Page 1: User Manual
User Manual GL-VP-6222 и GL-VP-6244 Analog IP Gateway 2FXS&2FXO Ports OR 4FXS&4FXO Ports http://www.giga-link.ru... -
Page 2: Table Of Contents
GL-VP-62XX FEATURES .................... 6 Software Features Overview ................. 6 Hardware specification ................... 8 CALL FEATURES ......................8 BASIC OPERATIONS ....................9 Understanding GL-VP-xxxx Voice Prompts ........... 9 Placing A Phone Call ..................11 5.2.1 Phone or Extension Numbers............... 11 5.2.2 Direct IP Calls .................. -
Page 3: Welcome
VoIP network, and efficiently manage communication costs. This manual will help you learn how to operate and manage your GL-VP-xxxx FXS Analog IP Gateway and make the best use of its many upgraded features including simple and... -
Page 4: Warranty
2. Insert the Ethernet cable into the WAN port of GL-VP-62XX and connect the other end of the Ethernet cable to an uplink port (a router or a modem, etc.) 3. Connect a PC to the LAN port of GL-VP-62XX for initial configuration or if it is being used as a router. -
Page 5: Gl-Vp-62Xx Display Panel
FXO ports to be connected to physical PSTN lines from FXO1 – FXO4 a traditional PSTN PBX or PSTN Central Office. Once the GL-VP-xxxx is turned on and configured, the front display panel indicates the status of the unit. 2.4 GL-VP-62XX Display Panel... -
Page 6: Gl-Vp-62Xx Features
LEDs POWER, and WAN are ON and READY blinking when device is up and running. 3 GL-VP-62XX FEATURES The GL-VP-62XX is a next generation IP voice gateway that is interoperable and compatible with leading IP-PBXs, SoftSwitches and SIP platforms. The GL-VP-62XX series is auto-configurable, remotely manageable and scalable. There are two models, the GL-VP-62XX, each offering superb voice quality, traditional telephony functionality, easy deployment, and 2 or 4 FXS&FXO ports respectively. - Page 7 GL-VP-62xx User Manual GL-VP-62XX FXS Analog Gateway Series GL-VP-xxxx 6104: 4 ports, 4 SIP accounts & choice of 2 profiles Telephone Interfaces GL-VP-xxxx 6108: 8 ports, 8 SIP accounts & choice of 2 profiles FXS/FXO, RJ-11 Network Interface Two (2) 10M/100 Mbps, RJ-45...
-
Page 8: Hardware Specification
10% - 90% (non-condensing) Compliance FCC, CE 4 CALL FEATURES The GL-VP-62XX supports the traditional telephony features available in a PBX as well as additional advanced telephony features. TABLE 6: Call Features Table (Star Code) Call Features Block CallerID (for all-config change) -
Page 9: Basic Operations
Pressing pound sign will serve as Re-Dial key. 5 BASIC OPERATIONS Understanding GL-VP-xxxx Voice Prompts GL-VP-62XX has a stored voice prompt menu for quick browsing and simple configuration. To enter the voice prompt menu, press *** on the standard analog phone connected to any FXS port. - Page 10 GL-VP-62xx User Manual TABLE 5: Definitions Of The GL-VP-xxxx Voice Prompts Menu Voice Will Say the Following: “Enter a Menu Option” Enter “*” for the next menu option Main Enter “#” to return to the main menu Menu Enter 01 – 05, 07,10 - 17, 47, 86 or 99 Menu option “DHCP Mode”, “PPPoE...
-
Page 11: Placing A Phone Call
GL-VP-62xx User Manual HTTP Firmware Version Firmware version information. Firmware upgrade mode. Enter “9” to Firmware Upgrade rotate among the following three options: always check check when pre/suffix changes never upgrade “Direct IP Calling” Enter the target IP address to make a direct IP call, after dial tone. -
Page 12: Direct Ip Calls
Elements necessary to completing a Direct IP Call: 1. Both GL-VP-xxxx and other VoIP Device, have public IP addresses, or 2. Both GL-VP-xxxx and other VoIP Device are on the same LAN using private IP addresses, or 3. Both GL-VP-xxxx and other VoIP Device can be connected through a router using public or private IP addresses (with necessary port forwarding or DMZ). -
Page 13: Call Waiting
GL-VP-62xx User Manual Call Waiting Call waiting tone (3 short beeps) indicates an incoming call, if the call waiting feature is enabled. Toggle between incoming call and current call by pressing the “flash” button. First call is placed on hold. Press the “flash” button to toggle between two active calls. -
Page 14: 3-Way Conferencing
The GL-VP-62XX supports Bellcore style 3-way Conference. Instructions for 3-way conference: Assuming that call party A and B are in conversation. A (GL-VP-62XX) wants to bring C in a conference: 1. A presses FLASH (on the analog phone, or Hook Flash for old model phones) to get a dial tone. -
Page 15: Configuration Guide
2. Connect an Ethernet cable between the WAN port on GL-VP-62XX to your PC. 3. You will have to assign a dummy IP with the same subnet as the GL-VP-xxxx IP Address, which is 192.168.0.160 by default. So, set an IP address like 192.168.0.x for your PC. - Page 16 Meaning By default, HTTP uses port 80. Web Port This field is for customizable web port. There are two modes to operate the GL-VP-62XX: IP Address DHCP mode: all the field values for the Static IP mode are not used (even though they are still saved in the Flash memory.) The GL-VP-62XX acquires its IP...
