- Page 1 NETWORK 1275 Danner Dr Tel:330-562-7070 TECHNOLOGIES Aurora, OH 44202 Fax:330-562-1999 INCORPORATED www.networktechinc.com ® VEEMUX Series SM-nXm-15V-LCD Video Matrix Switch Installation and Operation Manual MAN067 Rev Date 5/14/2007...
- Page 2 Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202. CHANGES The material in this guide is for information only and is subject to change without notice. Network Technologies Inc reserves the right to make changes in the product design without reservation and without notification to its users.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction..................................1 Basic Operation ................................1 Supported Web Browsers............................1 Compatibilty ................................. 1 Ordering Information..............................1 SM-nXm-15V-LCD ..............................1 Options..................................1 Materials ..................................2 Cables..................................2 Default User Name and Passwords ..........................2 Features and Functions..............................3 Installation.................................. - Page 4 Device Discovery Tool ..............................27 Infrared Control ................................28 Features And Functions............................. 28 Keypad..................................28 LCD Display ................................28 How To Use The IRT ..............................29 Change the Switch..............................29 Change Output Port ..............................30 Change Input Port..............................30 Set Configuration ..............................31 Battery Replacement ..............................
-
Page 5: Introduction
Ordering Information The SM-nXm-15V-LCD is built to a specific size ranging from 2, 4, 8, 12, or 16 monitors and 4 to 32 video sources. The “n” in the part number represents the number of video sources. Select a switch built for 4, 8, 16, or 32 video sources. The “m” in the part number represents the number of outputs (monitors). -
Page 6: Materials
NTI VEEMUX VIDEO MATRIX SWITCH Materials Materials Supplied with this kit: • NTI SM-nXm-15V-LCD Video Matrix switch • IEC Line cord, country specific • 4-#10-32 x 3/4" pan head screws and 10-32 cagenuts (server cabinet mounting hardware) • CD with: a pdf file of this owner's manual... -
Page 7: Features And Functions
NTI VEEMUX VIDEO MATRIX SWITCH Front View of SM-8X8-15V-LCD 1 2 3 4 6 7 8 VEEMUX Network Technologies Inc Menu Enter Rear View of SM-8X8-15V-LCD ETHERNET 1275 Danner Dr VIDEO VIDEO MONITOR MONITOR Aurora, OH 44202 www.nti1.com Tel:330-562-7070 Fax:330-562-1999 FEATURES AND FUNCTIONS LCD Display- for visual indication of connection between the monitor and a specific video source. -
Page 8: Installation
NTI VEEMUX VIDEO MATRIX SWITCH INSTALLATION Connect the Sources and Monitors Turn OFF power to all video sources (inputs) that will be connected to the VEEMUX before connecting or disconnecting any cables. Connect a VEXT-xx-MM cable from the video port of a video source to a 15HD female video connector labeled VIDEO 1 on the VEEMUX. -
Page 9: Connect Rs232
NTI VEEMUX VIDEO MATRIX SWITCH Connect RS232 RS232 control can be achieved using a separate user terminal or CPU with a terminal program. To make a terminal connection, connect a serial cable (specifications on page 31) between the user terminal and the 9 pin DIN female connector on the VEEMUX labeled "RS232". -
Page 10: Power Up
NTI VEEMUX VIDEO MATRIX SWITCH Power Up Plug the VEEMUX into an AC power outlet. Turn ON power to the VEEMUX. Turn ON power to the video sources and monitors connected to the VEEMUX. LED MATRIX (not available on all models) The LED Matrix is a grid of LEDs on the front panel of the VEEMUX. -
Page 11: Control Options
