Do Not Throw Away OWNER'S MANUAL MODEL NUMBER: WARNING: Read the Owner's Manual and PP927ESA fol low all Warnings and Safety In struc tions. Fail ure to do so SNOW THROWER can result in serious injury. 183616 Rev. 6 09.30.02 BY Always Wear Eye Protection During Operation Printed in U.S.A.
For Parts Call K&T 606-678-9623 or 606-561-4983 SAFETY RULES Safe Operation Practices for Snow Throwers IMPORTANT: This machine is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury or death. •...
For Parts Call K&T 606-678-9623 or 606-561-4983 • Do not put hands or feet near or under rotating parts. • Do not overload the machine capacity by attempting Keep clear of the discharge opening and front auger to clear snow at too fast a rate. area at all times.
For Parts Call K&T 606-678-9623 or 606-561-4983 SAFETY RULES ............2-3 MAINTENANCE ............. 14-15 PRODUCT SPECIFICATIONS ........3 MAINTENANCE SCHEDULE ........14 CUSTOMER RESPONSIBILITIES........ 3 SERVICE AND AD JUST MENTS ......16-18 WARRANTY..............32 STORAGE ..............18 ASSEMBLY / PRE-OPERATION ....... 5-7 TROU BLE SHOOT ING ..........
For Parts Call K&T 606-678-9623 or 606-561-4983 ASSEMBLY / PRE-OPERATION Read these instructions and this man u al in its entirety before you attempt to assemble or operate your new snow thrower. Your new snow thrower has been as sem bled at the factory with the ex cep tion of those parts left unassembled for shipping purposes.
Page 6
For Parts Call K&T 606-678-9623 or 606-561-4983 ASSEMBLY / PRE-OPERATION AUGER AUGER TRACTION DRIVE RETAINER CONTROL CONTROL CON TROL LEVER SPRING RETAINER LEVER SPRING TRACTION DRIVE CON TROL DRIVE AUGER CONTROL CONTROL BRACKET BRACKET FIG. 4 FIG. 6 INSTALL AUGER CONTROL ROD (See Figs. 5 and 6) INSTALL DISCHARGE CHUTE / CHUTE ROTATER HEAD (See Fig.
Page 7
For Parts Call K&T 606-678-9623 or 606-561-4983 ASSEMBLY / PRE-OPERATION INSTALL CHUTE DEFLECTOR REMOTE CONTROL INSTALL WEIGHT BAG (See Fig. 10) (See Figs. 8 and 9) Though seldom required, the weight bag will re duce the 1. Install remote cable bracket to discharge chute with ten den cy of the auger housing to ride up on hard, icy drifts.
For Parts Call K&T 606-678-9623 or 606-561-4983 OPERATION KNOW YOUR SNOW THROWER READ THIS OWNER'S MANUAL AND ALL SAFETY RULES BEFORE OPERATING YOUR SNOW THROWER. Compare the illustrations with your snow thrower to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference.
Page 9
For Parts Call K&T 606-678-9623 or 606-561-4983 OPERATION SPARK ENGINE OIL CAP AUGER DISCHARGE CHUTE CONTROL LEVER PLUG WITH DIPSTICK CONTROL SAFETY LEVER DRIVE SPEED DEFLECTOR REMOTE IGNITION CON TROL LEVER CONTROL LEVER GAS O LINE FILLER TRACTION CHUTE CHOKE DRIVE DE FLEC TOR CON-...
Page 10
For Parts Call K&T 606-678-9623 or 606-561-4983 OPERATION The operation of any snow thrower can result TO USE CHOKE CON TROL (See Fig. 14) in foreign objects thrown into the eyes, which The choke con trol is located on the en gine. Use the choke can result in severe eye damage.
Page 11
For Parts Call K&T 606-678-9623 or 606-561-4983 OPERATION DISCHARGE CHUTE CAUTION: Do not move speed con trol le ver CONTROL LEVER when traction drive control lever is en gaged. Damage to the snow thrower can result. • Slower speeds are for heavier snow and faster speeds are for light snow and transporting the snow thrower.
For Parts Call K&T 606-678-9623 or 606-561-4983 OPERATION TO ADJUST SKID PLATES (See Fig. 19) WARNING: Wipe off any spilled oil or NOTE: The wrench provided in your parts bag may be used fuel. Do not store, spill or use gasoline to adjust the skid plates.
Page 13
For Parts Call K&T 606-678-9623 or 606-561-4983 OPERATION COLD START - ELECTRIC STARTER ELECTRIC STARTER 1. Insert safety ignition key into the ignition slot until it 1. Connect the power cord to the engine. clicks. DO NOT turn the key. Keep the extra safety 2.
For Parts Call K&T 606-678-9623 or 606-561-4983 MAINTENANCE GENERAL REC OM MEN DA TIONS LUBRICATION CHART The warranty on this snow thrower does not cover items that ➀ SAE 30 Motor Oil have been sub ject ed to operator abuse or negligence. To receive full value from the warranty, operator must maintain ➁...
