User's Manual
DR1064/DR1128/DR1256/DR1512/DR11024
Dyne Telecom Co., Ltd.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DR1064 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dyne Telecom DR1064

  • Page 1 User’s Manual DR1064/DR1128/DR1256/DR1512/DR11024 Dyne Telecom Co., Ltd.

  • Page 2: Table Of Contents

    Contents & & & &...

  • Page 3: P R E P A R A T I O N

    Please Read the following precautions before using the unit. Any problem happened without reading this precaution is not Dyne telecom’s responsibilty. ● Do not use the unit for other purposes which are not recommended in this manual. ● Do not impact the unit by strong stock or shaking. Or it may cause a serious problems on unit.

  • Page 4: P R O U C T F E A T U R E S

    etc. ● Do not disassemble & assemble the unit by yourself. It will not covered by Dyne’s A/S ● Check the polarity before you use the battery. ● When you are not going to use the unit for a long time, remove the batteries to prevent damage from battery leakage and corrosion.

  • Page 5: A C C E S S O R I E S

    ● External Stereo Recording : Real time recording to MP3 file by connecting to external audio device. ● Mass Storage : Used as a portable storage device. ● Firmware Upgrade available via the USB ● Navigation : Anytime file selection is available while listening to music by Navigation file search function ●...

  • Page 6: W M A

    The battery indicator shows the battery consumption . The unit have a small rechargeable battery in side to preserve time & s e t t i n g s . H o w e v e r , i f 1 hours or 10 hours (In case a small Rechargeable battery is charged for an hour) is passed without batteries, the time &...

  • Page 7: L A Y O U T A N D F U N C T I O N K E Y S

    This product has automatic power off funtion. If the time passes 3 minutes without any use, the power is cut off automatically. To turn power off directly, Set the HOLD button on. To turn power on, release the HOLD button and press any key.

  • Page 8: M O D E S E T T I N G

    In case press any key in Hold mode, the current time will appear for about 5 seconds and disappear. To use the player again, release the HOLD button to off. This unit is devided into three modes like VOICE MODE, RADIO MODE and MUSIC MODE.
  • Page 9 Short Press Deleting file Stop State Long Press Deleting all the files in the folder Erase Displaying current time Short Press and the information of Stop State the recordedfile Long Press Mode Change Displaying the information of Mode/Display Short Press Playback the recored file State...
  • Page 10 Long Press Fast Forwarding Search Short Press Move the curser to the next or Menu State change the value up Move the cursor Stop State Short Press To the lower file Playing former file (In case of Playing within 10sec) Short Press Playing current file Playback...

  • Page 11: D E S C R I P T I O N O F L C D W H I L S T R E C O R D I N G

    Recording State *Navigation Function : Press folder button and go to Navigation Mode while playingback, you can select desired file using FF or REW button. By pressing play button shortly in the state of file selection, the selected file will be played back.

  • Page 12: P A U S E W H I L E R E C O R D I N G

    2. After placing Mic. to the sound source press REC button shortly to record 3. Press Stop button shortly to stop while playing – Try test recording not to fail recording - The number of recoding will be automatically saved next to the last recorded file - Be careful not to scrub the surface of the player while recording to prevent the noise to be recorded.
  • Page 13 1. By pressing Menu button, Change the mode to SHQ→HQ→SP→LP mode. 2. After checking selected mode, press menu button about 2 seconds, then recording will be started while the message number is changed. *By changing mode, recording time is extended when the remaining time is insufficient while recording Description pressing...

  • Page 14: C O N N E C T I N G T O T H E E X T E R N A L M I C R O P H O N E

    You can easily record the message by using the external microphone. 1. Connect the external microphone to the MIC terminal of the voice recorder. 2. Press REC button. It starts recording. 3. To stop the recording, press STOP button again. 4.

  • Page 15: P L A Y B A C K & P A U S E

    *Note! If you do not use the Microphone, Telephone line and Telephone adaptor supplied by us, the set may not work properly. & & Description 1.Choose the file you want to listen by FF or Rew buttton. 2. Press Play button shortly to play 3.