NTI VEEMUX VIDEO MATRIX SWITCH CONTROL OPTIONS The VEEMUX video matrix switch has four methods of control: • Front Panel LCD with Keypad • Directly via an RS232 Interface • Remotely via Ethernet (rack mount models only) • Infrared Remote (optional). Every unit comes standard with the Front Panel LCD with Keypad, and RS232 built in. -
Page 12: Scan Mode
NTI VEEMUX VIDEO MATRIX SWITCH Scan Mode Scan Mode causes an output port to automatically switch from one input port to the next consecutive input port after a specified period of time (referred to as the dwell time). Port switching will continue indefinitely and no ports will be skipped, whether there are video sources connected to them or not. -
Page 13: Baud Rate
NTI VEEMUX VIDEO MATRIX SWITCH On the DB-9 female connector, pins 4 (DSR) and 6 (DTR) are shorted and pins 7 (CTS) and 8 (RTS) are shorted. Therefore, host handshaking is bypassed and TXD and RXD are the only active signals. A straight through DB-9 cable (not null modem) will work for most CPUs. -
Page 14: Autostatus
NTI VEEMUX VIDEO MATRIX SWITCH Command Definitions (Cont'd) Command Good Response Description String RS SW *<CR> Internal Reset RV SW,00 *<CR>string\0<CR> Read NTI Version String RU SW *<CR>IP,OP<CR> Read Unit Size EA SW,ip *<CR> Set the IP address, ip is in xxx.xxx.xxx.xxx format, number of digits is minimum 1 and maximum 3 for each field Leading zeroes are accepted EM SW,ip... -
Page 15: Matrix Switcher's Control Program For Windows 9X, Nt, 2000 And Xp
NTI VEEMUX VIDEO MATRIX SWITCH Matrix Switcher's Control Program For Windows 9X, NT, 2000 AND XP The Matrix Switcher's Control Program is an easy and powerful graphical program that controls NTI matrix switches through an RS232 interface. The Matrix Switcher's Control Program is included on the CD packaged with the VEEMUX. The Matrix Switcher's Control Program is downloaded by clicking on the link "Download Matrix Switcher's Control Program"... -
Page 16: Ethernet Operations
NTI VEEMUX VIDEO MATRIX SWITCH Ethernet Operations Selection Description Set Unit IP Address - enter the desired IP address in xxx.xxx.xxx.xxx format - number of digits is minimum 1 and maximum 3 for each field. Leading zeroes are accepted Set Unit Subnet Mask - enter the desired IP address in xxx.xxx.xxx.xxx format - number of digits is minimum 1 and maximum 3 for each field. -
Page 17: Ethernet Control
NTI VEEMUX VIDEO MATRIX SWITCH ETHERNET CONTROL Telnet Interface-Port 2000 The Telnet Interface enables the user to control the switch using telnet client through an Ethernet connection. The telnet server listens on ports 2000 and 2005. Port 2000 is for an operator telnet session while port 2005 (must be enabled) is intended for a software control type session (see page 22). -
Page 18: Telnet Interface-Port 2005
NTI VEEMUX VIDEO MATRIX SWITCH S- nn,mm *<CR> Remove input mm from Scan List of output nn *<CR>oooxoxxxooooxxx< Sx nn Display the Scan List of output nn (o=skip x=don't skip) CR> <Ctrl>-<X> Good Bye. Quit telnet session (see note 4 below) Connection to host lost. -
Page 19: Command Detail
NTI VEEMUX VIDEO MATRIX SWITCH Command Detail RU-Read Unit Size Command: Byte 1 Byte2 Byte3 ‘R’ ‘U’ <CR> (0x52) (0x55) (0x0D) Response: Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8 Byte 9 ‘r’... -
Page 20: Ss_01- Enable Auto Status Mode
NTI VEEMUX VIDEO MATRIX SWITCH SS_01- Enable Auto Status Mode Command: Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 ‘S’ ‘S’ Space ‘0’ ‘1’ <CR> (0x53) (0x53) (0x20) (0x30) (0x31) (0x0D) Response: Byte 1 Byte 2 ‘∗’... -
Page 21: Terminate Telnet Session
NTI VEEMUX VIDEO MATRIX SWITCH Terminate telnet session Command: Byte 1 Byte 2 Byte 3 ‘X’ ‘X’ <CR> (0x58) (0x58) (0x0D) Response: Byte 1 Byte 2 <CR> ‘∗’ (0x0D) (0x2A) The unit will respond with ‘*’<CR> and close the connection, terminating the telnet session. The unit is then available for future connections. -
Page 22: Web Interface
NTI VEEMUX VIDEO MATRIX SWITCH Web Interface A user may control the connections of the VEEMUX using a Web Interface via any web browser (see page 1 for web supported browsers). With the VEEMUX connected to a LAN through an Ethernet cable, a user can access the web interface controls inside the VEEMUX. -
