V6000 Advanced FM Audio Transmitter
Transmit any audio format to all FM radios within range.
•
Create your own personal commercial-free radio station within you home, office or
•
car.
Works with PC/MAC computer: Transmit any audio format from your desktop or
•
notebook computer. No drivers needed.
Listen to audio from your computer speakers and transmit audio at the same time
•
using included port splitter cable adapter.
Works with virtually any device: iPod, MP3 player, CD player, PDA, DVD player,
•
Notebook/Desktop PC/MAC, satellite receiver, TV, etc.
Broadcast any audio format: MP3, MP4, WMA, WAV, AAC, internet streaming audio,
•
internet radio, CD audio, DVD audio, etc.
PLL Synthesized: Digitally tuned for extra stable transmission, no frequency drifting No
•
retuning necessary.
LCD display: Indicates - transmit frequency, power setting, display memory status.
•
User adjustable frequency range: User adjustable - 200 frequency range from 88 to
•
108MHz.
Versatile 4-way power feature: PC/MAC USB, (2) AAA batteries*, 12/24V car power,
•
100-240V A/C power. All cables and power accessories are included.
User adjustable transmit range/power up to 450 feet: Two-button user adjustable
•
from 0 to 200mW. Transmit range is up to 450 feet (up to150 meters).
Interchangeable External antenna. Use supplied telescoping antenna or attach your
•
other type(s) of antennas for optimal performance.
Microphone input option: Plug in standard 3.5mm stereo plug microphone to transmit
•
voice or voice over audio. (USE STEREO MICROPHONE ONLY)
Memory function: Allowing user to save frequency and power setting. Four memory
•
buttons are included allowing four different display settings to be saved.
Removable unit stand: Unit can be easily converted from desktop to portable uses.
•
USER'S GUIDE
Advertisement
Table of Contents
Summary of Contents for Mobile Black Box V6000
- Page 1 V6000 Advanced FM Audio Transmitter USER’S GUIDE Transmit any audio format to all FM radios within range. • Create your own personal commercial-free radio station within you home, office or • car. Works with PC/MAC computer: Transmit any audio format from your desktop or •...
- Page 2 • Spurious rejection: <23dB • Audio processing limiter, Pre-emphasis: (50uS) • Output antenna connector: SMA • Mobile Black Box V6000 FM transmitter • (5ft.) USB power cable • (5 ft.) 3.5mm audio cable • (8 in.) 3.5mm audio splitter cable •...
- Page 6 4. Optional – transmitting from a microphone: You may transmit audio from a microphone by connecting a stereo plug-type microphone to the microphone input jack (DO NOT USE A MONO PLUG-TYPE MICROPHONE, DOING SO WILL CAUSE PERMANENT DAMAGE TO YOUR V6000 UNIT) see illustration below….
- Page 7 60% and slowly increase to optimum level, if audio is set too high it will cause distortion in the receiving radio. 9. Setting volume level (PC/Mac). When using the V6000 FM transmitter with a PC or Mac computer the volume level will need to be optimized at all three different sources: (1) computer sound card, (2) Media player software and (3) FM receiver radio.
- Page 8 11. Saving preferred frequency and power setting into memory. The V6000 allows the user to save up to four separate frequency/power settings, one (frequency/power setting) per each memory bank number To store settings into memory: Step 1.Choose a memory bank number you wish to save settings to...
