- Page 1 NEO SCOOTER Tempo 3 Tempo 4 OWNER’S MANUAL...
-
Page 2: Preface And Introduction
1. PREFACE AND INTRODUCTION …………………………………3 2. SAFETY NOTICE……………………………………………………..4 2.1 Before driving 2.2 While driving 2.3 Labeling 2.4 EMI 3. PARTS INTRODUCTION…………………...………………………10 3.1 Parts description 4. OPERATION………………………………………………………….11 4.1 Control panel 4.2 How to operate your scooter 4.3 How to set to freewheel mode 5. - Page 3 Please carefully read this owner’s manual before using the vehicle. Improper use of the vehicle could result in harm, injury or traffic accidents. Therefore for maximum pleasure whilst using the vehicle please read this owner’s manual. ♦ This owner’s manual includes operation instructions for every aspect of the vehicle, assembly instructions, as well as instructions for how to deal with possible accidents.
-
Page 4: Before Driving
2.1 Before Driving The user needs to be familiar with the usage and operation of this vehicle before driving. Therefore, please follow the recommendations in this safety notice. ■ The same traffic rules apply to the use of this vehicle as apply to pedestrians For your safety, please therefore follow the rules that apply to pedestrians. -
Page 5: While Driving
2.2 While Driving ■ Please carry out daily inspections. Refer to the section entitled “DAILY CHECKING” ■ Do not move your body out of the vehicle whilst moving ♦ Such action may cause you to loose balance and risk injury from falling. ♦... - Page 6 ■ Ramps, inclines and drops ♦ Do not drive onto steep ramps greater than the specified gradient. Refer to the section entitled “CLIMBING ANGLE” in “9. SPECIFICATION“ ♦ Always use a low speed setting when ascending or descending a gradient. ♦...
- Page 7 2.3 Labeling Please carefully read all labels on the scooter before driving it. For your future reference, do not remove them. WARNING DRIVE Emergency freewheel device. Always re-engage the emergency WARNING freewheel device after use. Failure ※ ※ ※ ※ Please hold the tiller before loosening the to do so may result in injury.
- Page 8 2.4 EMI This portion of the content will provide the user with basic information that describes the problems with EMI, known sources of EMI, protective measures either to lessen the possibility or exposure or to minimize the degree of exposure, and suggested action should unexpected or erratic movement occur.
- Page 9 Note: Other types of hand-held devices, such as cordless phones, laptop computers, AM/FM radios, TV sets, CD player, and cassette players, and small appliances, such as electric shavers and hair dryers, so far as we know, are not likely to cause EMI problems to your powered vehicle.
-
Page 10: Parts Description
3.1 Parts Description 1. Speed Dial 2. Charger Socket Cover 3. Basket 4. Tiller 5. Tiller Adjust Lever 6. Head Lamp 7. Seat 8. Seat Rotation Lever 9. Side Reflector 10. Rear Reflector 11. Freewheel Lever 12. Anti-tip Wheel... -
Page 11: Control Panel
4.1 Control Panel 1. Wigwag paddle 2. Indoor/Outdoor Switch * 3. Indicator Switch * 4. Ignition 5. Speed Dial 6. Headlights Button 7. Battery Gauge 8. Power Eye 9. Hazard Warning Button * 10.Horn Button * on 6 and 8 only 4.2 How To Operate Your Scooter Key Ignition ■... - Page 12 4.1 Control Panel 1. Speed Dial 2. Horn Button 3. Head light / Rear Light Button 4. Speed Control Lever 5. Battery Indicator 6. Power Switch (must of key) 4.2 How To Operate Your Scooter ■ ■ ■ ■ Power switch Turn the key to power ON or OFF (ON) : Power is turned on (OFF) : Power is turned off...
-
Page 13: Battery Indicator
■ Battery Indicator Red light Yellow light Green light Green light Full capacity 25% Power remain 75% Power remain Diagnosed signal Voltage at 24.5V↑ Voltage at 22.7~23.6V Voltage at 23.6~24.5V Suggestion 1. You should recharge the batteries after each time the vehicle is used to ensure maximum range. - Page 14 Moving and Braking ■ ■ ■ ■ ♦ Push the right-hand side of the wigwag paddle forwards with your right thumb and the scooter will move forward. ♦ Push the left-hand side of the wigwag paddle forward with your left thumb and the scooter with move backward, emitting an audible reversing alarm.
-
Page 15: How To Set To Freewheel Mode
4.3 How To Set To Freewheel Mode ♦ Engaged Mode ：Lift the freewheel lever up completely, the scooter can be driven by motor power. ♦ Freewheel Mode ：Push the freewheel lever down completely, the scooter can be moved manually. Warning Never operate the freewheel level while seated on the scooter or on an incline. -
Page 16: Manual Brake
■ Manual Brake As well as an electromagnetic brake, squeeze the brake lever to apply the brake and then release the lever to release the brake. The manual brake tightness can be adjusted by the brake cable adjuster near the left hand side wheel. ■... - Page 17 5.1 Stopping 1. Release the wigwag paddle completely. The vehicle will naturally brake and stop. 2. Turn the scooter off at the key ignition. Then pull out the key. Attention ♦ The stopping distance will vary with your forward / reverse speed. Therefore please begin braking as early as you can.
