HISTORY INFORMATION FOR THE FOLLOWING MANUAL:

SERVICE MANUAL

ORIGINAL MANUAL ISSUE DATE: 4/2011
Version
Date
1.0
4/2011
2.0
5/2011
Subject
Original manual issue.
Add Missing Screw Part Number Information.
KDL-26/32/37/40BX320,321,420 (AEP/UK)
S/N range 6,000,001-6,999,999 (WS)
AZ2EK
CHASSIS
Segment: P-2F
LCD Digital Color TV
9-888-441-02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AZ2EK and is the answer not in the manual?

Questions and answers

Related Manuals for Sony AZ2EK

Summary of Contents for Sony AZ2EK

  • Page 1: Service Manual

    HISTORY INFORMATION FOR THE FOLLOWING MANUAL: SERVICE MANUAL AZ2EK CHASSIS ORIGINAL MANUAL ISSUE DATE: 4/2011 Segment: P-2F Version Date Subject 4/2011 Original manual issue. 5/2011 Add Missing Screw Part Number Information. LCD Digital Color TV 9-888-441-02 KDL-26/32/37/40BX320,321,420 (AEP/UK) S/N range 6,000,001-6,999,999 (WS)
  • Page 2 SERVICE MANUAL AZ2EK CHASSIS Segment: P-2F LCD Digital Color TV 9-888-441-02...

  • Page 3: Model List

    MODEL LIST MODEL COLOR COMMANDER DEST. MODEL COLOR COMMANDER DEST. KDL-26BX320 Black RM-ED046 AEP/UK KDL-26BX321 Black RM-ED046 AEP/UK KDL-32BX320 Black RM-ED046 AEP/UK KDL-32BX321 Black RM-ED046 AEP/UK KDL-32BX420 Black RM-ED046 KDL-37BX420 Black RM-ED046 KDL-40BX420 Black RM-ED046 AEP/UK KDL-26/32/37/40BX320,321,420(AEP/UK)

  • Page 4: Warnings And Cautions

    Components identified by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe operation. Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that are critical for safe operation are identified in this manual.
  • Page 5 Les composants identifi es par une trame et par une marque ! sur les schemas de principe, les vues explosees et les listes de pieces sont d’une importance critique pour la securite du fonctionnement. Ne les remplacer que par des composants Sony dont le numero de piece est indique dans le present manuel ou dans des supplements publies par Sony. Les reglages de circuit dont l’importance est critique pour la securite du fonctionnement sont identifi es dans le present manuel.

  • Page 6: Use Caution When Handling The Lcd Panel

    WARNINGS AND CAUTIONS USE CAUTION WHEN HANDLING THE LCD PANEL When repairing the LCD panel, be sure you are grounded by using a wrist band. When repairing the LCD panel on the wall, the LCD panel must be secured using the 4 mounting holes on the rear cover. Do not press on the panel or frame edge to avoid the risk of electric shock.

  • Page 7: Safety Check-Out

    SAFETY CHECK-OUT After correcting the original service problem, perform the following safety checks before releasing the set to the customer: 1. Check the area of your repair for unsoldered or poorly soldered connections. Check the entire board surface for solder splashes and bridges. 2.
  • Page 8 SAFETY CHECK-OUT Leakage Test The AC leakage from any exposed metal part to earth ground and from all exposed metal parts to any exposed metal part having a return to chassis, must not exceed 0.5 mA (500 microamperes). Leakage current can be measured by any one of three methods. 1.

  • Page 9: Self Diagnosis Function

    SELF DIAGNOSIS FUNCTION The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY LED will automatically begin to flash. The number of times the LED flashes translates to a probable source of the problem. A definition of the STANDBY LED flash indicators is listed in the instruction manual for the user’s knowledge and reference. If an error symptom cannot be reproduced, the remote commander can be used to review the failure occurrence data stored in memory to reveal past problems and how often these problems occur.
  • Page 10 SELF DIAGNOSIS FUNCTION [SELF DIAGNOSTIC SAMPLE SCREEN DISPLAY] SELF CHECK Item name BACK << 002 MAIN_POWER 003 DC_ALERT1    003 AUDIO_PROT    004 BALANCER_ERR    STBY LED flash time Error count 005 TCON_ERR    005 PANEL_ID_NVM_ERR    006 BACKLITE_ERR    007 TEMP_ERR    12345‐67891‐23456 [Home] Exit Panel operation time by hour Boot count Total operation time by hour Since the diagnostic results displayed on the screen are not automatically cleared, always check the self-diagnostic screen.

