ZINWELL

Real Scan

ZINWELL

User Manual

ZINWELL

PV-310 series

ZINWELL

Table of Contents

Need help?

Do you have a question about the Real Scan PV-310 series and is the answer not in the manual?

Questions and answers

Summary of Contents for Zinwell Real Scan PV-310 series

Page 1 ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL...
Page 2: Table Of Contents
Table of Contents Chapter 1 Introduction Important Notices ....................Product Functions ....................Package Contents ....................Chapter 2 Installation Product Outward ....................2.1.1 Front view of Real Scan ................2.1.2 Rear view of Real Scan ................System Installation ..................... Chapter 3 Operation Instruction Initial Setting .......................
Page 3: Chapter 1 Introduction
Chapter 1 Introduction Thanks for your purchase of Zinwell Real Scan. With Real Scan, you can turn your existing standard video to a high quality on your display devices. The system set up is very easy and there is no additional requirement for hardware or software.
Page 4: Package Contents
6. AAA batteries ..................x2 7. IR control..................x1 8. User manual..................x1 1. Real Scan Power supply 3. Video cable 6. AAA batteries x2 4.S-video cable VGA cable 7. IR control 8. User manual ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL ZINWELL...
Page 5: Chapter 2 Installation
Chapter 2 Installation 2.1 Product Outward 2.1.1 Front view of Real Scan PV-310 RealScan-PROGRESSIVE Power indicator and IR receiver Using blue LED to indicate the status of power and IR receiver Installation...
Page 6: Rear View Of Real Scan
2.1.2 Rear view of Real Scan VIDEO INPUT Please connect the external video from VCR, LD, V8 or video game to the VIDEO INPUT of box. S-VIDEO INPUT If the external video is s-video, please connect to the S-VIDEO INPUT of box. VGA OUTPUT Please use the VGA OUTPUT to your progressively scanned TV or projector.
Page 7: System Installation
2.2 System Installation : Progressively Big Screen scanned TV projector DVD/VCR/LD/IRD DVD/VCR/LD/IRD Video cable S-VIDEO cable S-VIDEO cable Camera Camera Video game Video game Adapter Adapter Please turn off the power of all devices before connection. Installation...
Page 8: Chapter 3 Operation Instruction
Chapter 3 Operation Instruction 3.1 Initial Setting When you finished the connections of Real Scan, because all the function settings are in the IR control, please refer to the following instructions of IR control and start the system setting. Steps: 1.
Page 9: Ir Control
3.2 IR Control POWER Res. Switch between power-on Select resolution of 1024x768, 800x600 and 640x480. Select Select the currently Menu highlighted menu item Display the main menu Exit Exit the current menu Adjust the selected item on selection and return to the parent menu.
Page 10: Advanced Setting
3.3 Advanced Setting 3.3.1 MAIN MENU The MAIN MENU shown below displays when you press "Menu" button. Press " " or " " button to select one of them below and press "Select" button to enter Sub-Menu. MAIN MENU PICTURE PREFERENCE EXIT 3.3.2 PICTURE setting...
Page 11: Osd Setting
3.3.3 OSD setting OSD Sub-Menu provides OSD POSITION selected mode and RESET. To enter OSD POSITION, press "Select" button in OSD. Using " ", " " or " ", " " button to adjust OSD menu to where you want on the screen. When you are finished making OSD POSITION adjustment, press "Exit"...
Page 12: Preference Setting
3.3.4 PREFERENCE setting PREFERENCE Sub-Menu provides RESOLUTION and INPUT SIGNAL modes. To select RESOLUTION or INPUT SIGNAL , press " " or" " button. To enter "1024 x 768", "800 x 600" or "640 x 480", press "Select" button in RESOLUTION. Press " "...
Page 13: Chapter 4 Other Information
Chapter 4 Other Information 4.1 Troubleshooting Symptom Solution Make sure the power cord is connected to No picture on display an AC outlet, DC plug is connected to DC IN port and the power LED is on. Make sure the display's power is on. Check the connection of your source signal.
Page 14: Specifications
4.2 Specifications POWER 12VDC 1.2A OUTPUT VIDEO INPUT Composite video RCA connector S-VIDEO INPUT S-Video 4-pin mini DIN VGA OUT D-Sub 15 pin Female connector Power Consumption 15W Typical ~ 45 Operating Temperature Operating Humidity 5% ~ 80% 5% ~ 80% Dimensions 230 x 140 x 40 mm 1080g...
Page 15 Operation Instruction...
Page 16 ZINWELL ZINWELL ZINWELL ZINWELL Headquarters : 7F, 512, Yuan Shan Rd., Chung Ho City, T aipei Hsien 235, Taiwan Tel: 886-2-2225-1929 Fax: 886-2-2225-1447 e-mail: zinwell@zinwell.com.tw http://www.zinwell.com.tw ZINWELL ZINWELL ZINWELL ZINWELL Hsinchu Plants (Sat-Comm & Satellite TV Product Sales) : 2, Wen Hua Rd., Hsin Chu Industrial Park, Hsin Chu Hsien 303,...
