- Page 1 DISHWASHER OWNER'S MANUAL MODEL : LD-9230(1)W(S,M)H LD-9230(1)W(S,M)HB LD-9240(1)W(S,M)H LD-9240(1)W(S,M)HB LD-9250(1)W(M)HB Please read this manual carefully before operating your dishwasher. Retain it for future reference.
-
Page 2: Table Of Contents
CONTENTS SAFETY AND CAUTION INSTALLATION INSTRUCTIONS PARTS NAME FUNCTION OF CONTROL BUTTON HOW TO USE AND OPERATE OPERATING SEQUENCE PROGRAM USER MAINTENANCE INSTRUCTIONS TROUBLE SHOOTING GUIDE SPECIFICATION... -
Page 3: Safety And Caution
SAFETY AND CAUTION IMPORTANT SAFETY INSTRUCTIONS WARNING - When using your dishwasher, follow basic precautions, including the following: • Please read this manual carefully before using the enclosure panels are properly in place. open the dishwasher for the first time. door very carefully if the dishwasher is operating, •... - Page 4 SAFETY AND CAUTION CAUTION concerning the Power Cord • Most appliances recommend they be placed upon a dedicated circuit; that is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner's manual to be certain.
-
Page 5: Prepare Cupboard Opening
INSTALLING INSTRUCTIONS Step 2 : WARNING PREPARATION FOR ELECTICAL WIRING A qualified electrician/plumber or competent person should carry out any CAUTION electrical/plumbing work required to install this appliance. For personal safety, remove house fuse or open circuit breaker before installation. Do not use an extension cord or adapter Step 1 : plug with this appliance. -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Step 3 : Step 4 : PREPARING THE DISHWASHER INSTALLING THE DISHWASHER FOR INSTALLATION IN CUPBOARD Lay the dishwasher on its back. Before sliding the dishwasher into the cupboard opening, all necessary height and Adjust the legs to the required height balancing adjustments should be made as shown in below figure. -
Page 7: Drain Line Connection
INSTALLATION INSTRUCTIONS Step 5 : DRAIN LINE CONNECTION If the end of drain hose does not fit to ■ When the drain hose is connected to a the drain line, use a rubber separate standpipe, it is essential that an connector(not supplied) that is airtight connection be made. -
Page 8: How To Level The Dishwasher
INSTALLATION INSTRUCTIONS Step 8 : Step 6 : HOW TO LEVEL THE DISHWASHER WATER SUPPLY CONNECTION Connect the water supply hose to the After installing the dishwasher, you may notice water tap as shown.(Some models consist a slight sticking of the door to the dishwasher, of an inlet valve and hose.) when you open or close the door. -
Page 9: Parts Name
PARTS NAME 1. Control Panel 11. Upper Rack 2. Front Cover 12. Cutlery Basket 13. Detergent And Rinse 3. Process Monitor 4. Power Switch Aid Dispenser 5. Drain Hose 14. Upper Spray Arm 6. Inlet Hose 15. Lower Spray Arm 7. -
Page 10: Function Of Control Button
FUNCTION OF CONTROL BUTTON LD-923~ / 924~ Series LD-923~ Series LD-924~ Series... -
Page 11: Delay Start
INDICATOR TIME LEFT DELAY START • Before starting, the display window shows the running time of • Refill with • If you want to delay the the selected program. special salt start of selected program, • After starting, the display window shows the remaining time. press this button before •... -
Page 12: Child Lock
FUNCTION OF CONTROL BUTTON LD-925~ Series PROGRAM CHILD LOCK BEEP ON/OFF • When you want to • Used to lock or unlock the • The dishwasher must be select program, press control buttons to prevent switched on. each button. all the setting from being •... - Page 13 INDICATOR TIME LEFT DELAY START • Before starting, the display window shows the running time of • Refill with • If you want to delay the special salt the selected program. start of selected program, • After starting, the display window shows the remaining time. press this button before •...
-
Page 14: How To Use And Operate
HOW TO USE AND OPERATE 1. Loading your Dishwasher Take care not to obstruct the rotation of the spray arms and ensure that large For better washing performance, always load items do not prevent the detergent the dishwasher according to the instructions. dispenser lid from opening. -
Page 15: Loading The Upper Rack
HOW TO USE AND OPERATE 4. Loading the Upper Rack 5. Adjusting the Upper Rack (Not on all models) It is best to load this with more delicate Your upper rack can be raised or lowered to items such as, small plates, long cutlery, cater for different size of crockery. -
Page 16: Adding Detergent
HOW TO USE AND OPERATE 6. Adding Detergent Push latch to open Dispenser • Detergent must be put into the detergent chamber before starting every program except the Pre-Wash. • Please follow the manufacturer’s instructions Place proper within the manual, when determining the detergent into this correct amount of detergent to use. -
Page 17: Adding Rinse Aid
HOW TO USE AND OPERATE 7. Adding Rinse Aid Dispenser � For filling To fill the Rinse Aid chamber, rotate the round cap counter clockwise and remove. Fill the container to the maximum level with a good quality Rinse Aid, then replace and lock the cap. -
Page 18: Salt Filling
HOW TO USE AND OPERATE 8. Salt Filling This model has a water softener to soften hard water. Please read these notes carefully for correct operation. In order to provide satisfactory rinsing results, the dishwasher requires soft water, i.e.,containing little or no lime, otherwise water stains will be left behind on the dishes and interior containers. - Page 19 HOW TO USE AND OPERATE ■ For refilling When the salt container is empty, the salt refill lamp will automatically turn on during operation. The salt should be refilled after the cycle has finished. We recommended the salt refill should always be carried out, as mentioned previous page, prior to starting the next operation.
-
Page 20: Operating Sequence
OPERATING SEQUENCE Press the “Power” button Before starting, the display window shows the running time of the selected program. After starting, the display window shows Check there is rinse aid the remaining time. and salt The time in the display window will start to decrease minute by minute. -
Page 21: Program
PROGRAM ▶Running time may vary according to the water temperature, water pressure and voltage. WASH RINSE Program Heating Pre Wash Main Wash Rinse 1 Rinse 2 Rinse 50℃ ℃ 70℃ ℃ 70℃ ℃ Intensive 45℃ ℃ 65℃ ℃ 70℃ ℃ Normal 45℃... -
Page 22: User Maintenance Instructions
USER MAINTENANCE INSTRUCTIONS To prevent trouble and poor operating, it is important to check filters and spray arms at regular intervals. Filters Lower Spray Arm • Remove the lower rack first. • Check that the water jet holes are not •... -
Page 23: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE I If a problem occurs check below to see whether this can be solved. I In the unlikely event that the problem cannot be rectified, please contact a service engineer. Problem Possible Causes No lights come on when the •... - Page 24 LD-9230(1)W(S,M)H LD-9250(1)W(M)HB LD-9240(1)W(S,M)H 450mm 450mm 580mm 530mm 850mm 817mm LD-9230(1)W(S,M)HB LD-9240(1)W(S,M)HB 450mm 550mm Capacity 9 Place settings 817mm Weight See rating label Power Supply See rating label Power Consumption See rating label Water Feed Pressure 50 ~ 800 kPa P/No.: 672060102002...