  • Page 11: Sec 1. Disassembly And Parts List

    SEC 1. DISASSEMBLY AND PARTS LIST • Items with no part number and no description are not stocked because they are seldom required for roution service. • The construction parts of an assembled part are indicated with a collation number in the remark colum. •...
  • Page 12 DISASSEMBLY AND PARTS LIST 1-1. KDL-26BX320/321 1-1-1. REAR COVER ASSY AND STAND BLOCK REF. No. PART No. DESCRIPTION REMARK WS0020401 REAR COVER (GW26) WS0018201 COVER, NECK (M3B) WS0018101 NECK (M3B) WS0017601 BASE (M3B) ASSY BX320 WS0017701 BASE (M5B) ASSY BX321 WS0030801 SCREW +BVTP2 4X16 WS0010101...
  • Page 13 DISASSEMBLY AND PARTS LIST 1-1. KDL-26BX320/321 1-1-3. G13 BOARD, A BOARD, SWITCH UNIT, VESA BRACKET AND REF. No. PART No. DESCRIPTION REMARK SIDE BRACKET WS0016001 SWITCH UNIT WS0015801 STATIC CONVERTER (TV)-G13 WS0020001 BRACKET, VESA (GW26) WS0019701 CONNECTOR ASSY 26 FFC WXGA EU WS0016301 MOUNTED PWB A WS0017001...
  • Page 14 DISASSEMBLY AND PARTS LIST 1-1. KDL-26BX320/321 1-1-5. PANEL SUPPORT, H BOARD, LCD PANEL AND BEZEL ASSY REF. No. PART No. DESCRIPTION REMARK WS0016901 PANEL SUPPORT (A) 1-811-375-11 LCD PANEL (A26V7) WS0020301 BEZEL (GW26) WS0016501 MOUNTED PWB H KDL-26/32/37/40BX320,321,420(AEP/UK)
  • Page 15 DISASSEMBLY AND PARTS LIST 1-2. KDL-32BX320/321, BX420 1-2-1. REAR COVER ASSY AND STAND BLOCK REF. No. PART No. DESCRIPTION REMARK WS0018701 REAR COVER (GW32) WS0018801 BRACKET, VESA (M6) (GW) WS0018201 COVER, NECK (M3B) WS0018101 NECK (M3B) WS0017601 BASE (M3B) ASSY BX320,420 WS0017701 BASE (M5B) ASSY...
  • Page 16 DISASSEMBLY AND PARTS LIST 1-2. KDL-32BX320/321, BX420 1-2-3. G13 BOARD, A BOARD, SWITCH UNIT AND SIDE BRACKET REF. No. PART No. DESCRIPTION REMARK WS0016001 SWITCH UNIT WS0015801 STATIC CONVERTER (TV)-G13 WS0016701 CONNECTOR ASSY 32 FFC WXGA EU BX320,321 WS0016801 CONNECTOR ASSY 32 FFC FHD EU BX420 WS0016301 MOUNTED PWB A...
  • Page 17 DISASSEMBLY AND PARTS LIST 1-2. KDL-32BX320/321, BX420 1-2-5. PANEL SUPPORT, H BOARD, LCD PANEL AND BEZEL ASSY REF. No. PART No. DESCRIPTION REMARK WS0016901 PANEL SUPPORT (A) 1-811-376-11 LCD PANEL (A32VE) BX320,321 1-811-377-11 LCD PANEL (A32VC) BX420 WS0018601 BEZEL (GW32) WS0016501 MOUNTED PWB H KDL-26/32/37/40BX320,321,420(AEP/UK)
