EXTREME CCTV PX100 Specifications

Key Features
•
Fully functional, Pan-Tilt-Zoom speed dome camera designed
specifically to deliver night vision performance under infrared
•
600ft active-infrared night vision (full 30fps video) when
matched with dual SuperLED IR illuminators (850nm | 10º)
•
Weatherproof housing suitable for harsh outdoor applications
•
470 TVL LXR CCD for outstanding spectral response to
infrared illumination
•
Day-night mechanical IR filter technology for vivid daytime
images and exceptional performance under IR
•
Wide-dynamic range capability
•
Compatibility with Pelco P or Pelco D protocols
•
230x total zoom (23x optical zoom, 10x digital zoom)
•
Auto video flip ensures correct image orientation
•
OSD menu for easy operation and control
•
Pan-Tilt speed from 0.5º to 300º per second for smooth,
accurate control
•
220 presets, 4 preset tours, 4 patterns tours & 4 auto-scans
•
8 programmable privacy zone masks
•
7 alarm inputs; 2 programmable auxiliary outputs
•
Built-in clock allows scheduling of camera functions
•
Integrated fan and heater
•
Vandal-proof design
•
Beautiful traffic black finish and black internal liner
Description
The PX100 is a fully functional vandal-resistant speed dome
designed for 24/7 performance when integrated with Extreme CCTV
infrared illumination. Using dual SuperLED IR illuminators (850nm |
10º), the PX100 produces 600ft of night vision video at a full 30fps.
The optical core the PX100 is an LXR-type CCD with day-night
mechanical filter technology, resulting in vivid daytime images and
outstanding night-time performance under Extreme CCTV infrared
illumination. Featuring a total zoom of 230X (23X optical and 10X
digital), the camera produces 470TVL color and 550TVL
monochrome images with low-smear, low-streak and excellent anti-
blooming characteristics.
The PX100 delivers comprehensive speed dome functionality,
offering 220 presets, 4 preset tours, 4 pattern tours and 4 auto-
scans. Pan-Tilt speeds from 0.5º to 300º per second combine with
variable speed zoom to produce smooth and accurate PTZ control.
On-Screen-Display (OSD) provides critical information including
directional orientation and zoom setting. Up to 8 privacy zones are
also available to block surveillance of specific target areas such as
windows, doorways or other private areas. A built-in clock can be
programmed to control camera functions on a set schedule.
The PX100 features a vandal-resistant housing to ensure
performance in physically abusive environments. The all-weather
design is suitable for both indoor or harsh outdoor environments. A
beautiful jet black finish makes the PX100 the most discreet,
aesthetically appealing vandal-proof speed dome available.
When combined with Extreme CCTV infrared illuminators, the
PX100 delivers outstanding speed dome performance with award-
winning night vision for absolute 24/7 surveillance in day or dark.
Patent Pending. Specifications are subject to change without notice
© Extreme CCTV Inc 2006. Extreme CCTV International Inc is a subsidiary of Extreme CCTV Inc
Dealer / Distributor
Vandal-Resistant, All-Weather
Pan-Tilt-Zoom Speed Dome
Product Image
The PX100 (shown above with BRK-01-0001 wall mount
bracket) provides high performance night vision surveillance
when combined with Extreme CCTV infrared illuminators.
PX100 captures a
night image from
100ft away with
SuperLED infrared
illumination.
Applications
•
Airports
•
Retail
•
Transportation
•
Casinos
•
Prisons
•
City centers
•
Commercial buildings
•
Industrial
•
Ports
•
Government buildings
•
Defense
•
Schools and colleges
Corporate Headquarters