  • Page 16: P L A Y I N G P R E V I O U S / N E X T F I L E W H I L E P L A Y I N G

    1. Press REW button shortly while playback Previous song will be upfront in case of playback in 10 seconds. 2. Press button shortly while playblack, it moves to next song Ongoing song will begin from the first in case of playback 10 seconds afterward.

  • Page 17: D I S P L A Y I N G F I L E I N F O R M A T I O N

    Description LCD Display 1. While playing, Press REC button shortly, “ A → “ will be displayed on LCD and then Starting point of section repeat will be set. 2. Press REC button shortly again, then “A → B“ on LCD will show and work the section repeat.

  • Page 18: M E N U S E T I N G

    folder button. For using hearing aid fuction, earphone must be connected to the set. Connecting earphone, when pressing long REC button, hearing aid function starts. When pressing stop button, this function stops. Caution Before wearing earphone, do not forget to check the sound level which is sometime s strong enough to hurt the sense of hearing of a person who has sensitive ear.

  • Page 19: S Y S T E M S E T I N G M E N U

    LOW, HIGH HIGH Mic Sensivity LP(6K), SP(32K), HQ(64K), SHQ(128K) SHQ(128K) Record type VOR OFF, VOR ON VOR OFF VOICE OPERATING RECORD Noise Reduction OFF, Noise Reduction ON Noise Reduction Noise Reduction * Pressing FF or REW button in the main menu, it moves to system setting menu.
  • Page 20 Alarm Voice Recording, Radio Recording Voice Recording Recording Time Preset Japanese, Korean, English Japanese Language OFF, 1 ~ 20sec LCD Backlight ON LCD Backlight 0~20 LCD Contrast 0~20 Beep Sound Memory Size & Version Description System Information Upgrade & Font Download System Upgrade Low Level Format &...
  • Page 21 Playback all the file’s front for 10 seconds. Intro Stop after playback one file only. Normal One Stop after playback all the files in Memory. Normal All Random Playback from first to last files in Memory Normal Random Repeat playback all the files in Memory Reapeat One Repeat playback all the files in Memory Repeat All...
  • Page 22 Mode Description Playback of 130% speed rate Speed 130% Playback of 130% speed rate Speed 120% Playback of 130% speed rate Speed 110% Playback of 130% speed rate Speed 100% Playback of 130% speed rate Speed 90% Playback of 130% speed rate Speed 80% *Note LP(Long Play)recording is only being played with Normal Play speed,100%.
  • Page 23 exists. SETTING VOR RANGE 1. Automatic Setting 1-1. Start Recording. 1-2. Make the circumstance quiet after pressing Erase button shortly. * The dot line of Level bar on the bottom of the LCD changes to maximum value of the input sound and becomes the standard range of the VOR. 1-3.
  • Page 24 Record with 6Kbps Long Play *Note *Lower bit rate is able to povide longer recording time but low sound quality. System Setting Menu 1. Sleep Mode If Sleep Time is set on, the unit is powered off automatically after the set time 2.
  • Page 25 Alarm will be activated if it is set on. Select Time, Minute, Day by FF or buttons and set the Alarm time and day by Vol+ or Vol- buttons. The alarm will be set on after set the alarm time and press the Play button.
  • Page 26 6. Language Select one language among Korean, Japanese and Engligh by FF or REW button. If press Play button after language selection, the menu and all description will be displayed by the selected language. 7. LCD Backlight LCD Backlight supports to see the LCD display in the dark place. Set the Backlighting time by FF or REW button after press Play button.

  • Page 27: R A D I O M O D E

    Caution! Be careful the USB cable is not disconnected while upgrading and font downloading. Note Refer to the “Font Download“ for the detail. 12. Initialize Initialize the Menu setting value after memory format. Caution! Low Format may take several minutes depending on the memory size. Be careful the power is not off while format.
  • Page 28 Long Press Save Manual Station Searching Short Press station Stop Searching automatically Stop Cancel current selected category Menu Short Press and move to upper class. Short Press Select preset mode and frequency man ual mode.Preset Long Press Search station automatically Save current selected station and Play Short Press...

