Introduction
This Tyco Electronics/AMP Netconnect auto-negotiating Fast
Ethernet Media Converter translates between 10/100Base-TX
copper and 100Base-FX fiber cabling. The converter can be either
rack mounted in a 19" Chassis Unit or used as a standalone unit.
The Media Converter enables you to extend the distance of your
10/100BaseTX Ethernet network up to 2 kilometers for multi-mode
fiber or up to 30 kilometers for single-mode fiber. SC, ST and MT-RJ
optical multimode fiber connectors are available.
This range of media converters also includes a WDM ( Wavelength
Division Multiplexing ) Converter. This has exactly the same
functionality as the standard converters but the WDM technology
that combines the transmit (TX) and receive (RX) lines onto a single
fiber, which reduces cabling cost.
A pair of WDM converters ( wavelength 1310 and 1550 nm ) should
be installed at either end of the single fiber cable.
(AP) PL0336 Issue 1.36
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Tyco Electronics 10/100Mbit/s Ethernet Media Converters
- Page 1 Ethernet Media Converters Product User Guide Introduction This Tyco Electronics/AMP Netconnect auto-negotiating Fast Ethernet Media Converter translates between 10/100Base-TX copper and 100Base-FX fiber cabling. The converter can be either rack mounted in a 19” Chassis Unit or used as a standalone unit.
-
Page 2: Package Contents
Integral 1K MAC address table automatic learning n Supports back-pressure & flow control n DIP-switches to set the operation mode for the UTP and Fiber port n Fiber connectivity up to 2Km (multi-mode) or 30 Km (single-mode). WDM technology for single-mode only. Page 2 Tyco Electronics... -
Page 3: Technical Support And Service
If you have a faulty unit then please contact us through the web site to arrange for a replacement unit. The faulty unit must be returned to us as part of the replacement agreement. Page 3 Tyco Electronics... -
Page 4: Front Panel
Fiber Port. This port is for the 100 Base-FX connection to the distant media converter, NIC card or Ethernet switch. The port operates in either full duplex or half duplex modes depending on the setting of DIP switch 2. Page 4 Tyco Electronics... -
Page 5: Rear Panel
2. Open the rackmount bracket kit which contains two rackmount brackets with thumbscrews and four securing screws. 3. Attach a rackmount bracket on both sides of the media converter using a screwdriver. Page 5 Tyco Electronics... - Page 6 Figure 4 - Inserting the media converter into the chassis 5. Gently push the thumbscrews in and gently turn clockwise to tighten. Completing The Installation When the converter has been installed as specified above, then the system can be configured as detailed below:- Page 6 Tyco Electronics...
- Page 7 5. Verify that UTP LK/ACT LEDs light up when the UTP cable connection is correct, and Fiber LK/ACT LED is either green to show presence of a valid fiber link or blinks to indicate traffic activity. Page 7 Tyco Electronics...
-
Page 8: Dip Switch Settings
With DIP-switch 2 in the OFF (up) position, the fiber port will be configured in 100Mbit/s full-duplex mode (Default setting). Fiber Half-duplex With DIP-switch 2 in the ON (down) position, the fiber port is configured to 100Mbit/s half-duplex mode . Page 8 Tyco Electronics... - Page 9 For such applications the converter should operate in 100M operation. Notes:- § After changing the DIP-switch setting, the unit needs to be reset by power-cycling before the switch changes can take effect. Page 9 Tyco Electronics...
-
Page 10: Link Loss Forwarding (Llf)
“switch” converter mode is 1589 bytes including CRC and tagged VLAN extension. All Packets greater than 1589 bytes are discarded and so will not pass across the link. When in “pure” converter mode packets will not be rejected regardless of size. Page 10 Tyco Electronics... - Page 11 No device attached or faulty cable Orange The port is in full-duplex mode FDX/COL Blinks Collisions in half-duplex mode The port is in half-duplex mode or no device is attached. Table 1 - LED Status and description Page 11 Tyco Electronics...
-
Page 12: Troubleshooting
3. Check the configuration of the front panel DIP switches. The default setting for the fiber link is Full Duplex and the default setting for the UTP port is Auto-Negotiate. Link Loss Forwarding is disabled by default. See page 8 for DIP switch settings. Page 12 Tyco Electronics... -
Page 13: Product Part Numbers
Converter with MT-RJ multimode connector 0-1591028-x Converter with SC singlemode connectors 0-1591030-x WDM Converter with SC singlemode 1550nm 0-1591029-x WDM Converter with SC singlemode 1310nm 0-1591031-x Where –x is the country code. Consult dealer for precise codes. Page 13 Tyco Electronics... -
Page 14: Optical Fiber Specifications
Avg. Power Avg. Fast Ethernet Avg. Launch Loss Budget Sensitivity Converter Type Power dBm Multimode Converter (SC) Multimode Converter (ST) Multimode Converter (MT-RJ) Singlemode Converter (SC) Table 2 - Optical Specifications Page 14 Tyco Electronics... -
Page 15: Product Specification
0ºC to 45ºC (32ºF to 113ºF) Temperature Operating 10% to 90% (Non-condensing) Humidity Power Supply External Power Adapter DC 9V, 0.7 A Power 4 Watt. (Max.) Consumption FCC Class A, CE Mark Table 3 - Product Specifications Page 15 Tyco Electronics...
