- Page 1 User manual type 34003059 User manual, English OneRemote EXT set top box controller. Only for connection to a Bang & Olufsen or compatible TV. Operate these and other devices with a B&O remote control: Sagem ITD-84 Boxer DVB/T receiver and others.
-
Page 2: Daily Use
O has to be pressed first, to get the coloured operation. Green Yellow Blue Beolink 1000 and other remote controls. Operation is optimal with Beo4 or Beo5 that has coloured function Beolink 1000 Operation: buttons. Other remote controls can be used with limited operation. AsO on newer remote controls. - Page 3 Bang & Olufsen remote control terminal, via a Bang & Olufsen TV. Beo4 or Beo5 remote controls can be used. Beolink 1000 can be used with reduced functional- ity. This guide explains how.
- Page 4 EXT controller. When a scart type connected source is selected with a Bang & Olufsen remote control, the B&O TV starts to parse control data from the remote control to the attached device, via the scart cable. The OneRemote EXT controller captures these data and converts these into IR data, that can operate the specific device.
-
Page 5: Option Programming
B&O remote controls are not equipped with many keys, so we have designed a ‘layout’ that works logically, even when shifting between different devices. To get a common layout for many devices, we therefore needed to redefine a few of the beo4 buttons to other functions: Coloured buttons. -
Page 6: Menu Option
91 is set. This option reverses the use of the sets of arrows. Some people find it more comfortable to use the up/ down arrows for programme zapping, and therefore also benefits from this option, using a Beo4 or Beo5. qqqqqq91 Yellow/ Blue is programme Zap. -
Page 7: Installation
Installation The OneRemote EXT cable must be connected to the devices ’TV’ scart output socket and a scart input socket on the TV. Then the IR-emitter must be stuck in a way that it can emit IR-light in to the the devices IR-receiver, that normally receives the IR- light emitted thom the devices own remote control. - Page 8 www.oneremote.dk Made in Denmark 34003059u3uk...
