KAISHOT IDF-PVR Series User Manual

Portable micro audio/video recorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
www.idfone.co.kr
KAISHOT
IDF-PVR(Series) User Manual Ver1.1
● Please note that the manufacturer does not hold
responsibility for troubles caused by the use of imitation
parts.
● Please read "Safety Instruction" (page 1-3) carefully before
use in order to prevent personal injuries or damages to the
product.
● The content of manual can be changed without any notice.
The actual product may look different
from the picture in the User Manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IDF-PVR Series and is the answer not in the manual?

Questions and answers

Summary of Contents for KAISHOT IDF-PVR Series

  • Page 1 KAISHOT IDF-PVR(Series) User Manual Ver1.1 ● Please note that the manufacturer does not hold responsibility for troubles caused by the use of imitation parts. ● Please read "Safety Instruction" (page 1-3) carefully before use in order to prevent personal injuries or damages to the product.

  • Page 2: Safety Instruction

    KAISHOT Safety Instruction This instruction is intended to protect user's safety and prevent any damages to the product. Please read this instruction before use and follow the instruction carefully. Failure to comply may cause serious injuries or death Warning Do not dry this product with electronic heat source such as radiator, microwave, or stove when it gets wet.
  • Page 3 KAISHOT Press the power cord firmly when you plug it in to the outlet, and use the cord head when you unplug it in order to prevent damage to the cord. When the contact is not tight or a part of the cord is cut, it could lead to fire and/or heat over-generation.
  • Page 4 KAISHOT Place the battery in a room temperature when it is not used for long period of time after charged. When you need to use it again after long idle period, it is recommended to use it after recharging it fully. Even after the long idle period, the battery capacity may reduce gradually.

  • Page 5: Before You Use

    Do not support When you set up Backup Time with ‘0 min’, it should continuous recording. support continuous recording. But KAISHOT can record per one hour separately in order to operate system well Apply LCD Saving We recommend that you apply LCD Saving Mode On to Mode On.

  • Page 6: Table Of Contents

    …………………………………………………………... 01~03 Safety Instruction ………………………………………………………………….. 04 Before You Use ………………………………………………………………………….. 05 Contents …………………………………………………………….. 06 KAISHOT Introduction ................07 KAISHOT Series Introduction ……………………………………………………………………… 08 Components ………………………………………………………… 09 The Name of Each Part ……………………………………………. 10 Connecting/Disconnecting Camera ………………………………………………………………. 11~12 Use of Battery ..............

  • Page 7: Kaishot Introduction

    KAISHOT KAISHOT Introduction KAISHOT is a portable Micro Audio/Video Recorder (mobile Personal Video Recorder) which is used to record and store video and audio information, provide locational information, and transmit such information to control tower through wireless network, thus allowing real-time, on-site monitoring of the field operations.

  • Page 8: Kaishot Series Introduction

    KAISHOT KAISHOT Series Introduction Series Features IDF-PVR01 Series *Camera Connector Connected with Hybrid camera or Bullet camera * Hybrid Camera can use Wireless Communication Module/GPS/Camera together. Option Item : Wireless Communication Module and GPS IDF-PVR02 Series Camera Connector Connected with external equipment such as...

  • Page 9: Components

    KAISHOT Components Camera (Optional) Recorder camera User Manual Battery Pack Camera(optional): Hybrid or Bullet Camera(1.5m Turn Core) Micro SD Card CD (Manual/Software) Micro SD Card Reader AC adapter/Power Cord AV Cable USB data transfer Cable (1.5m cable) (1.5m Turn Core)

  • Page 10: The Name Of Each Part

    KAISHOT The Name of Each Part [Kaishot] Hand Strap Connector Belt Clip Camera Connector Speaker DC IN RESET A/V OUT 2.4” Color Micro SD Card Slot TFT LCD Battery Lock USB (Program Update) Cover Lock MENU POWER Tripod Socket UP/RIGHT...

