Room Air Conditioner

SERVICE MANUAL

CAUTION
-BEFORE SERVICING THE UNIT, READ THE SAFETY
PRECAUTIONS IN THIS MANUAL.
-ONLY FOR AUTHORIZED SERVICE PERSONNEL.
MODEL : LS-Q076ABL/BBG/BEL/ABG
LS-Q096ABL/BBG/BEL/AEL
LS-Q096ACG/ADG/ADL/BDL
LS-Q096AHG/ABG/ABM/AEM
LS-Q096BAG/BDG
LS-Q096ACL/AAG
LS-Q082BAG/BAM
LS-Q082AAL/ACG/ACL/ACM
LS-H096QNA0
LS-Q096BEG
http://www.LGEservice.com/techsup.html

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS-Q076ABL and is the answer not in the manual?

Questions and answers

Related Manuals for LG LS-Q076ABL

Summary of Contents for LG LS-Q076ABL

  • Page 1: Room Air Conditioner

    WEBSITE http://biz.LGservice.com E-MAIL http://www.LGEservice.com/techsup.html Room Air Conditioner SERVICE MANUAL CAUTION -BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. -ONLY FOR AUTHORIZED SERVICE PERSONNEL. MODEL : LS-Q076ABL/BBG/BEL/ABG LS-Q096ABL/BBG/BEL/AEL LS-Q096ACG/ADG/ADL/BDL LS-Q096AHG/ABG/ABM/AEM LS-Q096BAG/BDG LS-Q096ACL/AAG LS-Q082BAG/BAM LS-Q082AAL/ACG/ACL/ACM LS-H096QNA0 LS-Q096BEG...

  • Page 2: Table Of Contents

    Contents Details of LG Model Name(2002) ..................3 Details of LG Model Name(2003) ..................4 Functions ..........................5 Product References ......................8 Dimensions ..........................9 Refrigeration Cycle Diagram ....................12 Wiring Diagram........................13 Operation Details ......................... 14 Display Function ........................21 Self-diagnosis Function.......................

  • Page 3: Details Of Lg Model Name(2002)

    Details of LG Model Name(2002) Code Type Code of Model Meaning Type of Airconditioner LS: LG Split Type Airconditioner Chassis Name of toll of Unit Ex. LS-R S R Chassis Capacity(Btu/h) Cooling/Heating Capacity Ex. "09" 9,000Btu/h Electric Range Electric Standard...

  • Page 4: Details Of Lg Model Name(2003)

    Details of LG Model Name(2003) Code Type Code of Model Meaning Producing Center, L: Chang-won R22 N: India Refrigerant A: Chang-won R410A Z: Brazil C: Chang-won R407C D: Indonesia T: China M: Mexico K: Turkey R22 V: Vietnam E: Turkey R410A...

  • Page 5: Functions

    Functions Indoor Unit Operation ON/OFF by Remote controller Sensing the Room Temperature • Room temperature sensor. (THERMISTOR) Room temperature control • Maintains the room temperature in accordance with the Setting Temp. Starting Current Control • Indoor fan is delayed for 5 sec at the starting. Time Delay Safety Control •...

  • Page 6: Remote Control

    Remote Control Operation ON/OFF Operation Mode Selection Cooling Operation Mode.( Auto Operation Mode.( (Cooling (Heating Healthy Dehumidification Operation Mode.( Heating Operation Mode.( model only) model only) Fan Speed Selection (Low) (Med) (High) (CHAOS) Room, Temperature Display : (High:39°C Low:11°C) Temperature Setting HIGH TEMPERATURE Down to 18°C...
  • Page 7 Remote Control Operation ON/OFF Operation Mode Selection Cooling Operation Mode.( Auto Operation Mode.( (Cooling (Heating Healthy Dehumidification Operation Mode.( Heating Operation Mode.( model only) model only) Fan Speed Selection (Low) (Med) (High) Room, Temperature Checking : (High:39°C Low:11°C) Temperature Setting HIGH TEMPERATURE Down to 18°C...

