MICROWAVE OVEN
SERVICE MANUAL
MODEL: MS2548GR
MS2548XR
CAUTION
BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
February, 2009
P/NO : MFL31039014
Printed in Korea
Table of
Contents
Previous
Page
Next
Page
1
2
3
4
5
Advertisement
Table of Contents
Related Manuals for LG MS2548GR
Microwave Oven LG MS2548GR Owner's Manual & Cooking Manual
Microwave oven (24 pages)
Microwave Oven LG MS2549DRK Owner's Manual
Microwave functionality, capacity:25l, edge round cavity,mw output power:850w (34 pages)
Microwave Oven LG MS-2344B Service Manual
Microwave oven (34 pages)
Microwave Oven LG MS3042G Owner's Manual
(24 pages)
Microwave Oven LG MS2548AR Owner's Manual
(31 pages)
Microwave Oven LG MS2540SR Owner's Manual
(27 pages)
Microwave Oven LG MS254 Series Owner's Manual
(24 pages)
Microwave Oven LG MS2589DRS Owner's Manual
(35 pages)
Microwave Oven LG MS259 Series Owner's Manual
(24 pages)
Microwave Oven LG MS259 Series Owner's Manual
(60 pages)
Microwave Oven LG MS253 SERIES Owner's Manual
(28 pages)
Microwave Oven LG MS423 Series Owner's Manual
(32 pages)
Microwave Oven LG MS253 Series Owner's Manual
(29 pages)
Microwave Oven LG MS-255T Service Manual
(28 pages)
Microwave Oven LG MS-256NB Service Manual
(35 pages)
Microwave Oven LG MS-1905C Instruction Manual
(19 pages)
Summary of Contents for LG MS2548GR
Page 1: Microwave Oven
Internal Use Only Website http://biz.lgservice.com MICROWAVE OVEN SERVICE MANUAL MODEL: MS2548GR MS2548XR CAUTION BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. February, 2009 P/NO : MFL31039014 Printed in Korea...
Page 2: Safety Precautions
CAUTION MICROWAVE RADIATION DO NOT BECOME EXPOSED TO RADIATION FROM THE MICROWAVE GENERATOR OR OTHER PARTS CONDUCTING MICROWAVE ENERGY. Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 3: Table Of Contents
REPLACEMENT PARTS LIST - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-1 LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 4: Specifications
Accessories Glass tray Rotating ring This microwave oven is designed for household use only. It is not recommended for commercial purposes. Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 5: Cautions
• NEVER put iron tools on the magnetron. BY PROPERLY QUALIFIED SERVICE • NEVER put anything into the latch hole and the PERSONNEL. interlock switches area. LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 6: Installations
The wire which is colored brown must be connected to the terminal in the plug which is marked with the letter L or colored red. Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 7: Operating Instructions
11. STOP/CLEAR: Used to stop over and clear all entries except time of day. 12. START/Q-START: One tap allows over to begin functioning. LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 8: Operating Sequence
5. AUTO DEFROST Auto Weight Stop/Clear Start Defrost (kg) 7. ONE TOUCH AUTO MENU ONE TOUCH Weight Stop/Clear Start AUTO MENU (kg) Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 9: Schematic Diagram
SCHEMATIC DIAGRAM LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 10: Circuit Description
EXCEPT MAXIMUM. • The micom controller controls the ON-OFF time of relay 2 by the applied signal to vary the average output Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 11: Service Information
4 mW/cm . Always start measuring of an unknown field to assure safety for operating personnel from radiation leakage. LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 12
5 mW/cm.sq. Leakage for a fully assembled oven (Before the latch switch (primary) is interrupted) with the door in a slightly opened position-less than 2 mW/cm.sq. Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 13: Measurement Of Microwave Power Output
2) Disconnect two terminals, and remove one screw of the earth terminal. CAUTION: DISCHARGE THE HIGH VOLTAGE CAPACITOR BEFORE SERVICING (refer to page 2-1) LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 14: Diode Removal