  • Page 11: Connecting/Disconnecting Camera

    KAISHOT Connecting/Disconnecting Camera Cover Lock Cover Lock [Connecting] [Disconnecting] Line up the arrow as the picture Hold the connector’s lock position and above and push the cable down. pull it up to unlock the connection. It will lock automatically and will Camera will be separated from the secure the connection.

  • Page 12: Use Of Battery

    KAISHOT Use of Battery [Battery Mounting] Lever Lever Align the battery with the power Push the battery up, and then connector, and load the battery as slide the Lock to the left to shown on the figure. engage the lock as shown.
  • Page 13 Charging Time - When system is turned off Small Cap. Large Cap. (2,100mAh) (4,200mAh) Connect AC Adapter to the KAISHOT and insert power cord to the power outlet. Time 4~5 hours 7~8 hours When battery is fully charged, there will be green light lit on LED indicator.

  • Page 14: Micro Sd Card Management

    KAISHOT Micro SD Card Management Caution : You must turn OFF the power before you insert or remove the Micro SD Card, or the stored information may be damaged or lost. If you have to remove the Micro SD Card when the power is ON, you should remove the SD Card through the Main Menu.
  • Page 15 KAISHOT [Managing the SD Card through Main Menu] Press the MENU button in the Main Menu for 2-3 seconds. * You can also remove the SD Card while recording, transferring, or playing the data through this method. * If you want to delete the file separately: - Refer to "Playback"...

  • Page 16: Outputting Video To The External Monitor

    KAISHOT Outputting Video to the External Monitor You can play the files recorded by KAISHOT on TV or other external monitors. ▬ Turn off the power supply before connecting the recorder to the external devices. Open the side cover and connect the supplied AV cable with external monitor's AV cable.

  • Page 17: Kaishot Preview

    KAISHOT KAISHOT Preview Refer to page 17 [Main Menu] ("Description of Icons on Upper-Right Corner of the Screen") Transfer Messages Play Setup Time Setting (dd-mm-yyyy AM/PM) [Function Buttons] - Power ON/OFF - Press short: move to the previous or next menu...
  • Page 18 KAISHOT [Description of Icons on Upper-Right Corner of the Screen] New message or image file is received There is no message or image file, or no file is received Wireless module such as WiFi is connected Wireless module such as WiFi is NOT connected...
  • Page 19 ▪ Data is NOT being recorded when file is being transmitted. ▪ You can watch real-time video through KAISHOT Viewer ▪ You can check the list of received messages in the Main Menu by pressing Message icon, and select the message you want to check...
  • Page 20 KAISHOT Functions How to Use ▪ Select GPS icon and press ENTER button to change your GPS settings. ▪ Check GPS module. ▪ GPS information is used to set up time, store GPS data while recording, and transmit GPS information while real-time transmission.

  • Page 21: Recording Functions

    KAISHOT Recording Functions ▪ Recording Functions Details ► Icon Information in the Screen during Recording ► Starting and Stopping a Recording ► Pausing, and Restarting a Recording after Pausing ► Locking and Unlocking a Recording Function ► Checking Messages ▪ You may not be able to perform Recording when: ►...
  • Page 22 KAISHOT [Icon Information in the Screen during Recording] Unlock mode indicated by Recording mode (Pause indicated by Remaining Micro SD Card capacity left) (Number indicates how much memory Wireless Module On Message Status Remaining Recorded file name GPS Status Battery yymmddhhmmsss.MP4...
  • Page 23 KAISHOT [Starting and Stopping a Recording] Starting a Recording ▪ Select REC icon in the Main Menu and press ENTER button to start recording. ▪ Recording is possible, except when data is being transmitted real-time, by pressing for 2-3 seconds ▪...
  • Page 24 KAISHOT [Pausing, and Restarting a Recording after Pausing] Pausing while Recording ▪ Press ENTER button for 2-3 seconds to pause recording. (You can check the text message by pressing "ENTER" button shortly.) ▪ Icon will change Restarting after Pausing ▪ Press ENTER button for 2-3 seconds while pausing a recording to restart a recording.