- Page 17 The time IP address is assigned to the LAN clients. Forward all WAN IP traffic to a specific IP address if DMZ IP no matching port is used by GL-VP-62XX or defined in port forwarding. Copyright © 2009-2011 GigaLink Page 17 of 46...
- Page 18 WAN side http access update via WAN port is disabled. You may also access the Device Status page which provides details of the GL-VP-xxxx product. The Device Status page terms are defined in Table 6: Status Page Definitions. TABLE 6: Status Page Definitions Copyright ©...
-
Page 19: Super User Settings
PPPoE Link Up Shows whether the PPPoE connection is running if connected to DSL modem. Shows type of NAT the GL-VP-62XX is connected to via its WAN port. It is based on STUN protocol. Shows several information regarding the individual FXO Port Status ports. - Page 20 Default setting is blank. STUN server is: IP address or domain name of stun server This parameter specifies how often the GL-VP-62XX sends a blank UDP packet to the SIP server to keep the “hole” on the keep-alive interval NAT open.
- Page 21 Meaning This parameter defines the URI or IP address of the NTP NTP Server server which is used by the GL-VP-62XX to display the current date/time. If this parameter is set to “Yes”, the configuration update via Lock Keypad Update keypad is disabled.
-
Page 22: Configuring The Fxs Channels
GL-VP-62xx User Manual SUPER CONFIGURATION PAGE DEFINITIONS Setting Options Meaning Using these settings, user can configure tone frequencies according to their preference. By default they are set to North American frequencies .Frequencies should be configured with known values to avoid uncomfortable high pitch sounds. -
Page 23: Fxs Profile
Authenticate ID authentication. Can be identical to or different from SIP User ID. SIP service subscriber‟s account password for Password GL-VP-62XX to register to (SIP) servers of ITSP. Name Name Profile ID Select the corresponding Profile ID (1/2) Hunting Group 6.5 FXS Profile... - Page 24 IP address or Domain name of Outbound Proxy, or Media Outbound Proxy Gateway, or Session Border Controller. Used by GL-VP-62XX for firewall or NAT penetration in different network environments. If symmetric NAT is detected, STUN will not work and ONLY outbound proxy can correct the problem.
- Page 25 (if allowed by ITSP) but is without Registration unable to receive incoming calls. Defines the local SIP port the GL-VP-62XX will listen and Local SIP port transmit. The default value for Profile 1 is 5060 and 6060 for Profile...
- Page 26 GL-VP-62xx User Manual header information. PROFILE PAGE DEFINITIONS Setting Options Meaning DTMF Payload Type Sets the payload type for DTMF using RFC2833. DTMF in-audio Send DTMF as inband (in-audio). Default “YES”. DTMF via RFC2833 DTMF via SIP INFO Send DTMF via SIP INFO message.
- Page 27 No Key Entry Timeout Default is 4 seconds. Preferred Vocoder The GL-VP-62XX supports up to 5 different Vocoder types including G.711 A-/U-law, G.726 (Supports bit rates 16, 24, 32 and 40), G.723.1, G.729A/B/E and iLBC. The user can configure Vocoders in a preference list that will be included with the same preference order in SDP message.
- Page 28 SDP message of an INVITE request will be 20ms. If the configured voice frames per TX exceeds the maximum allowed value, the GL-VP-62XX will use and save the maximum allowed value for the corresponding first vocoder choice. The maximum value for PCM is 10(x10ms) frames;...
- Page 29 GL-VP-62xx User Manual Default is Callee. This decides whether Caller or Callee Fax Tone sends out the re-INVITE for T.38 or Fax Pass Through. Detection Mode Jitter Buffer Type Select either Fixed or Adaptive based on network conditions. Jitter Buffer Length Select Low, Medium or High based on network conditions.
