertical at the factory,open end is inside pool.
Page 5 Meijer.com P.No.5674 M10x100 Hex Head Bolt P.No.5675 M10 Nut P.No.3177 Resin Side Upper Joint P.No.5673 M14x30 Hex Head Bolt P.No.5672 M14 Nut P.No.0341 #12 Sheet Metal Screw STEP4. Refer page-7 "5)Connecting tension staraps." to determine kind of straps. Attach End strap to Horizontal support. Put M8x20 hex head bolt from top and put M8 Nut from bottom.
Page 6: Drawing Pool Shape
Meijer.com (4847mm) 4) DRAWING POOL SHAPE 10-7/8" Please Draw a line with seeing the picture of each pool size. Side Vertical (618mm) (618mm) 3/8" 3/8" Wall 16x12 (1236mm) 5/8" X Point (6083mm) (7319mm) 11-4/8" 1/8" (618mm) (618mm) (1236mm) (618mm) (1236mm) (1236mm) (618mm) 3/8"...
Page 7: Connecting Tension Straps
Meijer.com (12520mm) 1" (765mm) (1530mm) (1530mm) (1530mm) (765mm) 6-1/8" 1/4" 1/4" 1/4" 6-1/8" (6120mm) 1" 41x21 This end should be connected End strap to horizontal support. 5) CONNECTING TENSION STRAPS Use #0106.PACK Strap Bolt Package Use #0105.PACK Strap Bolt Package 20mm Middle strap P.No.0923...
Page 8: Positioning Assembled Oval Parts
Meijer.com IMPORTANT ! Digging holes for assembled braceless oval structural components. Use Building block to hold assembled braceless oval structural component. Stamp ground under building block well to bellow than needed level. Put some sand to the ground and pour some water to make sand tight. Then put building block on top of sand.
Page 9: Assembling Bottom Rail
Meijer.com Put Pressure plate by Using #12 Sheet P.No.0341 Metal Screw after Positioning Assembled #12 Sheet Metal Screw oval parts. P.No.6254 Pressure Plate 7) ASSEMBLING BOTTOM RAIL STEP Before proceeding, remove the steel wall from carton and stand on a 3'x3' board inside pool area as shown at down. Put the liner, (leaving it in the carton) inside pool area.
Page 10: Build An Earth Mound(Cove)
Meijer.com 11) LINER INSTALLATION INSIDE OF POOL 1/4in Reinforcing Washer CAUTION: 1/4in Reinforcing Washer Remove your shoes. The liner should never be forcefully pulled or dragged, especially when it holds water, even only 1/2". When you enter the pool during installation, use a ladder other INSIDE OF POOL than a pool ladder.
Page 11: Helpful Information
Meijer.com 13) HELPFUL INFORMATION 14) SAFETY RULES Proper filtering and chemical treatments should not make it necessary Read your instructions and safety rules carefully. If you do not follow to change the pool water. the safety rules someone could be injured or damage could occur. Your pool dealer will advise you of the proper procedure.
Page 12: Braceless Oval Parts List
Meijer.com...
