Satellite USA WBS41202NF Specification Sheet

12 Way Multiswitch for a 5 LNB DirecTV ® system
5 SAT-IF signals 16 receivers
Features
SAT-IF
- For use with DirecTV's new 5 LNB satellite dish only!
- Will distribute up to 12 independent satellite receivers.
- Outdoor mountable!
- Multiswitch will also work on DirecTV's older style satellite dishes and satellite receivers.
- Remote powerable via power port

Specifications

@ 19V
Input Vertical
POWER SUPPLY
Input Horizontal
Max Remote Current
@ 250MHz
THROUGH LOSS
@ 2200 MHz
NOISE FIGURE
ISOLATION of taps
MAX OUTPUT
LEVELS
5 dB
Gain of 5 dB
typically 7 dB
> 30 dB
250 ... 2200 MHz
Frequency ranges
- SAT-IF
Product Dimensions
Product Weight
320 mA
14 V
18 V
300 mA
-13.75 dBm 35 dBmV
250 ... 2200 MHz
5.19" (w) x 7.28" (h) x 1.41" (d)
3.00 lbs
