Summary of Contents for Huffy Bicycle Child Trailer
- Page 1 Owner’s Manual Bicycle Child Trailer This manual contains important safety, assembly, operation and maintenance information. Please read and fully understand this manual before operation. Save this manual for future reference. m0072 HBTrailer EN 032613 Copyright Huffy Corporation 2012...
-
Page 2: Table Of Contents
• Trailer ....................20 • Hitch Arm Spring ................... 20 • Disassembly and Storage ..............20 • Tires ..................... 21 • Inspection of the Bearings ..............21 • Lubrication .................... 21 • Lubrication Table................... 21 Warranty • Huffy Corporation Limited Warranty ...........22/23... -
Page 3: The Owner's Responsibility
The Owner’s Responsibility WARNING: The trailer is designed and constructed to provide a portable, com- fortable and sturdy addition to your outdoor ventures. Please read these instructions and all warnings carefully before using and keep the instructions for future reference. If the Trailer was purchased unassembled, it is the owner’s responsibility to follow all assembly and adjustment instructions exactly as written in this manual, and any “Special Instructions”... -
Page 4: Warning And Safety Information
Warning and Safety Information Meanings of Warnings: This symbol is important. See the word “CAUTION” or “WARNING” which follows it. The word “CAUTION” is before mechanical instructions. If you do not obey these instructions, mechanical damage or failure of a part of the Trailer can occur. The word “WARNING”... -
Page 5: Trailer Warnings
Trailer Warnings - continued • To avoid serious injury, children should always wear the seat belts and shoulder straps when riding in trailer. • When used with one occupant, the occupant must be seated in the center seating position and wearing the seat belt and shoulder straps. •... -
Page 6: Part Assembly View
Part Assembly View... -
Page 7: Parts Assembly List
Parts Assembly List... -
Page 8: Introduction To Assembly
Introduction to Assembly This Owner’s Manual is made for several different Trailers: • Some illustrations may vary slightly from the actual product. • Follow instructions completely. • If the Trailer has any parts that are not described in this manual, look for sepa- rate “Special Instructions”... -
Page 9: Assembling The Frame And Seat Panel
Assembling the Frame and Seat Panel Remove trailer and all components from carton and sort all contents. Steps: 1. Unfold Side Frames (2) so they are upright. 2. Lift up Crossbar (4) and slide Seat Straps (A) over Crossbar. 3. Push Side Frames apart and insert end of Crossbar into Clamp Bracket (B). 4. -
Page 10: Setting Up The Hitch Arm
Setting up the Hitch Arm Steps: 1. Turn the unit on it’s side. 2. Remove the Safety Pin (6) from rear hole as shown. 3. Rotate Hitch Arm (5) so that it points forward. 4. Insert Safety Pin (6) in FORWARD hole and snap clip ring over end of Safety Pin as shown. -
Page 11: Installing The Wheels
Installing the Wheels Steps: 1. Turn the unit on it’s back. 2. Slide each Wheel Shaft (A) into the Trailer Axle (B). 3. Press the Lock Button (C) until the Wheel locks into position and cannot be pulled out. 4. Repeat for opposite side. Note: To remove the Wheels (10, 11), push in the Lock Button (C) and pull the Wheel out of the Axle. -
Page 12: Attaching The Top Cover
Attaching the Top Cover Steps: 1. Position Cover (17) over the top of the trailer so that the PVC Window and Bug Mesh Screen (B) is to the front of trailer. 2. Fasten the Velcro (shown in black) in all the locations shown below (both sides). 3. -
Page 13: Attaching The Trailer To A Bike
Attaching the Trailer to a Bike Steps: (Hitch Connector (9) may be pre-installed from the factory) 1. Insert the Hitch Connector (9) into the Hitch Arm (5). 2. Insert Safety Pin (7) and snap Clip Ring (A) over end of Safety Pin as shown. 3. -
Page 14: Attaching Safety Strap To Bike
Attaching Safety Strap to Bike Steps: 1. Route Safety Strap (20) around Bike’s Frame (A) as shown. 2. Securely fasten Strap Clamp (B) to Bracket (C) as shown. 3. Ensure wheel functions properly with no interference. WARNING: If the Safety Strap interferes with your bike or other bike attach- ments, or if it does not tighten securely, do not use the Trailer. -
Page 15: Installing Fag
Installing Flag The Flag (19) slides into the Slot (A) in the side of the Left Cover. Steps: 1. Connect both sections of the Flag (19) as shown. 2. Locate the Slot (A) on the rear corner of the Cover and slide Flag shaft all the way in so that it is secure. -
Page 16: Placing Children In The Trailer
Placing Children in the Trailer When you place the children in the seat or remove the children from the seat, always check if the trailer is stably connected with the bike and the bike is properly parked. • Open the front of top cover and place the children in the proper position. •... - Page 17 Placing Children in the Trailer Single Passenger: 1. When carrying a single child, place child in the middle of the trailer seat and connect the two Shoulder Strap Clips (A) to the two Lock Clips (B) as shown. 2. Connect the two Waist Straps (C) on each side of the child to the Harness Lock Clips (D).
-
Page 18: Electronic Foot Pedal
Electronic Foot Pedal (Not included with all models) Remove Pull Tab (A) for battery operation fig 04 View from underneath Foot Pedal Battery Replacement: Batteries: DC 1.5V, AAA. The unit requires 2 batteries (B). 1. Loosen the battery compartment Cover Screw to remove the Cover (C). 2. - Page 19 Electronic Foot Pedal - continued Foot Pedal (A) Placement: • Make sure Sound Unit (B) faces forward. • Make sure Foot Pedal (A) is sitting fl at on the bottom of the foot compartment as shown. fig 05 Operation: • Turn unit ON (E) (fi...
-
Page 20: Trailer
Trailer WARNING: Inspect the Trailer frequently. Failure to inspect the Trailer and to make repairs or adjustments, as necessary, can result in injury to the rider or to others. Make sure all parts are correctly assembled and adjusted as written in this manual and any “Spe- cial Instructions”. -
Page 21: Tires
Tires Maintenance: • Frequently check the tire infl ation pressure because all tires lose air slowly over time. For extended storage, keep the weight of the Trailer off the tires. • Do not use unregulated air hoses to infl ate the inner tubes. An unregulated hose can suddenly over infl... -
Page 22: Huffy Corporation Limited Warranty
• Used in a manner contrary to the instructions and warnings in this Owner’s Manual Huffy will not be liable for incidental or consequential loss or damage, due directly or indirectly from use of this product. Some states do not allow the exclusion or limita- tion of incidental or consequential damages, so the above limitation may not apply to you. -
Page 23: Huffy Corporation Limited Warranty
Huffy Corporation Limited Warranty What will Huffy do? Huffy will replace, without charge to you, the component found to be defective by Huffy. The original owner must pay all labor and transportation charges connected with the repair or warranty work. - Page 24 • Always read the user manual that comes with your helmet to make sure it is fi tted and attached properly to the wearer’s head according to the fi tting instructions described in the user manual. Check www.Huffy.com for the current contact information H Helmet EN 100212 i0027...