  • Page 8: Product References

    Product References LS-Q096BAG, LS-Q096ACG LS-Q096BBG, LS-Q096BEL LS-Q076BBG LS-Q096ACL, LS-Q096AAL LS-Q096AHG, LS-Q096ABL LS-Q082BAG/BAM LS-Q076BEL Model Name LS-Q096ADG, LS-Q096ADL LS-Q096ABG, LS-Q096AEL LS-Q082AAL/ACG LS-H096QNA0 LS-Q076ABL LS-Q082ACL/ACM LS-Q096BDG, LS-Q096BDL LS-Q096ABM, LS-Q096AEM LS-Q076ABG Item Unit LS-Q096AAG LS-Q096BEG 7,000 9,000 9,000 8,000 9,000 Cooling Capacity Btu/h...

  • Page 9: Dimensions

    Dimensions (1) Indoor Unit Installation plate MODEL All Models Unit...
  • Page 10 (2) Outdoor Unit Gas side (3-way valve) Liquid side (2-way valve) MODEL 7K Heat Pump, 9K Cooling unit -10-...
  • Page 11 (3) Outdoor Unit Gas side (3-way valve) Liquid side (2-way valve) MODEL 9K Heat Pump unit -11-...

  • Page 12: Refrigeration Cycle Diagram

    Refrigeration Cycle Diagram (1) Cooling Only Models INDOOR UNIT OUTDOOR UNIT LIQUID SIDE CAPILLARY TUBE HEAT HEAT EXCHANGE EXCHANGE (EVAPORATOR) (CONDENSER) GAS SIDE COMPRESSOR (2) Cooling & Heating Models INDOOR UNIT OUTDOOR UNIT CHECK VALVE LIQUID SIDE (Heating Model only) VALVE CAPILLARY TUBE HEAT...

  • Page 13: Wiring Diagram

    Wiring Diagram (1) Indoor Unit 1. LS-Q076ABL, LS-Q076BBG, LS-Q076BEL 2. LS-Q096AAG, LS-Q096AAL, LS-Q096ACG 3. LS-Q082BAG, LS-Q096ACL, LS-Q082AAL LS-Q096ABL, LS-Q096ABG, LS-Q066AHG LS-Q096ADL, LS-Q096ADG, LS-Q096BAG LS-Q082ACG, LS-Q082ACL, LS-Q082ACM LS-Q096AEL, LS-Q096BBG, LS-Q096ABM LS-Q096BAG, LS-Q096BDG, LS-Q096BDL LS-Q096AEM, LS-H096QNA0, LS-Q096BEG LS-Q082BAM AC PWB ASM DC PWB ASM AC PWB ASM.

  • Page 14: Operation Details

    Operation Details 1. MAIN UNIT FUNCTION • DISPLAY 1) C/O Model Operation Indicator • ON while in appliance operation, OFF while in appliance pause. • Flashing while in disconnection or short in Thermistor. (3 sec off / 0.5 sec on) Sleep Timer Indicator •...

  • Page 15: Defrost Control

    • While in compressor off, the indoor fan repeats low airflow speed and pause. • While the intake air temp is between compressor on temp. and compressor off temp., 10-min dehumidifica- tion operation and 4-min compressor off repeat. Compressor ON Temp. Setting Temp+0.5°C Compressor OFF Temp.
  • Page 16 Fuzzy Operation (C/O Model) • According to the temperature set by Fuzzy rule, when the intake air temp is 0.5°C or more below the setting temp, the compressor is turned off. When 0.5°C or more above the setting temp, the compressor is turned on. Compressor ON Temp Setting Temp + 0.5°C Compressor OFF Temp...
  • Page 17 2) Fuzzy Operation for Dehumidification • According to the setting temperature selected by Fuzzy rule, when the intake air temp is 0.5°C or more below the setting temp, the compressor is turned off. When 0.5°C or more above the setting temp, the compressor is turned on.

  • Page 18: Sleep Timer Operation

    Off-Timer Operation • When the set time is reached after the time is input by the remote control, the appliance stops operating. • The timer LED is on when the off-timer is input. It is off when the time set by the timer is reached. •...

  • Page 19: Forced Operation

    Jet Cool Mode Operation (C/O Model) • If the Jet Cool key is input at any operation mode while in appliance operation, the Jet Cool mode operates. • In the Jet Cool mode, the indoor fan is operated at super-high speed for 30 min at cooling mode operation. •...
  • Page 20 Remote Control Operation Mode • When the remote control is selected by the slide switch on the main unit, the appliance operates according to the input by the remote control. Protection of the evaporator pipe from frosting • If the indoor pipe temp is below 0°C in 7 min. after the compressor operates without any pause while in cool- ing cycle operation mode, the compressor and the outdoor fan are turned off in order to protect the indoor evaporator pipe from frosting.

