HOME OF ULTRA AX314 / AX315 / AX316
SMART TECHNOLOGY
ELECTRIC SHOWER
Installation and User Guide
IMPORTANT:
IMPORTANT:
This booklet should be left with the user after
installation and demonstration.
We offer a technical advisory service on the
telephone to contractor with problems in the field.
RING 0844 372 7766
Advertisement
Table of Contents
Related Manuals for Home of ultra AX314
Summary of Contents for Home of ultra AX314
- Page 1 HOME OF ULTRA AX314 / AX315 / AX316 SMART TECHNOLOGY ELECTRIC SHOWER Installation and User Guide IMPORTANT: IMPORTANT: This booklet should be left with the user after installation and demonstration. We offer a technical advisory service on the telephone to contractor with problems in the field.
-
Page 2: Table Of Contents
Redring After Sales Service ......... . How your AX314 / AX315 / AX316 Shower Works ...... -
Page 3: How To Install Your Ax314 / Ax315 / Ax316 Shower
HOW TO INSTALL YOUR AX314 / AX315 / AX316 SHOWER WARNING: ALL WIRING AND INSTALLATION MUST BE SUPERVISED BY A SUITABLY QUALIFIED PERSON. WARNING: DO NOT INSTALL THIS SHOWER WHERE IT MAY BE SUBJECTED TO FREEZING CONDITIONS We recommend that the installation is done in the following sequence. - Page 4 7. If you have not yet done so, remove the front cover assembly by undoing the retaining screws at the top and bottom of the unit and lifting the cover off. Your shower is provided with 2 fixing positions in the backplate (see Diagram 7 on page 9). The top-fixing hole is a “key-hole”...
- Page 5 c) ELECTRICAL WARNING: THIS SHOWER MUST BE EARTHED. The electrical installation must be in accordance with the current BS.7671 (IEE Wiring Regulations) and “Part P” of the Building Regulations and/or local regulations 1. The shower unit is designed for a single phase AC electrical supply. Please check the rating plate on the unit to see what details apply to your shower.
-
Page 6: How To Maintain Your Ax314 / Ax315 / Ax316 Shower
That the holes in the shower handset are not blocked 7. DEMONSTRATE OPERATION TO USERS HOW TO MAINTAIN YOUR AX314 / AX315 / AX316 SHOWER It is recommended that the shower unit and hose etc. be cleaned using a soft cloth and that the use of abrasive or solvent based cleaning fluid be avoided, especially on any plated finishes. -
Page 7: How To Use Your Ax314 / Ax315 / Ax316 Shower (Detailed)
HOW TO USE YOUR AX314 / AX315 / AX316 SHOWER (DETAILED) Ensure the electricity and water are turned on to the unit. Your shower has 2 control knobs (see Diagram 6). Knob “A” controls the 3 power settings. The most popular is “High”. -
Page 8: What To Do If Things Go Wrong (1) Self Help
Cat No. 93597813 Additional accessories and spare parts can be Phased Shut-Down Relay Cat No. 93597878 supplied against any Credit or Debit cards Handset Cat No. 93597864 from Home of Ultra Hotline 0844 372 7750 Chrome Shower Hose 1.25m Cat No. 93797641... -
Page 9: What To Do If Things Go Wrong (2) Professional Service
“B” is pressed. Check circuit through shutdown PCB. If defective then replace. Power supply not reaching shower. HOME OF ULTRA AFTER SALES SERVICE We offer a technical advisory service on the telephone to installers and other customers with problems in the field. -
Page 10: How Your Ax314 / Ax315 / Ax316 Shower Works
HOW YOUR AX314 / AX315 / AX316 SHOWER WORKS 1. Water is heated instantaneously as it flows over the heating elements in the copper cylinder (Diagram 8). 2. The heaters are only switched on when sufficient water is flowing. This is done automatically with a switch which works on water pressure and is indicated by 2 or 3 lights illuminating depending on knob “A”... -
Page 11: Guarantee And Contact Details
GUARANTEE AND CONTACT DETAILS Full details of terms and conditions are available on request from:- Manufactured in England for:- ULTRA FINISHING LIMITED WIDOW HILL ROAD, HEASANDFORD INDUSTRIAL ESTATE, BURNLEY, LANCS, BB10 2BE TEL: 01282 436934 / FAX: 01282 428915 Technical Advice Line: 0844 372 7766 Website: www.ultra-group.co.uk... -
Page 12: How To Use Your Ax314 / Ax315 / Ax316 Shower (Summary)
HOW TO USE YOUR AX314 / AX315 / AX316 SHOWER (SUMMARY) 1. Ensure the electricity and water are turned on to the unit. 2. Press the start / stop button “B”. This will turn the shower on, the water will flow and the indicator lights will glow showing chosen Power Selection.
