Radio Shack In-Ear Earbud Headset Owner's Manual

+P/'CT"'CTDWF"*GCFUGV
YKVJ"'CTJQQM
21-1897
# #
"+/2146#06"
If an icon appears at the end of a
paragraph, go to the box on that
page with the corresponding icon
for pertinent information.
R R R R ý #
— Warning — Important
° ° ° °
. . . .
— Caution — Hint
± ± ± ±
— Note
± ±
"016'" "
• Before setting your headset to
VOX or PTT, check your 2-way
radio to see if it has a VOX
function. If it does not, you can
only use your headset in PTT
mode. Do not set your headset
to VOX.
• Do not change your headset's
mode (VOX or PTT) while in
use.
OWNER'S MANUAL — Please read before using this equipment.
Thank you for purchasing a RadioShack In-Ear Earbud
Headset. Your headset allows handsfree operation of your
2-way radio. It is compatible with the Motorola FR50, FR60,
T289, T5100, T5200, T6200, T6300 series, and
RadioShack 21-1854, 21-1863 and 21-1864 FRS radios.
Clothing Clip – lets
you easily attach the
microphone to your
lapel or shirt.
Microphone with
PTT (Push to Talk)
Switch – lets you
transmit with a press
of the switch.
PTT/VOX Selection –
lets you select manual
or voice-activated
mode.
75+0)"6*'"*'#&5'6
1. Turn off your 2-way radio.
2. Before connecting the headset to your 2-way radio, set
on the headset to
VOX/PTT
for manual operation. ±
operation, or
PTT
3
3. Insert the / -inch (2.5mm) plug into your 2-way radio's
32
combined microphone/earphone jack.
4. Place the earphone in your ear, then adjust the earhook
to fit your ear. If you do not want to use the earhook,
©
2002 RadioShack Corporation.
All Rights Reserved.
RadioShack and RadioShack.com are trademarks
used by RadioShack Corporation.
Detachable Earhook
Earphone – fits either
your left or right ear.
Voice Activation Control (VOX) –
lets you set the headset to
automatically activate the radio so
you transmit only when you speak.
for voice-activated
VOX