  • Page 21: Display Function

    Display Function 1. Heating Model 2. Cooling Model Operation Indicator Operation Indicator • Cooling, Soft Dry, Fan, Heating • Cooling, Soft Dry, Fan Sleep Timer Indicator Sleep Timer Indicator • Sleep Mode • Sleep Mode Timer Indicator Timer Indicator • Timer Mode •...

  • Page 22: Installation

    Installation 1. Installation of indoor, Outdoor unit 1) Selection of the best location • Select a place so that the warm air and noise from the air conditioner do not disturb neighbors. 1. Indoor unit More than 10 cm • Do not have any heat or steam near the unit. More than 10 cm •...
  • Page 23 3) How to fix installation plate 4) Drill a hole in the wall The wall you select should be strong and solid enough • Drill the piping hole with a ø70mm hole core drill. Drill to prevent vibration the piping hole at either the right or the left with the hole slightly slanted to the outdoor side.

  • Page 24: Flaring Work And Connection Of Piping

    2. Flaring Work and Connection of Piping 1) Flaring work 4. Flaring work • Firmly hold copper pipe in a die in the dimension Main cause for refrigerant leakage is due to defect in shown in the table above. the flaring work. Carry out correct flaring work using the following procedure.
  • Page 25 2) Connection of piping Indoor 3. Tape the tubing, drain hose, and the connecting cable. Be sure that the drain hose is located at the • Preparing the indoor unit's piping and drain hose for lowest side of the bundle. Locating at the upper installation through the wall.

  • Page 26: For Left Rear Piping

    • Tighten the flare nut with a wrench. • Wrap the area which accommodates the rear piping housing section with vinyl tape. Open-end wrench (fixed) Indoor Connection unit pipe pipe Flare nut Vinyl tape Wrap with vinyl tape (wide) Connection pipe Wrench Connecting cable Indoor unit tubing...
  • Page 27 3. Insert the connecting cable into the indoor unit. Outside diameter Torque • Don't connect the cable to the indoor unit. kg . m inch • Make a small loop with the cable for easy connection Ø6.35 later. Ø9.52 Ø12.7 4.

  • Page 28: Connection Of The Pipes-Outdoor

    • Bundle the piping and drain hose together by wrap- 3) Connection of the pipes-Outdoor ping them with cloth tape over the range within which they fit into the rear piping housing section. 1. Align the center of the pipings and sufficiently tighten the flare nut by hand.

  • Page 29: Connecting The Cable Between Indoor Unit And Outdoor Unit

    3. Connecting The Cable Between Indoor Unit and Outdoor Unit 1) Connect the cable to the Indoor unit. • Connect the cable to the indoor unit by connecting the wires to the terminals on the control board in dividually according to the outdoor unit connection. (Ensure that the color of the wires of the outdoor unit and the terminal No.
  • Page 30 2) Connect the cable to the outdoor unit Outdoor unit Terminal block (Pillar terminal) 1. Remove the control cover from the unit by loos- Connecting ening the screw. cable Connect the wires to the terminals on the control Holder for board individually.

  • Page 31: Checking The Drainage And Forming The Pipings

    4. Checking the Drainage and Forming the Pipings 1) Checking the drainage 2) Form the piping 1. To remove the front panel from the indoor unit. 1. Form the piping by wrapping the connecting por- • Set the air direction louvers up-and-down to the posi- tion of the indoor unit with insulation material and tion(horizontally) by hand.

  • Page 32: Test Running

    5. Test Running 1. Check that all tubing and wiring have been properly connected. Intake temperature 2. Check that the gas and liquid side service valves are fully open. Discharge air 1. Prepare remote control 1. Remove the battery cover by pulling it according to the Discharge arrow direction.

  • Page 33: Operation

    Operation Name and Function-Remote Control The remote control transmits the signals to the system. START/STOP BUTTON Operation starts when this button is pressed and stops when the button is pressed again. Remote Control OPERATION MODE SELECTION BUTTON Used to select the operation mode. Signal transmitter ROOM TEMPERATURE SETTING BUTTONS Used to select the room temperature.
  • Page 34 Name and Function-Remote Control The remote control transmits the signals to the system. START/STOP BUTTON Operation starts when this button is pressed and stops when the button is pressed again. Remote Control OPERATION MODE SELECTION BUTTON Used to select the operation mode. Signal transmitter ROOM TEMPERATURE SETTING BUTTONS Used to select the room temperature.