  • Page 18 DISASSEMBLY AND PARTS LIST 1-3. KDL-37BX420 1-3-1. REAR COVER ASSY AND STAND BLOCK REF. No. PART No. DESCRIPTION REMARK WS0023001 REAR COVER (GW37) WS0018801 BRACKET, VESA (M6) (GW) WS0022501 COVER, NECK (ML3B) WS0022401 NECK (ML3B) WS0022301 BASE STAND (ML3B) WS0002901 SCREW, +PSW M5X16 WS0030701 SCREW, +PSW M4X8...
  • Page 19 DISASSEMBLY AND PARTS LIST 1-3. KDL-37BX420 1-3-3. G13 BOARD, A BOARD, SWITCH UNIT AND SIDE BRACKET REF. No. PART No. DESCRIPTION REMARK WS0016001 SWITCH UNIT WS0022101 STATIC CONVERTER (TV)-G14 WS0022201 CONNECTOR ASSY 37 FFC FHD WS0016401 MOUNTED PWB A WS0017001 BRACKET, SIDE (EU) (GW) WS0023101 POWER SUPPLY CORD (WITH CORE)
  • Page 20 DISASSEMBLY AND PARTS LIST 1-3. KDL-37BX420 1-3-5. PANEL SUPPORT, H BOARD, LCD PANEL AND BEZEL ASSY REF. No. PART No. DESCRIPTION REMARK WS0016901 PANEL SUPPORT (A) 1-811-374-11 LCD PANEL (C37H4-L01) WS0022901 BEZEL (GW37) WS0016501 MOUNTED PWB H WS0030701 SCREW, +PSW M4X8 WS0031201 SCREW, T4X25L KDL-26/32/37/40BX320,321,420(AEP/UK)
  • Page 21 DISASSEMBLY AND PARTS LIST 1-4. KDL-40BX420 1-4-1. REAR COVER ASSY AND STAND BLOCK REF. No. PART No. DESCRIPTION REMARK WS0024001 REAR COVER (GW40) WS0018801 BRACKET, VESA (M6) (GW) WS0022501 COVER, NECK (ML3B) WS0022401 NECK (ML3B) WS0022301 BASE STAND (ML3B) WS0030801 SCREW +BVTP2 4X16 WS0010101 SCREW +BVTP 3X12 TYPE2 IT-3...
  • Page 22 DISASSEMBLY AND PARTS LIST 1-4. KDL-40BX420 1-4-3. G13 BOARD, A BOARD, SWITCH UNIT AND SIDE BRACKET REF. No. PART No. DESCRIPTION REMARK WS0016001 SWITCH UNIT WS0022101 STATIC CONVERTER (TV)-G14 WS0023301 CONNECTOR ASSY 40 FFC FHD WS0016401 MOUNTED PWB A WS0017001 BRACKET, SIDE (EU) (GW) WS0024101 POWER SUPPLY CORD (WITH CORE)
  • Page 23 DISASSEMBLY AND PARTS LIST 1-4. KDL-40BX420 1-4-5. PANEL SUPPORT, H BOARD, LCD PANEL AND BEZEL ASSY REF. No. PART No. DESCRIPTION REMARK WS0016901 PANEL SUPPORT (A) 1-811-329-11 LCD PANEL (S40ESP) WS0023901 BEZEL (GW40) WS0016501 MOUNTED PWB H WS0030801 SCREW +BVTP2 4X16 KDL-26/32/37/40BX320,321,420(AEP/UK)