  • Page 25: Playback Functions

    KAISHOT Playback Functions ▪ Playback Functions Details ► Icon Information in the Screen during Playback ► Starting and Stopping a Playback ► Pause / Restart / Return to the Start of the Playback / Fast-forward and Rewind ► Adjusting OSD, Audio Volume, LCD Brightness ►...
  • Page 26 KAISHOT [Icon Information in the Screen during Playback] Playback Micro SD Card Capacity Wireless (Number indicates the memory cap.) Module Time file is Remaining being played Message Status Battery File name GPS Status (yymmddhhmmss.MP4) Total recording time Recorded time (day month date h:m:s year) (Lat.
  • Page 27 KAISHOT [Starting and Stopping a Playback] Starting a Playback ▪ You can check the list of files recorded when you press “Play” button. Select the file you want to watch and press ENTER to start playback. ▪ The icon will change to Stopping a Playback ▪...
  • Page 28 KAISHOT Pause / Restart/ Return to the Start of the Playback / Fast-forward and Rewind Pause while Playback Mode ▪ Press ENTER button for 2-3 seconds to pause playback. You can check the text message by pressing "ENTER" button shortly.
  • Page 29 KAISHOT [Adjusting OSD, Audio Volume, LCD Brightness] ▪ If you press MENU button 2-3 seconds while playback, Popup Menu appears. ▪ If you press MENU button shortly (less than 2 seconds), the Menu will disappear. Changing OSD Status ▪ Select OSD Display and ENTER button.
  • Page 30 KAISHOT Adjusting Audio Volume while Playback ▪ Select desired Audio volume and press ENTER button. Adjust volume with button. Adjusting LCD Brightness while Playback ▪ Select desired LCD Brightness and press ENTER button. Adjust the brightness with button.
  • Page 31 KAISHOT [Micro SD Card Management in the Recording File Menu] ▪ Press MENU button in the Play List for 2-3 seconds. Popup Menu will appear. ▪ Popup Menu will disappear when you press MENU button again, without changing any values.
  • Page 32 KAISHOT Deleting File / Directory from the File List ▪ Choose the file or directory you want to delete and press MENU button for 2-3 seconds. Select DELETE, and then press ENTER button to delete.

  • Page 33: Transmission (Real-Time) Functions

    ▪ Values changed in the Setup will affect the properties of transmission, as well as the condition of transmission. ▪ Transmission will continue while checking the messages. ▪ You can watch the real-time transmitted video via KAISHOT Viewer. For the information regarding KAISHOT Viewer, please refer to the KAISHOT Viewer Manual.
  • Page 34 KAISHOT [Icon information in the Main Screen while Real-time Transmission] Lock Status Micro SD Card Capacity Wireless (Number indicates module status the memory cap.) Remaining Recording mode battery * When wireless module status icon shows weak signals, real-time transmission may not work properly.
  • Page 35 ▪ When Server IP of Transfer Setup is inputted, KAISHOT can transmit Image(Client) to Server IP . When you want to connect with KAISHOT to get Video file directly, you should set initial field of IP or last field of IP with “0”.
  • Page 36 KAISHOT [Locking and Unlocking while Real-time Transmission] Locking while Real-time Transmission ▪ Press MENU button for 2-3 seconds while transmission to activate Lock function. ▪ Lock Icon will change from ▪ Except pressing MENU button for 2-3 seconds to deactivate Lock function, no buttons will function normally.

