12-2020.fm Page 1 Tuesday, May 23, 2000 6:56 PM
4-Way Electronic Crossover
Your RadioShack 4-Way Electronic Cross-
over lets you get the best sound from your
auto sound system. It takes the full audio
range and splits it up into four smaller rang-
es. High frequencies are sent to the tweeters'
amplifier, middle-range frequencies are sent
to the mid-bass and mid-range speakers'
amplifier, and low frequencies are sent to the
subwoofer's amplifier.
Since each speaker only gets the frequen-
cies that it handles best, overall sound quali-
ty improves. The crossover even lets you
adjust the specific frequency ranges that
each speaker receives to precisely match its
capabilities.
The crossover's features include:
Remote Control — lets you adjust the sub-
woofer output level and boost the cross-
over's
frequency level.
BASS EQ
Subwoofer Equalizer — lets you set the
bass equalizer to 30–100 Hz.
Mid-Bass, Mid-Range, and Tweeter (High-
Range) Controls — let you adjust the mid-
bass, mid-range, and tweeter output levels.
Crossover Point Selectors — let you set
the frequency limits for the subwoofer, mid-
bass, mid-range, and tweeter.
Automatic Power On — the crossover turns
on when you turn on the vehicle's auto sound
system (when it is connected to a switched
power lead).
Low Input Selector — lets you select one-
line or two-line input to match your auto
sound system's line output.
OWNER'S MANUAL — Please read before using this equipment.
A complete auto sound system using this
crossover should also include:
• a receiver/CD player/cassette deck that
has line-level outputs
• any combination of one subwoofer, two
mid-bass
speakers, and two tweeters
• a separate power amplifier for each
speaker type or a power amplifier with
multiple input channels
INSTALLATION
You can easily connect this crossover. How-
ever, improper connections can damage
your crossover and other components in
your auto sound system and possibly your
vehicle's electrical system. Before you install
your crossover, read all the installation in-
structions in this owner's manual and follow
them carefully.
Before you begin, you should know which
wire is the power wire in your vehicle's elec-
trical system and be sure your auto sound
system has line-level outputs.
Notes:
• Use audio patch cables with phono-type
connectors (available at your local
RadioShack store) to complete the
input/output connections.
• Be sure to correctly match the input and
output connections' polarity (left output
to left input, and right output to right
input).
©
2000 RadioShack Corporation. All Rights Reserved.
RadioShack and RadioShack.com are trademarks
used by RadioShack Corporation.
speakers,
two
mid-range

Advertisement

loading

Summary of Contents for Radio Shack 4-Way Electronic Crossover

  • Page 1 12-2020.fm Page 1 Tuesday, May 23, 2000 6:56 PM 4-Way Electronic Crossover OWNER’S MANUAL — Please read before using this equipment. Your RadioShack 4-Way Electronic Cross- A complete auto sound system using this over lets you get the best sound from your crossover should also include: auto sound system.
  • Page 2 12-2020.fm Page 2 Tuesday, May 23, 2000 6:56 PM • Use 18-gauge wire (available at your over's (left) and (right) jacks. INPUT MAIN L local RadioShack store) to complete the Then set LOW INPUT power connections. If your auto sound system has two sets of line output jacks, connect the front output jacks to Choosing a Mounting Location the crossover's...
  • Page 3 12-2020.fm Page 3 Tuesday, May 23, 2000 6:56 PM Connecting Power tery power only when you set the vehicle’s ignition switch to ON or ACC. With this type of connection, the cross- over turns on when you set the ignition switch to ON or ACC.

  • Page 4: Adjusting The Controls

    12-2020.fm Page 4 Tuesday, May 23, 2000 6:56 PM immediately, then check the wiring con- Setting the SUB Crossover Point nections. Also, check the settings of other crossover point selector lets you set components in your auto sound system. If the upper frequency limit for subwoofer out- you hear no distortion or static, proceed to put.
  • Page 5 12-2020.fm Page 5 Tuesday, May 23, 2000 6:56 PM Hz, or Hz. All signals below If you do not want to set an upper frequency the selected crossover point are blocked; all limit so that frequencies higher than 4 kHz can signals at or above the selected crossover go to your mid-range speakers, slide the point go to your mid-bass speakers.

  • Page 6: Noise Suppression

    12-2020.fm Page 6 Tuesday, May 23, 2000 6:56 PM MOUNTING THE Noise Suppression CROSSOVER AND ITS Every vehicle produces its own electrical REMOTE CONTROL noise generated by the ignition system, alter- nator, and accessory systems. High-fidelity After you have correctly connected the cross- audio systems are susceptible to picking up over and set the controls, follow these steps to these noises.

  • Page 7: Replacing The Fuse

    12-2020.fm Page 7 Tuesday, May 23, 2000 6:56 PM • noise/spike suppressors to control igni- 1. Be sure the power source is off. tion coil, distributor, alternator, or genera- 2. Firmly grasp the fuse's plastic end and tor noise, as well as to eliminate pops and pull it out.
  • Page 8 12-2020.fm Page 8 Tuesday, May 23, 2000 6:56 PM Limited One-Year Warranty This product is warranted by RadioShack against manufacturing defects in material and workman- ship under normal use for one (1) year from the date of purchase from RadioShack company-owned stores and authorized RadioShack franchisees and dealers.