  • Page 24: Other Parts

    DISASSEMBLY AND PARTS LIST 1-5. OTHER PARTS 1-5-1. MISCELLANEOUS WS0030501 BAG ASSY, SCREW (B) - (Contains Screw Part Numbers: WS0002901(4 pcs) & WS0018001(3 pcs)) 1-5-2. ACCESSORIES * WS0019001 MANUAL, INSTRUCTION * WS0019101 MANUAL, INSTRUCTION * WS0019201 MANUAL, INSTRUCTION WS0015901 REMOTE COMMANDER (RM-ED046) KDL-26/32/37/40BX320,321,420(AEP/UK)

  • Page 25: Sec 2. Adjustment

    SEC 2. ADJUSTMENT HOW TO ENTERING SERVICE MODE 1) Turn on the main power switch to place this set in standby mode. 2) Press the buttons on the remote commander as follows, and entering service mode. Info Channel Volume TV POWER 3) Service mode display.
  • Page 26 ADJUSTMENT 4) How to use the remote commander. Function The flow of control Service mode on <Info><5><Vol Up><Power> Service mode off <Other> / <Power off + on> Adjustment Item up / down Data Value up / down 5) After entering service mode, then turn off the power switch. KDL-26/32/37/40BX320,321,420(AEP/UK)

  • Page 27: Sec 3. Diagrams

    SEC 3. DIAGRAMS 3-1. BLOCK DIAGRAM 3-1-1. BLOCK Crystal Flash EEPROM 512Mbit 512Mbit 512Mbit 128Kbit OSDA0/OSCL0 DDC_LUT0 DDC_LUT1 PDD*/etc RA*/RBA*/RDQ crystal in DDC_LUT2 Filter RDQM* crystal out PANEL_SEL DRAM Nand Flash CLK/Crystal ADCINN/P_DEMOD OSDA0/OSCL0 Demod TUNER_DATA/CLK Interface Interface IF_AGC Tx even/odd LVDS_CTRL1 HDMI1 HDMI_SDA0/SCL0...
  • Page 28 DIAGRAMS 3-1. BLOCK DIAGRAM 3-1-2. RESET/I2C & UART 3V3_SW MT5388 MT5388 OSDA0/OSCL0 Temp Light EEPROM T-Con Sensor Sensor 3V3_SW EEPROM OSDA1/OSCL1 Audio AMP USB_PWR_EN 5V_TUNER TUNER_CLK/TUNER_DATA Reset IC ORESET# Tuner 3V3_SW Audio RESET_AMP HDMI_SCL0/HDMI_SDA0 GPIO_7 HDMI1 Flash 512Mbit 3V3_SW HDMI_SCL1/HDMI_SDA1 U0TX HDMI2 U0RX...

  • Page 29: Connector Diagram

    DIAGRAMS 3-2. CONNECTOR DIAGRAM 3-2-1. KDL-26BX320/321 T-CON Board Panel CN202 CN6401 CN6402 CN8156 CN13 CN17 Main board Power Board Inverter CN9101 IR board Key Pad board KDL-26/32/37/40BX320,321,420(AEP/UK)
  • Page 30 DIAGRAMS 3-2-2. KDL-32BX320/321 T-CON Board Panel CN202 CN6401 CN6402 CN8156 CN13 CN17 Main board Power Board Inverter CN9101 IR board Key Pad board KDL-26/32/37/40BX320,321,420(AEP/UK)
  • Page 31 DIAGRAMS 3-2-3. KDL-32BX420 T-CON Board Panel CN202 CN6401 CN6402 CN8156 CN13 CN17 Main board Power Board Inverter CN9101 IR board Key Pad board KDL-26/32/37/40BX320,321,420(AEP/UK)
  • Page 32 DIAGRAMS 3-2-4. KDL-37/40BX420 T-CON Board Panel CN202 CN6401 CN6402 CN8156 CN13 CN17 Main board Power Board Inverter CN9101 IR board Key Pad board KDL-26/32/37/40BX320,321,420(AEP/UK)

  • Page 33: Circuit Boards Location

    DIAGRAMS 3-3. CIRCUIT BOARDS LOCATION KDL-26BX320/321 KDL-32BX320/321/420 G13 Board A Board G13 Board A Board Switch Unit Switch Unit H Board H Board KDL-37BX420 KDL-40BX420 G14Board A Board G14Board A Board Switch Unit Switch Unit H Board H Board KDL-26/32/37/40BX320,321,420(AEP/UK)
  • Page 34 English 11EP7100-1 Sony Corporation Sony UK Made in U.K. 9-888-441-02 Service Promotions Dept. © 2011. 05 KDL-26/32/37/40BX320,321,420(AEP/UK)