  • Page 37: Checking Messages

    ▪ Checking messages may terminate automatically when: ► Any of the situation above (You may not able to check messages) occurs, message checking will terminate automatically. ▪ You can send messages via KAISHOT Viewer. ▪ Values changed in the Setup will affect the message checking function.
  • Page 38 KAISHOT [Checking Messages] Checking Messages ▪ You can check the list of messages in the Main Menu by selecting Message icon, and press ENTER button to check the message you selected. Currently available SD Card Memory Capacity Current time (dd-mm-yy am/pm h:m)
  • Page 39 KAISHOT ▪ You can check messages by pressing ENTER button while recording, playback, or real- time transmission. Functions will normally continue while checking messages. ▪ While Checking messages, press to check previous message, to check next message. Receiving a New Message while Checking Messages ▪...
  • Page 40 KAISHOT [Zooming In a Message] ▪ Menu screen will appear if you press MENU button for 2-3 seconds while checking message.(Previously performed function will resume if you press MENU button shortly (less than 2 seconds) ▪ If you press MENU button in the Menu screen without changing any settings, Popup Menu will disappear.
  • Page 41 KAISHOT [Managing Micro SD Card in the Messages Menu] ▪ Popup Menu will appear when you press MENU for 2-3 seconds in the Message List. ▪ If you press MENU button in the Popup Menu without changing any settings, Popup Menu screen will disappear.

  • Page 42: Gps Settings Functions

    KAISHOT GPS Setup ▪ GPS Setup Functions Details ► GPS Setup ► Checking GPS Information ► GPS Setup and Checking Messages while Checking GPS Information ▪ GSP Information is used for Recording and Transmission. If GPS is not connected properly or OFF, or if it is impossible to receive information to it, default GPS value will be used.
  • Page 43 KAISHOT [GPS Setup] ▪ Select the value you want to change by using , and press ENTER button. ▪ You will return to the previous screen by pressing MENU button shortly (less than 2 seconds). GPS Power : On/Off Resume : Restart GPS.
  • Page 44 KAISHOT [Checking GPS Information] ▪ Check GPS information by pressing GPS icon. ▪ Press MENU button shortly (less than 2 seconds) to return to the Main Menu. The number of satellite, (Lat. Lon.Vel)

  • Page 45: Setup

    KAISHOT Setup ▪ Setup Details ► Record Setup ► Stream Setup ► GPS Setup (Refer to GPS Setup Function ► Tools Setup ▪ Select Setup in the Main Menu and press ENTER button to set up the value of each functions..
  • Page 46 KAISHOT [Record Setup] ▪ Select REC Setup in the Setup menu and press ENTER button. ▪ Press MENU button shortly (less than 2 seconds) to return to the Main Menu. REC Setup Details Format NTSC Video ▪ Determines the resolution of video PAL Video Format file.
  • Page 47 KAISHOT REC Setup Details ▪ Select a mic to use for recording. ▪ You can choose to record audio and video, or audio only. ▪ When set up as “0 min”, Per one hour recording separately. (except for abnormal situations) ▪...
  • Page 48 KAISHOT [Stream Setup] ▪ Select Stream Setup in the Setup, and press ENTER. ▪ Press MENU" button shortly (less than 2 seconds) to return to the previous menu. Stream Setup Details NTSC video Format PAL Video Format ▪ Resolution setup. Value range may differ according to the video format.
  • Page 49 ▪ This is where you set up MENU move to next KAISHOT’s server IP. It is change value essential that KAISHOT exists setup ENTER within NAT or HSDPA mobile network and KAISHOT Viewer exists in the outside network.
  • Page 50 KAISHOT Use Ad-hoc Mode (Use as AP Mode) ▪ - Set up the AP name of the product (SSID). Caution Be sure that the surrounding wireless network environment does not have the same SSID setup. ▪ Select the network type, choose Ad-hoc mode using ENTER button.
  • Page 51 KAISHOT Stream Setup Details ▪ “Select REC” is “REC on”. ▪ It is for set up back up time for REC during transmission. ▪ When set up as “0 min”, Per one hour recording separately. (except for abnormal situations) ▪ When “Backup Time Setup” is...
  • Page 52 KAISHOT [Tools Setup] ▪ Select Tools Setup in the Setup menu, and press ENTER button. ▪ It will return to the Setup menu when you press MENU button shortly (less than 2 seconds). Tools Setup Details LCD Brightness. 1 to 10 Use "...