- Page 30 GL-VP-62xx User Manual Early Dial Default is No. Use only if proxy supports 484 response. This parameter controls whether the phone will send an early INVITE each time a key is pressed when a user dials a number. If set to “Yes”, an INVITE is sent using the dial-number collected thus far;...
- Page 31 GL-VP-62xx User Manual { ^1900x. | <=1617>[2-9]xxxxxx | 1[2-9]xx[2-9]xxxxxx | 011[2-9]x. | [3469]11 } Explanation of example rule (reading from left to right): ^1900x. - prevents dialing any number started with 1900 <=1617>[2-9]xxxxxx - allows dialing to local area code...
- Page 32 GL-VP-62xx User Manual Copyright © 2009-2011 GigaLink Page 32 of 46...
-
Page 33: Configuring The Fxo Channels
Configuring The FXO Channels Configuring the FXO channels on the GL-VP-62XX is an easy process. Follow the GUI interfaces. The Device Status page terms are defined in Table 8: FXO Lines Configuration Definitions. An example of the Channel Dialing Configuration is shown in Figure 6. - Page 34 Authenticate ID authentication. Can be identical to or different from SIP User ID. SIP service subscriber‟s account password for Password GL-VP-62XX to register to (SIP) servers of ITSP. Name Name Profile ID Select the corresponding Profile ID (1/2) Enable PSTN...
-
Page 35: Fxo Profiles
Profiles are basically IP PBX / SIP Server configuration templates. If you have more than one IP PBX system or SIP Server that you would like to use with the GL-VP-62XX, then you can configure Profile 2 or 3. Note – Make sure you select the correct profile for each channel under Channels WEBPAGE. - Page 36 VoIP service provider. IP address or Domain name of Outbound Proxy, or Media Gateway, or Session Border Controller. Used by GL-VP-62XX for firewall or NAT penetration in different Outbound Proxy network environments. If symmetric NAT is detected, STUN will not work and ONLY outbound proxy can correct the problem.
- Page 37 (if allowed by ITSP) but is Registration unable to receive incoming calls. Defines the local SIP port the GL-VP-62XX will listen and transmit. Local SIP port The default value for Profile 1 is 5060 and 6060 for Profile Defines the local RTP-RTCP port pair the PROFILE will listen and transmit.
- Page 38 SIP Extension to notify SIP server that the unit is behind Proxy-Require the NAT/Firewall. NAT IP address used in SIP/SDP message. Use NAT IP Default is blank. Preferred Vocoder The GL-VP-62XX supports up to 5 different Vocoder types Copyright © 2009-2011 GigaLink Page 38 of 46...
- Page 39 SDP message of an INVITE request will be 20ms. If the configured voice frames per TX exceeds the maximum allowed value, the GL-VP-62XX will use and save the maximum allowed value for the corresponding first vocoder choice. The maximum value for PCM is 10(x10ms) frames;...
- Page 40 GL-VP-62xx User Manual PROFILE PAGE DEFINITIONS Setting Options Meaning G729E Payload Default value is 102. Range is from 96 to 127. Type: Default is No. VAD allows detecting the absence of audio and conserve bandwidth by preventing the transmission of "silent packets"...
- Page 41 GL-VP-62xx User Manual If set to “Yes”, an INVITE is sent using the dial-number collected thus far; Otherwise, no INVITE is sent until the “(Re-)Dial” button is pressed or after about 5 seconds have elapsed if the user forgets to press the “Re-Dial”...
- Page 42 GL-VP-62xx User Manual PROFILE PAGE DEFINITIONS Setting Options Meaning Caller Request Default is NO Timer Callee Request Default is NO Timer Force Timer Default is NO Specify Default is Omit Refresher Specify Default is UAC Refresher Force INVITE Default is NO Default is Standard.
-
Page 43: Saving The Configuration Changes
Once a change is made, press the “Update” button in the Configuration Menu. The GL-VP-62XX will display the following screen to confirm that the changes have been saved. To activate changes, reboot or power cycle the GL-VP-62XX after all changes are made. -
Page 44: Rebooting From Remote
To configure the TFTP server via the Web configuration interface, open up your browser to point at the IP address of the GL-VP-62XX. Input the admin password to enter the configuration screen. From there, enter the TFTP server address in the designated field towards the bottom of the configuration screen. -
Page 45: Restore Factory Default Settings
1. Factory Reset will be disabled if the “Lock keypad update” is set to “Yes”. 2. Please be aware by default the GL-VP-62XX WAN side HTTP access is disabled. After a factory reset, the device‟s web configuration page can be accessed only from its LAN port. -
Page 46: Technical Support Contact
GL-VP-62xx User Manual 9 TECHNICAL SUPPORT CONTACT Email: info@giga-link.ru Copyright © 2009-2011 GigaLink Page 46 of 46...