4) Remove the screw holding the high voltage capacitor bracket. Fan Motor ASS Y Suction Guide Remove Door Assembly Capacitor Transformer H.V. Diode Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 15
Magnetron Waveguide Taptite Screw Dome Waveguide Bracket Wire Leads Magnetron Gasket Magnetron Turntable Motor LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 16
FIG. 1 CAUTION: CHECK THE CORRECT POSITION MAGNETRON H.V. TRANSFORMER H.V. DIODE H.V. CAPACITOR PRIMARY CIRCUIT PROTECTOR Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 17: Interlock Continuity Test
Primary Switch Monitor Switch Secondary Switch NOTE : After checking for the continuity of switches, make sure that are connected correctly. LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 18: Component Test Procedure
Normal: Less than 1 Ω (Ohm-meter scale: Rx1) • Filament terminal 2. Measure the resistance. Normal: ∞ (Ohm-meter scale: Rx1000) • Filament to chassis Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 19
Some inexpensive meters may indicate infinite resistance in both direction. Normal: ∞ Measure the continuity (Reverse). Abnormal: Continuity. (Ohm-meter scale: Rx10000) LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 20
• MAKE SURE THE WIRE LEADS ARE IN THE CORRECT POSITION. • WHEN REMOVING THE WIRE LEADS FROM THE PARTS, BE SURE TO GRASP THE CONNECTOR, NOT THE WIRES. Copyright © 2007 LG Electronics. Inc. All right reserved. 5-10 LGE Internal Use Only...
Page 21: Trouble Shooting
Turntable drags or makes Distribute food evenly. Cook IExcessive weight on tray or noise. smaller portions and,or use improperly balanced. lighter weight cookware. LGE Internal Use Only 5-11 Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 22
4. Random programming when touching other pads. 5. Display is fixed at some figure and can not accept any input. Copyright © 2007 LG Electronics. Inc. All right reserved. 5-12 LGE Internal Use Only Only for training and service purposes...
Page 23
Continuity. Check continuity No continuity. Defective power Replace power of power supply supply cord. supply cord. cord. LGE Internal Use Only 5-13 Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 24
Abnormal. output. magnetron. magnetron. NOTE: Simple test of power output-conducted by heating one liter water for one min. if available. Copyright © 2007 LG Electronics. Inc. All right reserved. 5-14 LGE Internal Use Only Only for training and service purposes...
Page 25
Check high vol- Defective high Replace high Abnormal tage diode. voltage diode. voltage diode. Normal Check Defective Replace Abnormal magnetron. magnetron. magnetron. LGE Internal Use Only 5-15 Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 26
• When Removing the wire leads from the parts, be sure to grasp the connector, not the wires. • When removing the magnetron, be sure to install the magnetron gasket in the correct position and in good condition. Copyright © 2007 LG Electronics. Inc. All right reserved. 5-16 LGE Internal Use Only...
Page 27: Exploded View
#EV# EXPLODED VIEW INTRODUCTION MODEL: OVEN CAVITY PARTS INTERIOR PARTS BASE PLATE PARTS DOOR PARTS LATCH BOARD PARTS CONTROL PANEL PARTS -6-1-...
Page 28
#EV# DOOR PARTS (II) MODEL: 13581A 13536A 13552A 13213A 13551A 14026A 14970A -6-3-...
Page 29
#EV# CONTROL PANEL PARTS (II) MODEL: 24781M 23551A 268711 WTP018 24510L 24970A 23551B -6-5-...
Page 30: Oven Cavity Parts
#EV# OVEN CAVITY PARTS 33112U 33052A WTT010 33390G 34370T 36549S 35889A WTP013 -6-6-...
Page 31: Latch Board Parts
#EV# LATCH BOARD PARTS 43500A 466001 43501A 466003 466001 WSZ085 -6-7-...
Page 32: Interior Parts
#EV# INTERIOR PARTS 568771 WSZ062 56411A 50FZZA 56201A WTT028 56549F 54974S WSZ002 55900A WTT037 WSZ002 50CZZH WTP004 56930G 56851C 56912B WEB001 948501 55262A 54810C WTT028 34930W 56324A WSZ002 -6-8-...
Page 33: Base Plate Parts
#EV# BASE PLATE PARTS 56170D 63302A 63303A 647781 WTT030 WSZ002 WTT021 -6-9-...
Page 34
-40-...