  • Page 53: Setup

    KAISHOT Tools Setup Details Decide video input/output format Refer to Micro SD Card Management Choose the method of how you want to be indicated when message is received. It will continue to alarm until the message is being checked. This product supports operation in English, Korean, Chinese, and Japanese.

  • Page 54: Program Upgrade

    KAISHOT Program Update Bootloader, Kernel, Ramdisk Update Bootloader, Kernel , Ramdisk Update process Connect KAISHOT to PC USB port with USB cable. *If KAISHOT battery capacity is not enough then use adapter. If during upgrade time KAISHOT power off then big problem for update.
  • Page 55 “COM7” then connection is completed. If port number is “PORT ####” then connection is problem. That time KAISHOT power restart and restart first step. Use “Select file button” and select update file for Bootloader, kernel, Ramdisk(RootFs). After then press “OK” button...
  • Page 56 KAISHOT Bootloader, Kernel, Ramdisk Update process Bootloader Download Kernel Download Ramdisk(RootFS) Download Check Bootloader icon Check Kernel icon Check RootFS icon And press download And press download And press download button then download button then download button then download processing starting processing starting.
  • Page 57 KAISHOT Bootloader, Kernel , Ramdisk Update process Bootloader, Kernel, Ramdisk update done then press close button for SDNW software finishing. KAISHOT power off. (If KAISHOT power switch not run then remove USB cable or use KAISHOT RESET switch )
  • Page 58 SDCARD Folder Insert the SD Card that contains the updated version information of KAISHOT that you wish to install, and turn the system on. Program update message will appear.

  • Page 59: Troubleshooting

    Please check if SD card is inserted correctly. Please KAISHOT power on again in case It shows when file can not play on the playback list or the file is damaged. Also it can show when the file is not supported on message list.

  • Page 60: Troubleshooting

    KAISHOT Error Messages Possible causes and solutions The battery is almost empty. The system will automatically turn off after terminating all functions. Replace the battery or recharge the battery. This message appears when wireless setup has incorrect value, or WiFi signal is weak.

  • Page 61: Product Specifications

    KAISHOT Product Specifications [KAISHOT] Technical Specifications ARM920T Mic Input Internal 1 Ch , External 1 Ch Internal Speaker Output Power : 1W USB 1.1 : 1port External I/O Interface AV out : 1ea [Φ3.5 AV Jack (RCA)] 2.4 “ color TFT-LCD (QVGA)
  • Page 62 KAISHOT [Hybrid Camera: Standard Camera] Technical Specifications TV system NTSC / PAL 1/4" CCD Image Sensor Lens and View Angle 3.6mm(standard) F2.0 / 68° , lens exchangeable Scanning system 525 Lines, 60 fields/sec / 625 Lines, 50 fields/sec 0.5 Lux, F1.2, 5600 °K Min.
  • Page 63 KAISHOT [Functional Specifications] Functional Specifications Embedded OS (Linux) Video Input (Camera) 1Ch, NTSC/PAL(Selectable) Video Output 1Ch, NTSC/PAL(Selectable) NTSC: [720 X 480] [640 X 480] [320 X 240] (W X H) Resolution PAL: : [720 X 576] [352 X 288] (W X H) Video Quality High[1.5Mbps], Standard[1Mbps], Low[700Kbps]...
  • Page 64 02-2109-6490 Please be sure to use battery charger, battery and peripherals recommended by manufacturer to prevent damage or breakage to the KAISHOT. Warranty period: Battery charger (1 year), Battery (6 months) Any damage caused by the use of imitation product is liable to the user’s responsibility.