  • Page 35: Disassembly Of The Parts (Indoor Unit)

    Disassembly of the parts (Indoor unit) Warning : Disconnect the unit from power supply before making any checks. Be sure the power switch is set to “OFF”. To remove the Grille from the Chassis. • Set the up-and-down air discharge louver to open position (horizontally) by finger pressure.
  • Page 36 2. To remove the Control Box. • Remove securing screws. • Pull the control box out from the chassis careful- Caution label 3. To remove the Discharge Grille. • Unhook the discharge grille and pull the dis- charge grille out from the chassis carefully. 4.
  • Page 37 • Unhook the tab on the right inside of the chassis at the same time, slightly pull the evaporator toward you until the tab is clear of the slot. 5. To remove the Motor Cover • Remove 2 securing screw. •...

  • Page 38: 2-Way, 3-Way Valve

    2-way, 3-way Valve 2-way Valve (Liquid Side) 3-way Valve (Gas Side) Valve cap Hexagonal wrench (4mm) Open position Flare nut Flare nut Closed position Open position Closed position piping piping Service Service connection connection port cap port To outdoor unit To outdoor unit Works Shaft position...

  • Page 39: Air Purging

    1. Air purging Required tools : hexagonal wrench, adjustable The air in the indoor unit and in the piping must be wrench, torque wrenches, wrench to purged. If air remains in the refrigeration pipes, it will hold the joints, and gas leak detec- affect the compressor, reduce to cooling capacity, and tor.

  • Page 40: Pumping Down

    2. Pumping down Liquid side Indoor unit Outdoor unit Open 2-Way valve Gas side Closed 3-Way valve CLOSE CLOSE Purge the air • Procedure (6) Operate the air conditioner at the cooling (1) Confirm that both the 2-way and 3-way valves cycle and stop it when the gauge indicates are set to the open position.
  • Page 41 1) Re-air purging (Re-installation) Liquid side Indoor unit Closed Outdoor unit 2-Way valve Gas side Closed 3-Way valve Gas cylinder OPEN CLOSE • Procedure (6) Disconnect the charge set and the gas cylin- (1) Confirm that both the 2-way valve and the 3- der, and set the 2-way and 3-way valves to the way valve are set to the closed position.
  • Page 42 2) Balance refrigerant of the 2-way, 3-way valves (Gas leakage) Liquid side Indoor unit Outdoor unit 2-Way valve Open Gas side 3-Way valve Open OPEN CLOSE • Procedure (3) Open the valve (Lo side) on the charge set and discharge the refrigerant until the gauge (1) Confirm that both the 2-way and 3-way valves indicates 0 kg/cm are set to the back seat.
  • Page 43 3. Evacuation (All amount of refrigerant leaked) Liquid side Indoor unit Outdoor unit 2-Way valve Open Gas side 3-Way valve Open Vacuum pump OPEN CLOSE • Procedure (4) Disconnect the charge hose from the vacuum pump. (1) Connect the vacuum pump to the charge set’s –...

  • Page 44: Gas Charging

    4. Gas Charging (After Evacuation) Liquid side Indoor unit Open Outdoor unit 2-Way valve Gas side Open 3-Way valve Check valve Charging cylinder OPEN CLOSE • Procedure (1) Connect the charge hose to the charging This is different from previous procedures. cylinder.

  • Page 45: Cycle Troubleshooting Guide

    Cycle Troubleshooting Guide Trouble analysis 1. Check temperature difference between intake and discharge air and operating current. Temp. difference : approx. 0°C • All amount of refrigerant leaked Current : less than 80% of out. Check refrigeration cycle. rated current Temp.