Page 23: Video Switch Page
NTI VEEMUX VIDEO MATRIX SWITCH Video Switch Page The Video Switch page (right) displays the active connections (shown in orange) and enables the user to control the video connections of the VEEMUX. Up to 100 different connection configurations can be saved and later recalled by any connection method. -
Page 24: Setup Pages
NTI VEEMUX VIDEO MATRIX SWITCH To save a configuraton, from the Stored Configurations user interface, use the drop-down list to select the desired slot (numbers 0-99) to save the active configuration into and press the Save button. Note: This will save the currently active configuration on the VEEMUX. -
Page 25: Video Input Names
NTI VEEMUX VIDEO MATRIX SWITCH Figure 11- Web interface Serial Setup page Changes to the Serial Address and Serial Speed (Fig. 11) do not require a reset and will take effect immediately. Video Input Names Note: Only the changes to the port directly to the left of the Save button will be saved. -
Page 26: Output Names
NTI VEEMUX VIDEO MATRIX SWITCH Output Names From the Administration menu, the Output Names page can be displayed. This page enables the Administrator to change the names of the output ports displayed on the Switch page. change an Output Name, enter the name of the port for the desired output port number, and press "Save". - Page 27 NTI VEEMUX VIDEO MATRIX SWITCH The output selection at the top of the page can be changed to any output to display the Scan Sequence Input selections and dwell times for that output. The inputs and the amount of time that each will be viewed (0-32000 seconds) can be set to cycle sequentially for each connected output.
-
Page 28: Update Firmware
NTI VEEMUX VIDEO MATRIX SWITCH Update Firmware For updating the Ethernet Control, use this section and insert the file v1_x.bin For updating the Front Panel LCD, use this section and insert the file rmtlcd_va_1_x. hex Figure 15- Web interface Update Firmware page The Update Firmware page (located in the main menu under "ADMINISTRATION") shows the current version of the firmware for the Web interface (Fig-15-upper) and for the Front panel (Fig-15-lower) and enables the Administrator to update the firmware of the VEEMUX. -
Page 29: Change Password Page
NTI VEEMUX VIDEO MATRIX SWITCH Change Password Page Figure 16- Web interface Password page Use this page to change the password for accessing the web interface. (This password is also used for the telnet interface.) Be sure to make note of the new password exactly as it is case sensitive. The password must be between 5 and 16 characters in length and can be alphabetical or numeric. -
Page 30: Logout Page
NTI VEEMUX VIDEO MATRIX SWITCH Logout Page Figure 18- Web interface Logout page This page will enable the user to end the session and close the web interface connection. Click on the "Press Here to Continue Logout" button to exit the VEEMUX web interface. Note: The connection will timeout automatically after a preset period of inactivity, configurable on the Web Setup page. -
Page 31: Device Discovery Tool
NTI VEEMUX VIDEO MATRIX SWITCH DEVICE DISCOVERY TOOL In order to easily locate the VEEMUX on a network, or to change network settings, the NTI Device Discovery Tool may be used. A link to the Discovery Tool is provided on the web page that appears when you insert the instruction manual CD provided into your CD ROM drive. -
Page 32: Infrared Control
Unless otherwise specified, by default, all IRT-enabled switches will be configured as switch #1. Materials included: • IRT-64X32 Infrared Remote Transmitter for video matrix switches • (2) AA Cell Batteries- installed Network Technologies Inc Features And Functions Lo Batt Keypad Buttons Numbered 0-9 – Used for port selection OUT –... -
Page 33: How To Use The Irt
NTI VEEMUX VIDEO MATRIX SWITCH How To Use The IRT The IRT-64X32 enables the user to control the connections of up to 32 input ports and 16 output ports on up to four (4) separate NTI video matrix switches. When any key is pressed, the IRT will power ON. A number key should always be pressed first unless a change to the configuration is desired (see "Set Configuration"... -
