SanDisk V-Mate Quick Manual

The SanDisk V-Mate is a video memory card recorder that captures and
records video content from an analog source directly onto a flash memory
card. Recorded video is then available for playback on a compatible portable
device. Enjoying video content on the move has never been easier!
R E C O R D
The V-Mate allows you to select your desired playback device "profile" or
manually set video format, resolution, and quality levels via a user-friendly
graphical user interface (GUI). The GUI – displayed on your television
screen - makes it very easy to navigate through the menu and select
recording and viewing options. Operation is possible at the touch of a
button via the supplied remote control. Recording may be captured from
any composite video source, such as a:
Cable/Satellite/Terrestrial Set-Top Box
DVD Player
Video Cassette Recorder (VCR)
Personal Video Recorder (PVR)
Camcorder
S C H E D U L E R E C O R D I N G
The V-Mate enables you to schedule recordings based on channel, date, and
start/stop times, including daily and weekly repeats.
P L A Y B A C K
View your recorded video content by simply inserting your flash memory
card into a compatible portable device, such as a:
Mobile phone
Handheld game console
PDA
Video Music Player
Personal Media Player (PMP)
PC/notebook computer
V-Mate (connected to a TV)
E N J O Y
Finally, your video content can go where you go! The V-Mate takes your
mobile experience to new heights by enabling you to take advantage of the
video capabilities of your mobile device. The V-Mate gives you the flexibility
to:
Watch whatever you want whenever and wherever you want!
View favorite TV shows or movies during your daily commute
Catch those late night TV shows you always miss or the latest episode of
your favorite reality show during your lunch break!
Digitize your home videos
Share favorite video content with family and friends
To learn more about V-Mate, please visit www.sandisk.com/vmate
V-Mate
™
VIDEO MEMORY CARD RECORDER
Record your favorite TV shows and movies for
playback on your mobile device!
Works
Like a
VCR
( )
S
SanDisk and the SanDisk logo are trademarks of SanDisk Corporation, registered in the United States and other countries. V-Mate is a trademark of
SanDisk Corporation. SD, SDHC, miniSD, miniSDHC and microSDHC are trademarks. Memory Stick PRO, Memory Stick Duo and Memory Stick
PRO Duo are trademarks of Sony Corporation. MMC, MMCplus and MMCmobile are trademarks of the MultiMediaCard Association. Other brand
names mentioned herein are for identification purposes only and may be the trademarks of their respective holder(s).

Package Includes:

V-Mate
Remote control & battery
Audio/Video cables (2x)
Infrared emitter cable
:
USB cable
Power Supply
User Guide
*

KEY FEATURES

Set-up and execution is a breeze!
₋
No conversion of video formats necessary – just
SIMPLE
"Plug & Play"
₋
No PC required
₋
Supports popular media card formats (see
COMPATIBLE
specifications below)
GUI and full-featured remote control allow you to
FLEXIBLE
choose video format, resolution, and quality
settings for your compatible portable device

SPECIFICATIONS

₋
5.1"(L) x 2.6" (W) x 0.8" (H)
DIMENSIONS
₋
130mm (L) x 66mm (W) x 20mm(H)
₋
Codecs: MPEG-4 Simple Profile, H.263
₋
Formats: MP4, 3GP, 3G2
₋
Resolution: Up to 640x480 pixels
VIDEO FORMATS ₋
Frame Rate: Up to 30fps
₋
TV Formats: NTSC &
₋
Record up to 3.5 hours
video per gigabyte
₋
3.5mm input for composite video, audio left
& right
₋
3.5mm output for composite video, audio
left & right

CONNECTORS

₋
USB mini B
₋
IR emitter (connection to set-top box or
VCR)
₋
Power
₋
SD, SDHC, miniSD, miniSDHC, microSD,
microSDHC
SUPPORTED
₋
(RS-)MMC (DV), MMCplus , MMCmobile
CARD FORMATS
₋
Memory Stick/PRO/Duo/PRO Duo
₋
Power

INDICATORS

₋
Recording status
(LED)
₋
Card activity (at each card slot)
₋
TV with RCA composite video (NTSC or
MINIMUM
PAL) and audio connection
SYSTEM
₋
Video source with RCA composite video
REQUIREMENTS
and audio composite connection
* For home and personal use: This product is intended to be used for recording and playback for your home and
personal enjoyment. Copying and commercial use of copyrighte
may be prohibited by law. Use of your V-Mate in compliance with all copyright and applicable intellectual property
laws remains the responsibility of the user of the product.
** Recording times will vary by target device and video quality level. Recording time is approximately 3.6 hours in a
mobile phone (@ bit rate of 544kbps) and 1.8 hours on a notebook computer (@bit rate of 1.056kbps).
*** 1 megabyte (MB) equals 1 million bytes; 1 gigabyte (GB) equals 1 billion bytes.
SanDisk's product and executive images can be downloaded from http://www.sandisk.com/corporate/media.asp
SanDisk's web site/home page address: http://www.sandisk.com
PAL
** of high quality
***
d material without permission of the copyright owner
