Aztech WL576E Specifications

WL576E
Wall-plugged 300Mbps High-Speed Wireless-N AP
Aztech WL576E is a Wall-plugged 300Mbps Wireless-N
AP, which supports wireless 802.11b/g/n, and one
10/100Base-T Ethernet port.
Make Wired Network WiFi Ready
WL576 is equipped with 1 x 10/100M Auto MDI/MDIx LAN
port that can be used to connect to an existing wired
network to serve as a wireless interface. It can also be used
to configure the WL576E via its web-based GUI, or upgrade
the firmware.
MIMO Technology
The device is designed with MIMO technology, which
successfully reduces 'dead spot', and extends network
coverage within a home or in the building.

Advanced Security

WL576E features with 64/128-bit WEP encryption and WIFI
Protected Access (WPA), WPA2 to ensure the network
security and prevent unauthorized access to you network.
Portable without the Need of External Power Supply
The device is easy to setup. It is portable with no need of
any external power adaptor. It comes with the embedded
power supply and power plug, so that users can just plug
the device into a power socket.
ˆ
Maximum wireless signal rate derived from IEEE Standard 802.11g and draft 802.11n specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and
construction, and network overhead, lower actual data throughput rate.
Head Office Hong Kong Office
AZTECH TECHNOLOGIES PTE LTD. AZTECH SYSTEMS (H.K) LTD.
31 Ubi Road 1, Aztech Building Rooms 2-10, 3rd Floor, Core Building 1
#09-01 Singapore 408694 No. 1 Science Park East Avenue
Tel: (65) 6594 2288 Fax: (65) 6749 1198 HongKong Science Park
Shatin, New Territories, Hong Kong
Tel: (852) 2757 1177 Fax: (852) 2753 0578
Malaysia Office China Office
AZ-TECHNOLOGY SDN BHD. AZTECH COMMUNICATION DEVICE (DG) LTD.
Unit 719 Block A Kelana Business Centre Jiu Jiang Shui Village, Chang Ping Town
No. 97, Jalan SS7/2 Kelana Jaya Dong Guan City,
47301 Petaling Jaya Guang Dong Province, China.
Selangor Darul Ehsan, Malaysia Tel: (86)(769) 8393-6688 Fax: (86) (769) 8393-1138
Tel: (60)(3) 7804-8450 Fax: (60)(3) 7804-8457
Features
Supports ratified 802.11n technology with the data
•
transfer rate up to 300Mbps.
Shares large files, printing and storage quickly and
•
reliably in wider range in your home or office.
Eliminates the use of cable wires while providing reliable
•
wireless connection.
Enables wired network wireless ready through the LAN
•
port
• MIMO technology to reduce "dead spot" and increase
network coverage.
WEP, WPA, and WPA2 to ensure network security from
•
unauthorized access.
User-friendly web-based GUI and easy hardware setup.
•
Portable, no need of external power adaptor.
Support WPS to both Router and Client devices
•