  • Page 46: Electronic Parts Troubleshooting Guide

    Electronic Parts Troubleshooting Guide 1. Product does not operate at all. (* Refer to Electronic Control Device drawing and Schematic diagram.) Turn off Main Power (After 10 seconds) Turn on Main Power Does "beeping" sound is made from the Indoor Unit? Primarily, the operating condition of Micom is OK.
  • Page 47 2. The product is not operate with the remote control. Turn on Main Power While the compressor has been stopped, the compressor does not operate owing to the delaying function for 3 minutes after stopped. When the compressor stopped Indoor Fan is driven by a low speed. At this point the wind speed is not controlled by the remote controller.
  • Page 48 3. Compressor/Outdoor Fan are unable to drive. Turn on Main Power Operate "Cooling Mode( )" by setting the desired temperature of the remote controller is less than one of the indoor temperature by 1°C at least. When in Air Circulation Mode, Compressor/Outdoor Fan is stopped. Check the sensor for indoor temperature is attached as close as to be effected by the temperature of Heat Exchanger(EVA).

  • Page 49: When Indoor Fan Does Not Operate

    4. When indoor Fan does not operate. Turn off Main power Check the connection of CN-MOTOR Check the Fan Motor Check the Fuse(AC250V/T2A) Check the related circuit of indoor Fan Motor. • The pin NO 58 of Micom, and the part for driving TRIAC(the input and output signal of IC01M, PIN NO 7, 10) •...
  • Page 50 5. When Vertical Louver does not operate. • Confirm that the Vertical Louver is normally geared with the shaft of Stepping Motor. • If the regular torque is detected when rotating the Vertical Louver with hands Normal • Check the connecting condition of CN-U/D Connector •...
  • Page 51 6. When Heating does not operate Turn ON Main Power Operate “Heating Mode( )” by setting the desired temperature of the remote control is higher than one of the indoor temperature by 2°C at least. In heating Mode, the indoor fan operates in case the pipe temperature is higher than 28°C.
  • Page 52 Turn off Main Power • Check the electrical wiring diagram of outdoor side. • Check the abnormal condition for the component of Compressor/Out- door Fan Motor, 4 way. • Check the "open" or "short" of connecting wires between indoor and outdoor.

  • Page 53: Electronic Control Device

    Electronic Control Device (1) MAIN P.W.B ASSEMBLY (AC PART) • TOP VIEW • BOTTOM VIEW (1) MAIN P.W.B ASM (AC) • COOLING MODEL • HEAT PUMP MODEL -53-...
  • Page 54 (2) MAIN P.W.B ASSEMBLY (DC PART) • TOP VIEW • BOTTOM VIEW • TOP VIEW • BOTTOM VIEW -54-...
  • Page 55 (3) DISPLAY ASSEMBLY – 6871A20194 TOP VIEW BOTTOM VIEW – 6871A30009 TOP VIEW BOTTOM VIEW – 6871A20227 TOP VIEW BOTTOM VIEW -55-...

  • Page 56: Schematic Diagram

    Schematic Diagram -56-...
  • Page 57 Cooling Model • LED TYPE -57-...
  • Page 58 Cooling Model • HVB TYPE(PLASMA) -58-...
  • Page 59 Heat Pump Model • LED TYPE 4WAY -59-...
  • Page 60 Heat Pump Model • HVB TYPE 4WAY -60-...

