- Page 1 ECLIPSE H»Radio@ HDR109 HD Radio Tuner Unit Syntonisateur radio HD Afinador de Radio de HD Unidad ." » IN\tl ~N\tl \tNNHN\t <J » ." ::;; "" /ECLIPSE H» HDR109 Radio' HO Radio Tuner Unit Owners Manual Manuel de I'utilisateur Manual del Propieta...
- Page 2 ...J...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Warnings and Cautions Package Contents Installation System Wiring and Connections Compatible Units Operation Specifications iPod and iTunes are trademarks of Apple Inc., registered in the U.S. and other countries. HD Radio Technology Manufactured Under License from iBiquity Digital Corp. U.S. ™... -
Page 4: Warnings And Cautions
.WARNING This symbol means important instructions. Failure to heed them can result in serious injury or death. DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR ATTENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE. Any function that requires your prolonged attention should only be performed after com- ing to a complete stop. -
Page 5: Package Contents
Package Contents -"-,, -'''-1 """' U N' o ' LECL/PSE HDR109 t-WRadio HDR109 3.5-Meter E-Lan Cable X 1 Power Harness X 1 Antenna Extension Cable X 1 Mounting Screws X 4 Installation Locate the desired mounting position. Mark the position of the mounting screws. -
Page 6: System Wiring And Connections
System Wiring and Connections Sample Connection: ECLIPSE CD Tuner CH3083 (CD Changer) and HDR109 Optional iPod interface cable (iPC1 09) ...J " " <.9 ·us. ~§N ..ECLIPSE HD Radio-Ready Main Unit (CD5030) E-LAN cable Optional ECLIPSE CD Changer (CH3083) -
Page 7: Compatible Units
Press the [MODE] button for at least one second while a song you like is being played. The tag information of the song is stored in the main unit. DjfL VEn~1 """ CO~OJO "I I... C>- .r..' MUIf ---=-- _ MP3 WMA 114sc<\Nlls mlhmpl SOU"" Refer to http://www.eclipse-web.com/us-index.htmlfor compatible iPod models and iTunes. -
Page 8: Specifications
Specifications <GENERAL> Power Supply VDC (10.5V to 16.0V) Max. Current 0.35A Dimensions (W x H x D) 141mm x 78 mm x 28 mm (5.5 in x 3 in x 1.1 in) Mass (weight) Approx. 360 g (0.792 Ibs) ..J <.9 <Analog FM TUNER>... - Page 9 Le numero de serie est soit colle, soit estampe sur Ie chassis. Nota al consumidor Por favor conserve este folleto y apunte aqui el numero de serie de su HDR109 para identificacion. EI numero de serie se encuentra etiquetado estampado en el chasis del aparato.
- Page 11 Thank for purchasing ECLIPSE products. It is necessary to update your AVN726E or AVN76D with the Update Disc included with the HDR1 09. Please ask the Authorized ECLIPSE Dealer where you purchased the HDR1 09 for assistance. AVN726E1AVN76D Main Software Upgrade Instruction...
- Page 12 Wait until the software update is DO NOT TURN OFF ACC WHILE UPDATINGI completed. OR THE UNIT MAY BECOME UNRECOVERABLE AND/OR MAY NOT RETURN TO ITS NORMAL OPERATING STATE. 12 Push [OK] on the touch screen. 13 Push [End] on the touch screen. 16 Push the [MENU] button.
- Page 13 ECLIPSE AVN726E/76D Software Update Ver. 03.01.00.64...
- Page 14 Ie cadre de la garantie, y compris les coOts de retablissement de tels programmes informatiques ou de telles donnees. Si pendant la periode du service de la garantie du produit, Ie contenu du disque dur ou tout autre media de stockage de donnees est altere, efface, modifie ou egare, Eclipse n'est pas responsable.
- Page 15 This limited warranty provided by Fujitsu Ten Corp. of America ("Eclipse") covers all defects in materials or workmanship under normal use in your new Eclipse Product purchased from an authorized Eclipse retailer in the U.S.A. or Canada for a period of one (1) year from the date of original consumer purchase.
