OPERATOR'S MANUAL
Vac Attack II Blower / Vacuum
UT08932, UT08934 and UT08934B
Your new blower has been engineered and manufactured to Homelite's high standard for dependability, ease of operation, and
operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
using this product.
Thank you for buying a Homelite blower.
SAVE THIS MANUAL FOR FUTURE REFERENCE
To reduce the risk of injury, the user must read and understand the operator's manual before
Advertisement
Table of Contents
Related Manuals for Homelite VAC ATTACK II UT08932
Summary of Contents for Homelite VAC ATTACK II UT08932
- Page 1 Vac Attack II Blower / Vacuum UT08932, UT08934 and UT08934B Your new blower has been engineered and manufactured to Homelite’s high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
-
Page 2: Table Of Contents
TABLE OF CONTENTS ■ ■ ■ ■ ■ Introduction ... 2 ■ ■ ■ ■ ■ General Safety Rules ... 3 ■ ■ ■ ■ ■ Specific Safety Rules ... 4 ■ ■ ■ ■ ■ Symbols ... 5 - 6 ■... -
Page 3: General Safety Rules
■ ■ ■ ■ ■ Never attempt to burn off spilled fuel under any circum- stances. ■ ■ ■ ■ ■ Use only Homelite replacement parts and accessories. Failure to do so may cause poor performance, possible injury. -
Page 4: Specific Safety Rules
■ ■ ■ ■ ■ Do not operate vacuum without vacuum bag installed; flying debris could cause serious injury. Always close vacuum bag completely before operating. ■ ■ ■ ■ ■ Always hold the blower in your right hand, refer to the “Op- eration Instructions,”... -
Page 5: Symbols
Some of the following symbols may be used on this tool. Please study them and learn their meaning for safe operation of this product. SYMBOL NAME Safety Alert Symbol Read the Operator’s Manual Wear Eye and Hearing Protection Vacuum Door Blower Tubes Long Hair Loose Clothing... - Page 6 The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
-
Page 7: Specifications
SPECIFICATIONS Weight ... 10.4 lbs. (4.7 kg.) Engine displacement ... 30cc Air Velocity: MPH ... 200 CFM ... 420 Before using this blower, familiarize yourself with all operat- ing features and safety requirements. However, do not let familiarity with the blower make you careless. This new blower is equipped with the following features. -
Page 8: Features
TUBE CLAMP VACUUM BAG SHOULDER STRAP VACUUM BAG ADAPTOR VACUUM BAG STARTER GRIP INSTRUCTIONS When unpacking the blower: ■ Carefully remove the blower and accessories from the box. ■ Make sure that all items listed in the packing list are in- cluded. -
Page 9: Assembly
WARNING: Stop the engine and disconnect the spark plug wire before installing parts, making adjustments, cleaning, or when not in use. Failure to do so could result in possible serious personal injury. ASSEMBLING THE BLOWER TUBES See Figure 2. 1. Screw the nozzle onto the upper blower tube and tighten securely. -
Page 10: Installing The Vacuum Tubes
WARNING: Stop the engine and disconnect the spark plug wire before installing parts, making adjustments, cleaning, or when not in use. Failure to do so could result in possible serious personal injury. INSTALLING THE VACUUM TUBES See Figures 5 and 6. To install the vacuum tubes: 1. -
Page 11: Mixing The Fuel
WARNING: Gasoline is extremely flammable and explosive. A fire or explosion from gasoline will burn you and others. MIXING THE FUEL This product is powered by a 2-cycle engine and requires pre-mixing gasoline and 2-cycle oil. The mixture should be at a 50:1 ratio, using Premium Exact Mix™... -
Page 12: Starting And Stopping
STARTING AND STOPPING See Figure 7. Starting the product differs depending on whether the engine is cold or warm. Refer to the label on the air filter base for choke positions A, B, and C. TO START A COLD ENGINE: 1. -
Page 13: Vacuum Operation
■ Operate blower at the lowest possible throttle speed to do the job. ■ Check your equipment before operation, especially the muffler, air intakes and air filters. ■ Use rakes and brooms to loosen debris before blowing. ■ In dusty conditions, slightly dampen surfaces when water is available. -
Page 14: Replacing And Cleaning The Air Fil- Ter
■ ■ ■ ■ ■ Hold the engine higher than the inlet end of the vacuum tube. ■ ■ ■ ■ ■ Always point vacuum tube downhill when working on a hillside. ■ ■ ■ ■ ■ To avoid injury to the operator or unit, do not pick up rocks, broken glass, bottles, or other similar objects. - Page 15 SPARK ARRESTOR The muffler is equipped with a spark arrestor screen inside muffler body. After extended use the screen can become dirty and may need to have the muffler replaced by an authorized servicing dealer. WARNING: To avoid a fire hazard, never run the blower without the spark arrestor in place.
-
Page 16: Troubleshooting
IF THESE SOLUTIONS DO NOT SOLVE THE PROBLEM CONTACT YOUR AUTHORIZED SERVICING DEALER. PROBLEM POSSIBLE CAUSE Engine will not start: Engine starts but will not accel- erate: Engine starts but will only run at high speed at half choke: Engine does not reach full speed and emits excessive smoke: Engine starts, runs, and accel-... -
Page 17: Limited Warranty Statement
■ ■ ■ ■ ■ One year for the following units: UT08110, UT20760, UT10901; ■ ■ ■ ■ ■ Two years for all other Homelite products, if the product is used for personal, family or household use; ■ ■ ■ ■ ■ 90 days, if any of the above products are used for product used for any other purpose, such as commercial or rental. - Page 18 U.S. EPA standards for the first two years of engine use from the date of sale to the ultimate purchaser. Homelite Consumer Products, Inc. must warrant the emission control system on your nonroad or small off-road engine for the period of time listed above provided there has been no abuse, neglect, or improper maintenance of your nonroad or small off-road engine.
-
Page 19: Warranty
FIRST SCHEDULED REPLACEMENT, WHICH EVER COMES FIRST. The following recommended accessories are currently available. ACCESSORIES Gutter Attachment Kit ... Homelite - A07069AA Air Filter ... Power Care - AP04107 Spark Plug ... Champion - RCJ-6Y 2-Cycle Oil ... Homelite / AH99G01... -
Page 20: Parts Ordering / Service
CALIFORNIA PROPOSITION 65 SERVICE For parts or service, contact your nearest Homelite authorized service dealer. Be sure to provide all relevant information when you call or visit. For the location of the authorized service dealer nearest you, please call 1-800-242 4672 or visit us online at www.homelite.com.
