Summary of Contents for Global 900E
- Page 1 900E Vehicle GPS Tracker User Manual 2009-10-01 www.globaltrackergps.com...
-
Page 2: Table Of Contents
Table of Contents . 1. Working Directions..........3 2. GPS Tracker Installation........3 2.1. Product Parts List ........3 2.2. Precaution before Installation …....5 2.3. Installation............5 2.4. Wiring Description.........6 3. Operating Instructions ........7 4. SMS Tracking by Mobile........8 4.1. Position Report Function........9 4.2. Tracking Function..........9 4.3. -
Page 3: Working Directions
1. Working Directions Thank you for your purchase of 900E Vehicle GPS Tracker. In order to realize the full functions of this product, please read this manual carefully before starting to use the product. This product only maintained repaired qualified... - Page 4 GPS Tracker Unit GPS Antenna GSM Antenna Car Charger Lighter Socket www.globaltrackergps.com...
-
Page 5: Precaution Before Installation
2.2. Precaution before Installation Check if all the parts are included. Prepare a SIM card for GSM communication. Use some other mobile phone to confirm that the PIN code has not been set and that it can dial out and receive telephone calls and SMS without problem. Before install the SIM card;... -
Page 6: Wiring Description
GPS antenna, so that the antenna can receive the GPS signals. 2.3.4 Step 4: Connect power charging. 900E connects to the 4pin and 6pin wires. 2.4. Wiring Description. 4 pins connector Pin Color function... -
Page 7: Operating Instructions
3. Operating Instructions. SMS protocol of 900E, the default password of 900E is 000000 SMS Instruction Format Remark Request one position A******,000 000: command code ******: password, default 000000 Modify user password A******,001,###### 001: command code ******: old password , default 000000... -
Page 8: Sms Tracking By Mobile
No matter where you are, when you want to know the position of your vehicle. Step1 Send a SMS message or make a telephone call to the 900E. Step2 vehicle will report its location back to you by SMS, which... -
Page 9: Position Report Function
Position Data every 3 minute. Step2. 900E will send back one SMS-----Set Time OK. This SMS means that 900E is in tracking mode now and preset time interval is 3 minutes. Step3. 900E will send back position SMS at preset time interval. -
Page 10: Gprs Tracking By Computer
Platform server IP 8886: Platform server software Port When the 900E connect to the monitor system, the power LED flash by 1 S. Then you can login in the tracking server to manage your car. 6. Take Photo function (only for 900E): Connect the Camera to 900E,You can send a command to take photographs;... -
Page 11: Lcd Screen
7. LCD Screen (only for 900E) 7.1. Use as navigation. 7.2. Make and receive phone calls. 7.3. Receive massages from control center. 7.4. Receive GPS signal. 7.5. Fuel Sensor. Open http://www.globaltrackergps.com/ to begin tracking. www.globaltrackergps.com...
