ZigBee Wireless Survey Toolkit
for TB7200/TB7300/TB7600 Series
Thermostats
PRODUCT OVERVIEW
The Honeywell TBST-5014W wireless survey tools are
intended to verify and validate the deployment and use of
the Honeywell TB7200, TB7300 and TB7600 Series
wireless thermostats on a potential job site.
This document provides wireless guidelines and
instructions on how to use the wireless survey tools to
perform a site survey.
NOTE: Wireless installations require careful con-
sideration of the environment where the
wireless devices will be installed. We highly
recommend a site survey be performed prior
to bidding on or accepting a job.
The TB7200, TB7300, and TB7600 Series wireless
communicating thermostats are ideal for retrofit
applications where the addition of communicating field
bus wiring within the building space is prohibitive. These
wireless thermostats allow for the use of equipment
wiring used by existing electronic thermostats.
The Honeywell wireless thermostats, along with the
TB-VWG-APP-1014 wireless communication card and
the network driver and device .jar files, are specifically
designed to be used by Honeywell WEBs-AX controllers
WEB-2xx, WEB-6xx, and WEB-7xx controllers powered
®
AX
by Niagara
.
More Information
To learn more about the TB7200, TB7300, and TB7600
thermostats visit http://customer.honeywell.com.
• Wireless Installation & Integration Reference Guide
for TB7200, TB7300, TB7600 Series Thermostats
(Form No. 63-4522)
• TB7600 Series RTU/Heat Pump Communicating
Thermostats Specification Data (Form No. 63-2706).
• TB7600 Series RTU Communicating Thermostats
with Humidity Control Specification Data (Form No.
63-2707)
• TB7300 Series Communicating Fan Coil Unit
Thermostats Specification Data (Form No. 63-2709).
• TB7200 Communicating Zoning Thermostats
Specification Data (Form No. 63-2708).
• Sensor Selection Guide (Form No. 63-9285) for a
complete listing of compatible sensors.
Product Overview .....................................................
ZigBee Mesh Network Overview ..............................
Site Survey Overview ...............................................
.............................................................. 10
Trademarks .............................................................. 10
USER'S GUIDE
Contents
1
3
4
5
62-2024-03
Advertisement
Table of Contents
Related Manuals for Honeywell TB7200 series
Summary of Contents for Honeywell TB7200 series
-
Page 1: Table Of Contents
The Honeywell wireless thermostats, along with the TB-VWG-APP-1014 wireless communication card and the network driver and device .jar files, are specifically designed to be used by Honeywell WEBs-AX controllers WEB-2xx, WEB-6xx, and WEB-7xx controllers powered ® by Niagara... -
Page 2: Getting Started
5. Assign the PAN ID with the up/down arrows on the 200 full charge cycles. right, as shown in Fig. 3. Both devices should be • Contact Honeywell for replacement batteries. The assigned the same PAN ID. survey tools use a custom rechargeable battery type. -
Page 3: Zigbee Mesh Network Overview
ZIGBEE WIRELESS SURVEY TOOLKIT FOR TB7200/TB7300/TB7600 SERIES THERMOSTATS Mesh networking is a type of network where each node acts as an independent router. It allows for continuous connections and reconfiguration around broken or blocked paths by “hopping” and “re-meshing” from node to node until the final destination is reached. -
Page 4: Basic Design And Deployment Considerations
WEBs-AX controller with a Honeywell wireless communication card and related wireless thermostats. • Honeywell recommends using a per floor horizontal architecture vs. a vertical one. Transmitting from one floor to the other may be possible in certain... -
Page 5: Site Survey Overview
ZIGBEE WIRELESS SURVEY TOOLKIT FOR TB7200/TB7300/TB7600 SERIES THERMOSTATS • Always locate the controller with wireless card near or • Avoid placing the controller with wireless card and the in the direct line of sight to as many wireless thermostats near metal or enclosing the controller with thermostats as possible. -
Page 6: Performing A Site Survey
100% when in close proximity to each other. If a 0% signal strength dis- plays, see “Getting Started” on page 2. NOTE: To ensure a proper survey, Honeywell recom- mends using ONLY channels 15 or 25 to avoid network interference with 802.11 Wi-Fi devices in the 2.4GHz spectrum range. - Page 7 ZIGBEE WIRELESS SURVEY TOOLKIT FOR TB7200/TB7300/TB7600 SERIES THERMOSTATS At the Job Site the floor where a cluster of thermostats are to be installed. Locate the boundary where the signal 1. Begin by positioning one of the wireless survey strength is about 20%. tools in the proposed location for the WEBs-AX con- 3.
- Page 8 ZIGBEE WIRELESS SURVEY TOOLKIT FOR TB7200/TB7300/TB7600 SERIES THERMOSTATS WIRELESS THERMOSTAT PROPOSED WEBs-AX CONTROLLER WITH WIRELESS COMMUNICATION CARD MCR32619 Fig. 11. Proposed floor plan with three hop radiuses. 7. Repeat steps 2-5 until you establish the maximum each thermostat location has been confirmed to range covered by 5 hops where the last position have a signal strength of 10% or greater.
- Page 9 • Use TB-RP5000W repeaters if remote devices are too • Contact your Honeywell sales representative for far to bridge or the signal is too weak. recommendations if you have a floor plan layout •...
-
Page 10: Disclaimer
Honeywell documents should be considered as a guide to TRADEMARKS apply Honeywell Wireless Network devices only. The instructions included in this manual are based upon Honeywell in house testing and should be referred to as a Niagara, Niagara AX is a registered trademark of Tridium, guide only. Inc. - Page 11 ZIGBEE WIRELESS SURVEY TOOLKIT FOR TB7200/TB7300/TB7600 SERIES THERMOSTATS 62-2024—03...
- Page 12 ZIGBEE WIRELESS SURVEY TOOLKIT FOR TB7200/TB7300/TB7600 SERIES THERMOSTATS Automation and Control Solutions Honeywell International Inc. 1985 Douglas Drive North ® U.S. Registered Trademark Golden Valley, MN 55422 © 2011 Honeywell International Inc. 62-2024—03 M.S. Rev. 09-11 customer.honeywell.com Printed in United States...