For Parts Call K&T 606-678-9623 or 606-561-4983 MAINTENANCE V-BELTS TO CHANGE ENGINE OIL Check V-belts for deterioration and wear after every 50 Determine temperature range anticipated before next oil hours of operation and replace if necessary. The belts change. All oil must meet API service classifi cation SF-SJ. are not ad just able.
For Parts Call K&T 606-678-9623 or 606-561-4983 SERVICE AND ADJUSTMENTS 1. Disengage all controls and move throttle control to WARNING: To avoid serious injury, STOP position. Wait for all moving parts to stop. before performing any service or ad- 2. Disconnect spark plug wire from spark plug and place just ments: it wear it cannot come in contact with spark plug.
For Parts Call K&T 606-678-9623 or 606-561-4983 SERVICE AND ADJUSTMENTS TO REPLACE BELTS (See Fig. 23) The auger and traction drive belts are not adjustable. If the HINT: Insert a 3/8" drive ratchet (in the “ON” position) into belts are damaged or begin to slip from wear, they should the square hole in idler arm and rotate ratchet clockwise be replaced.
For Parts Call K&T 606-678-9623 or 606-561-4983 TO REMOVE WHEELS (See Fig. 24) NOTE: To seal punctures or prevent fl at tires due to slow leaks, tire sealant may be purchased from your local parts • Remove the klik pin and remove wheel from axle. dealer.
For Parts Call K&T 606-678-9623 or 606-561-4983 TROUBLESHOOTING See appropriate section in manual unless directed to a qualifi ed service center. PROBLEM CAUSE CORRECTION Does not start 1. Fuel shut-off valve (if so 1. Turn fuel shut-off valve to OPEN position. equipped) in OFF position.
For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS SNOW THROWER - MODEL NUMBER PP927ESA AUGER HOUSING / IMPELLER ASSEMBLY 44 27 www.mymowerparts.com...
Page 21
For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS SNOW THROWER - MODEL NUMBER PP927ESA AUGER HOUSING / IMPELLER ASSEMBLY KEY PART DESCRIPTION 183578 Bag, Weight 183577 Bracket, Weight Bag 74520524 Screw, Hex Head 5/16-18 x 1-1/2 181083 Pulley, Impeller...
Page 22
For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS SNOW THROWER - MODEL NUMBER PP927ESA CONTROL PANEL / DISCHARGE CHUTE www.mymowerparts.com...
Page 23
For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS SNOW THROWER - MODEL NUMBER PP927ESA CONTROL PANEL / DISCHARGE CHUTE KEY PART DESCRIPTION 183334 Knob, Lever 17501010 Screw #10-24 x 5/8 178674 Control Assembly, Defl ector 73800600 Nut, Lock 3/8-16...
Page 24
For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS SNOW THROWER - MODEL NUMBER PP927ESA HANDLES www.mymowerparts.com...
Page 25
For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS SNOW THROWER - MODEL NUMBER PP927ESA HANDLES KEY PART DESCRIPTION 178875X479 Lever, Auger Control, RH 178648X479 Lever, Traction Drive Control, LH 179439 Nut, Cage 1/4-20 178888 Bushing, Flange 169675 Retainer, Hairpin...
Page 26
For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS SNOW THROWER - MODEL NUMBER PP927ESA DRIVE 9 10 www.mymowerparts.com...
Page 27
For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS SNOW THROWER - MODEL NUMBER PP927ESA DRIVE KEY PART DESCRIPTION 146315 Screw, Hex Head 5/16-18 x 3/4 73800500 Nut, Lock 5/16-18 155415 Washer, Flat 17490508 Screw, Hex Head 5/16-18 x 1/2...
Page 28
For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS SNOW THROWER - MODEL NUMBER PP927ESA CHASSIS / ENGINE / PULLEYS 10 21 53 54 www.mymowerparts.com...
Page 29
For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS SNOW THROWER - MODEL NUMBER PP927ESA CHASSIS / ENGINE / PULLEYS KEY PART DESCRIPTION 181044 Spring, Traction Idler 180522 Pulley, Idler (2-1/4) - - - Engine, Tecumseh, Model Number OHSK90 (Order parts from Engine manufacturer)
Page 30
For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS SNOW THROWER - MODEL NUMBER PP927ESA WHEELS / DECALS 32 30 32 30 25 24 www.mymowerparts.com...
Page 31
For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS SNOW THROWER - MODEL NUMBER PP927ESA WHEELS / DECALS KEY PART DESCRIPTION 178834 Wheel Assembly (16" Power Steer) 155443 Pin, Klik 1/4 181843 Cover, Power Steering 17541008 Screw, Hex Head #10-24 x 1/2...
For Parts Call K&T 606-678-9623 or 606-561-4983 LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from de- fects in materials and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we fi...