  • Page 61: Exploded View And Replacement Parts List

    Exploded View and Replacement Parts List 1. Indoor Unit 135312 152313 135314 152302 131410 733010 359011 267110 342800 159830 135311 159901 268712 346810 35211B 249951 135516 354212 TYPE B TYPE A 249951 263230 352150 268714-2 268714-1 146811-2 146811-1 264110 268714-1 264110 266090 268714-2...
  • Page 62 Parts List(Indoor) PART No. LOCATION No. DESCRIPTION REMARKS LS-Q076ABL LS-Q076BBG LS-Q076BEL 131410 CHASSIS ASSEMBLY 3141A20006A 3141A20006B 3141A20006A 135311 GRILLE ASSEMBLY, DISCHARGE(INDOOR) 3531A10127A 3531A10127E 3531A10127E 135312 GRILLE ASSEMBLY, FRONT(INDOOR) 3531A20101B 3531A20103B 3531A20101E 135314 GRILLE ASSEMBLY, INLET SUB 3531A20100B 3531A20102D 3531A20100C 135516...
  • Page 63 Parts List(Indoor) PART No. LOCATION DESCRIPTION REMARKS LS-Q096ABL LS-Q096BBG LS-Q096BEL LS-Q096AEM LS-Q096BEG 131410 CHASSIS ASSEMBLY 3141A20006A 3141A20006B 3141A20006A 3141A20006A 3141A20006A 135311 GRILLE ASSEMBLY, DISCHARGE(INDOOR) 3531A10127A 3531A10127E 3531A10127E 3531A10232J 3531A10127R 135312 GRILLE ASSEMBLY, FRONT(INDOOR) 3531A20101B 3531A20103B 3531A20101E 3531A10167C 3531A10225E 135314 GRILLE ASSEMBLY, INLET SUB 3531A20100B 3531A20102D 3531A20100C...
  • Page 64 Parts List(Indoor) PART No. LOCATION DESCRIPTION REMARKS LS-Q096AHG LS-Q096ACG LS-Q096BAG LS-Q096ACL LS-Q096AAG 131410 CHASSIS ASSEMBLY 3141A20006B 3141A20006B 3141A20006B 3141A20006B 3141A20006A 135311 GRILLE ASSEMBLY, DISCHARGE(INDOOR) 3531A10127H 3531A10127H 3531A10127H 3531A10127H 3531A10127P 135312 GRILLE ASSEMBLY, FRONT(INDOOR) 3531A20103H 3531A20103A 3531A20103J 3531A20101K 3531A20103U 135314 GRILLE ASSEMBLY, INLET SUB 3531A20102H 3531A20102A 3531A20102J...
  • Page 65 Parts List(Indoor) PART No. LOCATION DESCRIPTION REMARKS LS-Q096ABG LS-Q076ABG LS-Q082BAG LS-Q082BDL LS-N096QNA0 131410 CHASSIS ASSEMBLY 3141A20006A 3141A20006A 3141A20006A 3141A20006A 3141A20006A 135311 GRILLE ASSEMBLY, DISCHARGE(INDOOR) 3531A10127A 3531A10127A 3531A10127E 3531A10127A 3531A10127P 135312 GRILLE ASSEMBLY, FRONT(INDOOR) 3531A20101B 3531A20101B 3531A20103J 3531A20101T 3531A10194K 135314 GRILLE ASSEMBLY, INLET SUB 3531A20100B 3531A20100B 3531A20102J...
  • Page 66 Parts List(Indoor) PART No. LOCATION DESCRIPTION REMARKS LS-Q096AEL LS-Q096ADG LS-Q096ADL LS-Q096BDG LS-Q096ABM 131410 CHASSIS ASSEMBLY 3141A20006A 3141A20006B 3141A20006A 3141A20006B 3141A20006B 135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A10127A 3531A10127A 3531A10127A 3531A10127E 3531A10127P 135312 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A20101B 3531A20103A 3531A20101A 3531A20103J 3531A10167F 135314 GRILLE ASSEMBLY,INLET SUB 3531A20100B 3531A20102A 3531A20100A...
  • Page 67 Parts List(Indoor) PART No. LOCATION DESCRIPTION REMARKS LS-Q082BAM LS-Q082AAL LS-Q082ACG LS-Q082ACL LS-Q082ACM 131410 CHASSIS ASSEMBLY 3141A20006B 3141A20006B 3141A20006A 3141A20006A 3141A20006A 135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A10127R 3531A10127A 3531A10127A 3531A10127A 3531A10127A 135312 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A10167G 3531A20101R 3531A20103G 3531A20101K 3531A10167H 135314 GRILLE ASSEMBLY,INLET SUB 3531A20142E 3531A20100P 3531A20102G...
