OWNER'S MANUAL FOR
DUOSEAL® VACUUM PUMP MODEL:
Never block the Exhaust Port.
with the potential of the pump body bursting and causing
possible injury to personnel in the area.
SAVE THESE INSTRUCTIONS
WARNING
Manufactured in an
ISO 9000
Registered Environment
idealvac.com
Part No. 67-2063
Printed in USA
(505)872-0037
idealvac.com
Advertisement
Table of Contents
Related Manuals for Welch DUOSEAL 1399B-10
Summary of Contents for Welch DUOSEAL 1399B-10
- Page 1 OWNER’S MANUAL FOR DUOSEAL® VACUUM PUMP MODEL: 1399B-10, 1399C-02, 1399N-01 & 1399B-01 Manufactured in an ISO 9000 Registered Environment WARNING Never block the Exhaust Port. If the exhaust port is blocked, pressure will build-up in the pump with the potential of the pump body bursting and causing possible injury to personnel in the area.
-
Page 2: Chart
INSTRUCTION WARNING AND CAUTION PLEASE READ BEFORE OPERATION While reading your manual, please pay close attention to areas labeled: WARNING AND CAUTION. The description of each is found below. WARNING Warnings are given where failure to observe instruction could result in injury or death to people. -
Page 3: Table Of Contents
TABLE OF CONTENTS Section Page Section 01 - Installation 1.10 Introduction Section 02 - Operation 2.10 Starting Procedures 2.20 Operation and System Optimization 2.21 High Pressure Operation 2.22 Gas Ballast Principles and Usage 2.23 System Leaks - Impact and Detection 2.30 Shutdown Procedure Section 03 - Maintenance... -
Page 4: Section 01 - Installation
Where extreme exhaust conditions are encountered it is best to pipe the exhaust direct out of the building. Welch recommended wire reinforced PVC, metal pipe or thick walled rubber hose be used as exhaust lines to avoid potential of line becoming crimped or collapsing resulting in the exhaust port being clocked. - Page 5 1.15 Electrical Power 1.151 Power Source Review Review the power source and the motor rating to be sure they agree in voltage, phase and frequency. On three-phase applications the direction of rotation of the motor must be considered. Make a momentary check rotation at the time of power installation and wiring.
-
Page 6: Section 02 - Operation
Commonly used refrigerants are liquid nitrogen or dry ice and acetone. The refrigerant to be used depends upon the freezing point of the contaminations. A variety of cold traps are available from Welch Vacuum, Thomas Industries, inc. 1.172... -
Page 7: High Pressure Operation
Leaky vacuum systems, too large a vacuum chamber for pump size or high gas loads to the vacuum systems are causes for extended runs of the pump at elevated pressure. If you need additional information, please contact Welch Vacuum at 847-676-8800, extension 1, for further information and precautions. 2.22 Principle of Gas Ballast 2.221... -
Page 8: System Leaks - Impact And Detection
2.226 Other Forms of contamination control The application of the gas ballast is a moderate and very successful method for the removal of condensable vapors. For very heavily laden systems, other means of removal such as oil separators may be required. For mild cases of contamination the simple expedient of a cold trap or a change of oil serve the purpose. -
Page 9: Section 03 - Maintenance
This is why a regular maintenance schedule for the oil is critical to obtain the longest service life out of your DUOSEAL pump. Welch recommends that you examine the condition of the oil on a daily basis in the early days of a new process or experiment. -
Page 10: Oil Changes And Oil Level
3.203 Forced Oil Flushing Procedure 1. Check the oil level, if the oil level is well above the fill mark, (This may indicate either the pump has been overfilled with oil or has ingested a liquid or a large amount of vapor water or organic solvents.) Please go to step 2. -
Page 11: Repairing Oil Leaks
3.40 Repairing Oil Leaks 3.41 Location, Cause and Effect Oil leaks may develop wherever two mating faces are sealed with a gasket. Such seams may fail as the result of deterioration of the gasket material, loosening of the screws caused by temperature variations, or improper care as the result of previous reassembly. -
Page 12: Section 04 - Trouble Shooting Guide
1/2 inch deflection. 4. If pump makes noise: vanes may be sticking, carry out a forced oil flush. 5. If noise level is still unsatisfactory, consult with WELCH Technical Service at (847)676-8800, Ext. 1. 4.30 Excessive Oil Mist 1. - Page 13 Section 5: QUICK REFERENCE CHARTS 1399 Specifications Motor Options Wired for 115V, 60Hz, 1Ph 1399B-01 Free Air Displacement, L/M (CFM) 35 (1.2) Wired for 230V, 60Hz, 1Ph Gas Ballast Wired for 230V, 50Hz, 1Ph 1399C-02 Ultimate Pressure, Torr (mbar) 1 (1.3)x10-4 Wired for 230V, 60Hz, 3Ph Rotational Pump (RPM) Wired for 230V, 50Hz, 3Ph...
- Page 14 Section 6: DIMENSIONAL DRAWING...
-
Page 15: Section 07 - Pumping Speed Curves
Section 7: PUMPING SPEED CURVES HIGH EFFICIENCY PUMPING CHARACTERISTIC OF DUOSEAL® PUMPS The low RPM design of DuoSeal vacuum pumps makes it possible to maintain high pumping efficiencies into the low micron range. High RPM direct drive vacuum pumps, on the other hand, experience a rapid fall off of pumping speed below 100 microns. - Page 16 Section 8: EXPLODED VIEW...
-
Page 17: Parts List
PARTS LIST ITEM DESCRIPTION ITEM DESCRIPTION 2-00-0716 SCREW HEX HD 10-32 x 1” LG. 41-1239 EXHAUST VALVE 2-00-2706 SCREW PAN HD 10-32 x 3/8” LG. 41-1285 STEEL WASHER FOR SHAFT COLLAR 2-00-6712 SCREW SOCKET HD 10-32 x 3/4” LG. 41-1304 VANE SPRING 2-01-0332 SCREW HEX HD 5/16-18 x 2”... -
Page 18: Oil Case
VIEW AND PARTS LIST FOR PART NUMBER 41-2378 Parts List for Model 41-2378 Item Description Qty. 2-01-0308 Screw Hex Hd 5/46-18x1/2” 41-1049 Pump Leg 41-2088 Oil Case, Machined 41-3753 Oil Case Window 61-2278 Drain Valve... -
Page 19: Section 09 - Accessory Section
Section 9: ACCESSORY SECTION Exhaust Filter Filters to 0.3 micron Filters oil mist from Easy Replacement Reduces pump noise particle size pump exhaus Standard Exhaust Filter Dimension Catalog Number Diameter Height Filter Replacement Use with pump model Element 1392, 1399, 1400 1417 1417L 1376,1380, 1402,1400... - Page 20 Coaxial Traps Reduces oil back streaming Stainless steel construction Easy Replacement of Element ISO Size Capacity Diameter Height Cat.No.1 NW16 to 4 CFM (140 L/min) 3.75 8.25 541001 5.25 Stainless Steel Element for ISO NW 16 Trap 1 541921 Stainless Steel Element for ISO NW 25 and NW 40 Traps1 541922 Cat.
- Page 21 Welch. This document is to be returned to Welch upon request and in all events upon completion of the purpose for which it is loaned.