-
Page 18: Charging The Battery
6.1 Charging The Battery Follow the procedure below step by step: 1. Turn the power switch to (OFF) 2. Connect the charger’s power cord into the power outlet. 3.Open the charging socket cap on the control panel. 4.Then connect the charger’s round plug to the charging socket. 5. - Page 19 Suggestion 1. Do not disconnect the charger cord if charging is not completed. The battery life will be seriously shortened or decayed if the battery is repeatedly used without being fully charged. Therefore be sure to charge the battery fully every time. 2.
- Page 20 6.2 Charger Both the chargers red and orange LED will be switched ON during charging. The orange LED will turn green when charging completed. It is recommended to leave the charger plugged in for at least 1-2 hours after the green light has become illuminated. This process may increase on maintain the performance of the batteries.
-
Page 21: Cleaning The Battery
■ Charging the battery ♦ Using the charger supplied with the scooter, the charging is about 8 hours. ♦ However, to ensure optimum performance we recommend a 12-hour charge. ♦ We also recommend that the batteries are not charged for more than 24 hours. ■... -
Page 22: Daily Checking
7.1 Daily Checking Check following items before driving. If your find anything abnormal, contact your Major’s dealer for further inspection or advice before using the scooter. Item Inspection Content ♦ Is there any looseness? Handlebar ♦ Can it turn left and right smoothly? Speed Control Dial ♦... -
Page 23: Regular Checking Record
7.2 Regular Checking Record To make sure your scooter is correctly serviced, take it to your dealer for regular maintenance checks. This should be at intervals of six months after an initial inspection after one month. Your dealer may charge a fee for this. The checking record is shown overleaf. - Page 24 7.3 Battery、 、 、 、 Fuse And Tire ■ Battery Refer to the section entitled “6.3 BATTERY” in “6. BATTERY CHARGING AND CARE ”. ■ Fuse If the battery charger is turned on and no LED are lit, check the battery charger fuse. Suggestion Ask for help from your Major’s...
-
Page 25: Maintenance
7.4 Maintenance ♦ You must maintain the vehicle frequently if you tend to drive on grass, sand, or gravel or in other adverse environments. ♦ Do not use water, oil or other chemical solutions to clean your scooter. Be sure NOT to spray the scooter with a hose or tap as this may cause damage to electronic components and PC circuit board. - Page 26 ♦ The Tempo3/Tempo4 can be disassembled into fire pieces, the seat (weight 6.2 kg),the front section (weight 25kg), the rear section (weight 20kg),and batteries (weight 11 kg ),without any tools please follow the steps and photographs below: 1. Switch off the scooter. 2.
-
Page 27: Assembling The Scooter
7.8 Assembling The Scooter Suggestions The assembly process is essentially the disassembly process in reverse. First study the text and photographs in the disassembly procedure before re-assembling the scooter. Tempo3/Tempo4 1. Position the front and rear sections of 2. Align the lower curved locking brackets of the front section with the corresponding pegs on the front of the rear section. - Page 28 If you have trouble with your scooter you can inspect the following before taking your scooter to the dealer: If you cannot save the problem, contact your dealer for assistance. Problem Symptom Remedy ˙Check batteries are connected ˙Batteries not connected ˙Check connection on front –...
- Page 29 Model Reference Tempo3 Tempo4 Dimension 47.4" x 22.8" x 43.3" 51.2" x 22.8" x 47.3" (L x W x H) 1200mmx580mmx1100mm 1300mmx580mmx1200mm Weight(Kg),W/I battery 87 Kg / 191.4 lbs 91 Kg / 200.2 lbs W/O battery 62 Kg / 136.4 lbs 66 Kg / 145.2 lbs Propulsion motor 8M x 1...
- Page 30 10.1 WARRANTY There is a comprehensive twelve-month warranty from the date on which your new scooter Tempo3/Tempo4 is delivered. The warranty covers the scooter for repairs or replacement during this period. For more detail, please see the Warranty Conditions below. Warranty Conditions: Any work or replacement part installation must be carried out by an authorized Major’s...
- Page 31 10.2 VIN (VEHICLE INDIFICATION NUMBER) To ensure the correct after sales service and warranty service support, please write down the vehicle identification number that is stuck on the back right-hand side of the frame. □Tempo3 □Tempo4 Model Motor serial # Key # Warranty Application Form Name...
- Page 32 PART NO：C37-040-00600...
