Handheld Reader Writer
V600-CHUD
Equipped with a USB Interface.
Simply connect to a personal
computer to use. No power sup-
ply needed.
• The Read/Write (R/W) Heads and ID Controller are
integrated in a compact, lightweight design.
• Simply connect the Handheld Reader Writer to a
personal computer to use.
• The ability to communicate with V600-series Data
Carriers enables use in existing systems.
• Conformance to R&TTE, FCC approvals.
Ordering Information
■ List of Models
Name
Handheld Reader Writer (USB) 0.8 M
Handheld Reader Writer (USB) 1.9 M

Specifications

■ Handheld Reader Writer
Item
Power supply voltage
Current consumption
Insulation resistance
Dielectric strength
Vibration resistance
Shock resistance
Ambient operating temperature during communication − 10 to + 55 ° C
Ambient operating humidity during communication
Ambient storage temperature
Ambient storage humidity
Degree of protection
Cable length
Weight
Note: This does not include the connector section. The main unit is not resistant to chemicals or oils.
■ Host Communications Interface Specifications
Item
Interface connector
USB version
Communications speed
Device class
Note: Treated as the COM port of the host unit.
Dedicated drivers are available for Windows 2000 and Windows XP personal computers.
The dedicated driver must be installed before connecting the V600-CHUD to a personal computer according to the V600-CHUD User's Manual
(Cat. No. Z219).
Consult your OMRON representative for details on the dedicated drivers.
V600-CHUD 0.8 M
V600-CHUD 1.9 M
Model V600-CHUD 0.8M
5 VDC±5%
250 mA max. (for a power supply voltage of 5.0 V)
50 M Ω min. (at 500 VDC) between connector and case
1,000 VAC, 50/60 Hz for 1min (1mA max.) between connector and case
Destruction: 10 to 150 Hz, 0.2-mm double amplitude, with 10 sweeps of 8 min each in 6 directions
2
Destruction: 150 m/s , 3 times each in 3 directions
35% to 85% (with no condensation)
− 25 to + 65 ° C
35% to 85% (with no condensation)
IEC 60529: IP63 (See note.)
0.8 m
Approx. 120 g (including connector and cable)
Series A plug
Ver 1.1
Full speed (12 Mbps)
COM class (See note.)
V600-CHUD
Model
1.9 m
V600-CHUD 0.8M/V600-CHUD 1.9M
Handheld Reader Writer
V600-CHUD 1.9M
1