  • Page 68 2. Outdoor unit 437210 552111 437212 552102 554031 435511 559010 546810 W0CZZ 649950 552116 567502 552202 554160 561410 550140 552203-1 552203-2 430410 -68-...
  • Page 69 Parts List(Outdoor) PART No. LOCATION No. DESCRIPTION REMARKS LS-Q076ABL LS-Q076BBG LS-Q076BEL LS-Q076ABG 437210 GRILLE ASSEMBLY, FRONT(OUTDOOR) 3531AR2512R 3531AR2512R 3531AR2512R 3531AR2512R 546810 MOTOR ASSEMBLY, OUTDOOR 4681A20004F 4681A20004F 4681A20004F 4681A20004F 430410 BASE ASSEMBLY, WELD[OUTDOOR] 3041AR2415K 3041AR2415K 3041AR2415K 3041AR2415K 435511 COVER ASSEMBLY, CONTROL(OUTDOOR)
  • Page 70 Outdoor unit 437210 437212 554031 435301 435511 546810 552102-2 559010 649950 552201 552111 552102-1 552116 W0CZZ 552202 567502 561410 554160 447910 550140 552203-1 430410 552203-2 -70-...
  • Page 71 Parts List(Outdoor) PART No. LOCATION DESCRIPTION REMARKS LS-Q096ACG LS-Q096BAG LS-Q096ACL LS-Q082BAG LS-Q096ABM LS-H096QNA0 430410 BASE ASSEMBLY, WELD[OUTDOOR] 3041AR2415K 3041AR2415K 3041AR2415K 3041AR2415E 3041A20008K 3041A20016A 435301 GRILLE, DISCHARGE 3530A20006B 3530A20006B 3530A20006B 3530A20006B 3530A20006B 3530A10059D 435511 COVER ASSEMBLY, CONTROL(OUTDOOR) 4994AR3492B 4994AR3492B 4994AR3492B 4994AR3492B 3551A30023E 3551A30023Q 437210 PANEL ASSEMBLY, FRONT(OUTDOOR) 3531AR2512R 3531AR2512R 3531AR2512R 3531AR2512R 3721A20027A 3721A20060B 437212 PANEL ASSEMBLY, REAR(OUTDOOR)
  • Page 72 Parts List(Outdoor) PART No. LOCATION DESCRIPTION REMARKS LS-Q096ABL LS-Q096BBG LS-Q096BEL LS-Q096AHG LS-Q096ABG LS-Q096AEM 430410 BASE ASSEMBLY, OUTDOOR 3041A20008K 3041A20008K 3041A20008K 3041A20008K 3041A20008K 3041A20008K 435511 COVER ASSEMBLY, CONTROL(OUTDOOR) 3551A30023E 3551A30023E 3551A30023E 3551A30023E 3551A30023E 3551A30023E 437210 PANEL ASSEMBLY, FRONT(OUTDOOR) 3721A20027A 3721A20027A 3721A20027A 3721A20027A 3721A20027A 3721A20027A 437212 PANEL ASSEMBLY, REAR(OUTDOOR) 3721A20026B 3721A20026B 3721A20026B 3721A20026B 3721A20026B 3721A20026B 447910 BARRIER ASSEMBLY, OUTDOOR...
  • Page 73 Parts List(Outdoor) PART No. LOCATION DESCRIPTION REMARKS LS-Q096BDG LS-Q096AEL LS-Q096ADG LS-Q096ADL LS-Q096AAG LS-Q096BEG LS-Q096BDL 430410 BASE ASSEMBLY,OUTDOOR 3041A20008K 3041AR2415K 3041AR2415K 3041AR2415K 3041AR2415K 3041A20008K 435301 GRILLE,DISCHARGE 3530A20006B 435301 GRILLE,DISCHARGE 3530A20006B 3530A20006B 3530A20006B 3530A20006B 435511 COVER ASSEMBLY,CONTROL(OUTDOOR) 3551A30023E 4994AR3492B 4994AR3492B 4994AR3492B 4994AR3492B 3551A30023E 437210 PANEL ASSEMBLY,FRONT(OUTDOOR) 3721A20027A 3531AR2512R 3531AR2512R 3531AR2512R 4994AR3492B 3721A20027A...
  • Page 74 Parts List(Outdoor) PART No. LOCATION DESCRIPTION REMARKS LS-Q082BAM LS-Q082AAL LS-Q082ACG LS-Q082ACL LS-Q082ACM 430410 BASE ASSY,WELD[OUTDOOR] 3041AR2415E 3041AR2415E 3041AR2415E 3041AR2415E 3041AR2415E 435511 COVER ASSEMBLY,CONTROL(OUTDOOR) 4994AR3492B 4994AR3492B 4994AR3492B 4994AR3492B 4994AR3492B 437210 GRILLE ASSEMBLY,FRONT(OUTDOOR) 3531AR2512R 3531AR2512R 3531AR2512R 3531AR2512R 3531AR2512R 437212 PANEL ASSEMBLY,REAR(OUTDOOR) 3530AR0058B 3530AR0058B 3530AR0058B 3530AR0058B...
  • Page 75 August, 2003 P/No.: 3828A20178A Printed in Korea...
