Combination reverse osmosis / deionization filter instructions

Advertisement

Quick Links

K ENT
MARIN
E
MAXXIMA & MAXXIMA Hi-S
Combination Reverse Osmosis / Deionization Filter Instructions

MAX24, MAX50 Parts List:

MAX35HIS, MAX60HiS Parts List:

Membrane
Housing
O-Ring
Membrane
Housing
Diagram 1
Diagram 3
The Membrane Housing
Waste Water (Orange tubing)
Membrane Housing
Split
Compression
Ring
Product Water (Yellow Tubing)
Flow Restrictor Diagram
This is shown for reference only.
All units have their flow restrictors PRE-
INSTALLED at Kent Marine This
component has no adjustment and
JacoNut
Compression
should not be removed or tampered with
Orange Tubing
Collar
Permission is hereby given for the use of this artwork and verbiage by Kent Marine distributors and their customers for the advertisement of the products of Kent
Marine. "Copyright Kent Marine" and date must be shown with each use . Any modification so as to allow advertising another brand is expressly forbidden and will
be legally pursued.
Kent Marine
TM
Part#
CF1M
1 Micron
Sediment
Filter
1
Part#
CF1M
1 Micron
Sediment
Filter
1

Membrane Insertion:

Disconnect the yellow tube that runs from the prefilter to the
membrane housing's cap. Unscrew this cap, and, if needed,
re-seat the housing's o-ring(see diagram 2). Remove
membrane from protective plastic bag. DO NOT REMOVE
PROTECTIVE TAPE FROM AROUND MEMBRANE! The
membrane has a plastic pipe located in the center of the
membrane material. At one end of the pipe, there are two
small black o-rings. Hold the housing vertically and insert the
membrane with the two small, black o-rings first(see diagram
2). It will stop at the large black gasket seal located on the
outer edge of the membrane material. Take the palm of your
hand and push the membrane into the housing. This is
sometimes a tight fit so push with adequate force. You will
feel it "seat" into the housing.
Front View
Prefiltered
Water In
Housing Cap
®
MAX24, MAX50
MAXHIS35, MAXHiS60
Copyright 1999, Kent Marine , Inc.
Copyright 1999, Kent Marine , Inc.
Part#
CFCE
Mixed-Bed
Matrix
Carbon
Filter
Cartridge
1
Part#
SILICAMAX
CFCE
Matrix
Silicate
Carbon
Removal
Filter
Cartridge
1
Diagram 2
Rear View
Model #
Tap Water In
®
®
Part#
Part#
GHF
CFI
Garden
Hose
Part #: MTFC50, MTFC24
Fitting
Deion
Membrane
Resin
1
1
Canister Wrench
Part#
Part#
GHF
Garden
Part #: MHIS35, MHiS60
High
Hose
Membrane
Fitting
Deion
Resin
1
1
Canister Wrench
Once the membrane is "seated",
you can check to make sure it is all
the way in. From the top of the
3/4" Space
membrane material to the edge of
the housing lip should measure
about 3/4 of an inch(see diagram
3). If it is not this far in, you will
have to either, re-insert the
membrane, or try to push it farther
inside. Once the membrane is
seated properly, screw the housing
cap onto the housing and re-attach
the yellow tube as before.
Stage
Stage
1
2
Stage 3
Membrane Filtration
1
1
1
1
Stage 4
CFI or SILICAMAX(Hi-S )
Product
Water
Waste
Out
Water
Out
REV. 2