Page 34: Change Output Port
NTI VEEMUX VIDEO MATRIX SWITCH Change Output Port Press the desired port number. If there is no change in the desired output port, the output port must still be selected. As the digits are selected, the last number entered will blink. The LCD will also display the current switch number followed by the decimal point. -
Page 35: Set Configuration
NTI VEEMUX VIDEO MATRIX SWITCH Set Configuration The IRT-64x32 factory default setting is 32 inputs and 16 outputs. When the batteries are changed the setting will return to the default value. At the default setting the IRT has the ability control any matrix switch with up to 32 inputs and 16 outputs without changing the configuration. -
Page 36: Battery Replacement
NTI VEEMUX VIDEO MATRIX SWITCH Battery Replacement The IRT has a low-battery indicator to let the user know when it is time to change the batteries. The right-hand decimal point in the LCD display will illuminate (see illustration below). This will stay illuminated while the IRT is in use until the batteries are changed or the battery charge is too low for the IRT to operate. -
Page 37: Ddc Support
NTI VEEMUX VIDEO MATRIX SWITCH DDC SUPPORT (Optional) DDC information allows the CPU to automatically select the optimal resolution for the monitor by receiving, at power up, information from the monitor concerning its resolution specifications. When DDC Support is installed, the DDC information is acquired from the monitor by the VEEMUX-A switch when the VEEMUX-A is powered-up. -
Page 38: Rs232 Upgrade Of The Front Panel Lcd Firmware
HyperTerminal has been configured for connection through the correct COM port on the PC. With the HyperTerminal window open, hold the spacebar and apply power to the VEEMUX. A command menu and the Command prompt (>) should appear. Copyright 2006 Network Technologies Inc Flash Loader Utility v1.0 Display this help menu Clear flash Load flash with .hex file... - Page 39 NTI VEEMUX VIDEO MATRIX SWITCH Press <L> to load the firmware (hex) file. This will prepare the file for transfer to the VEEMUX. If the file fails to load, press the <C> key to clear the old firmware, and press <L> to load it again. When the message “Start sending file via Xmodem protocol..”' appears, the VEEMUX is waiting for the Firmware file to be uploaded.
-
Page 40: Rs232 Connection Cables
NTI VEEMUX VIDEO MATRIX SWITCH RS232 CONNECTION CABLES Pinout of RS232 port on VEEMUX The VEEMUX RS232 serial port is a DB-9F (female) connector configured as a DCE (data communication equipment) port. The RS232 port interface signals are listed below, including equivalent CCITT V.24 identification, and signal direction: DB-9F Common CCITT... -
Page 41: Pinout For Matrix Y-1 Cable
NTI VEEMUX VIDEO MATRIX SWITCH Pinout for Matrix Y-1 Cable Wiring Schematic of Matrix-Y-1 cable 9D Male 9D Female 9D Male (Unit #1) (Source) (Unit #2) Not connected to source connector Jumper Jumpers Arrows indicate signal direction. RACK MOUNTING INSTRUCTIONS This NTI switch was designed to be directly mounted to a rack. -
Page 42: Specifications
NTI VEEMUX VIDEO MATRIX SWITCH SPECIFICATIONS General Information DESCRIPTION SPECIFICATION Operating temperature -18°C - 55°C (0°F - 131°F) (17-90% non-condensing RH) Storage temperature -30°C - 60°C (-20°F-140°F) (17-90% non-condensing RH) Power requirements 110 or 220VAC @ 50 or 60Hz Fuse protection 2A 240VAC Fast-blo Video Connectors 15HD female... -
Page 43: Troubleshooting
NTI VEEMUX VIDEO MATRIX SWITCH TROUBLESHOOTING Problem Solution No Video Check power – power ON, power cable connected Check video cabling – make sure cables are secured Check connections – make sure you’re connected to an active input SAFETY STATEMENTS Grounding These products have protective earth ground terminals and are built with full attention to consumer safety.