  • Page 29: P R E S E T S E T I N G

    Short Press Volume down Short Press Set the value down for the selected Vol - Menu menu Power Off Hold Save your preferred radio station and listen easily later time. To set the Preset, there are manual setting and automatic ways. The detail usage information is following.

  • Page 30: U S I N G P R E S E T

    4. press REC button shortly, currently selected broadcasting station will recorded. 2. Automatic Setting Description LCD Display Press Play button long and automatically set the Preset value.. * Note : Earphone has an antenna function. So, do not remove the earphone from the unit.

  • Page 31: P R E S E T D E L E T I O N

    Description LCD Display 1. IF press button long, the preset will be erased one by one, and the Preset numbers after the erased one will be erased one by one too. Description LCD Display 1. Select the folder to be recorded by pressing Folder button 2.
  • Page 32 *Press Stop button shortly in Menu Setting mode. Then, it will escape from Menu Setting mode. The detail information on each menu is described below. Description Default Function Setting LP(6K), SP(32K), HQ(64K), SHQ(128K) Record Type Japan, Asia/USA, Europe Japan Radio Band Function Setting Menu 1.

  • Page 33: B U T O N D E S C R I P T I O N

    Frequency Range 87.5 ~ 108 MHz Europe Frequency Step 0.05 MHz Status & Method Key Description Stop State Long Press Enter into Main Menu Playback Menu State Playback Short Press Change to the Navigation State Folder Short Press Delete the selected file Stop State Long Press Delete all the files in a folder...

  • Page 34: L C D D I S P L A Y D E S C R I P T I O N W H I L E P L A Y B A C K

    Move the cursor to next part or Menu State Short Press set the value up Move the cursor to the lower Stop State Short Press file Short Press Playback the previous file Playback Playback the previous file(In State Long Press case within 10 sec.

  • Page 35: P A U S E

    1. Select the file to playback by FF or REW button 2. Playback by pressing Play button shortly 3. Stop it by pressing Stop button while playback * Navigation Function : Press folder button and go to Navigation Mode while playingback, you can select desired file using FF or REW button.

  • Page 36: F A S T S E A R C H I N G

    2. Playback the next song by pressing FF button shortly while playback(after 10sec.) Fast forward or backward in a song by pressing REW or FF button while playback. Listen to the selected area repeatedly in a playback file. Description LCD Display 1.

  • Page 37: M E N U S E T I N G

    For using hearing aid fuction, earphone must be connected to the set. Connecting earphone, when pressing long REC button, hearing aid function starts. When pressing stop button, this function stops Caution Hearing Aid Function is for who has weak sense of ear Before wearing earphone, do not forget to check the sound level w hich is sometimes strong enough to hurt the sense of hearing of a person who has sensitive ear.
  • Page 38 Bass Boost OFF, BASS Boost ON Bass Boost INTRO, NORMAL ONE, NORMAL ALL, NORMAL RANDOM, REPEAT ALL Repeat REPEAT ONE, REPEAT ALL, REPEAT RANDOM OFF, Clock, User’s Image Screen Saver 80%, 90%, 100%, 110%, 120%, 130% 100% Play Speed 1.Screen Saver If it pass some time in Playback, the LCD view will change to Watch or User Image.

  • Page 39: U S I N G B Y C O N N E C T I N G T O Pc

    No need to get installation of any software but directly use this device in Window ME, 2000, XP. However, being requested to install „ MASS Storage Driver“ in Windows 98. Insert provided CD into CD-ROM to make it autorun with „ Installation program“. If not, kindly select and click „...

  • Page 40: F O N T D O W N L O A D ( L A N G U A G E S U P P O R T )

    Connected to PC , It is automatically recognized with removable disc. No need to get installation of any software but directly use this device in Window ME, 2000, XP. However, being requested to install „ MASS Storage Driver“ in Windows 98. Select the Mass Storage Drive for Windows 98 on the menu of INSTALLATION PROGRAM in CD.

  • Page 41: L I S T E N I N G T O R E C O R D E D F I L E

    3. Select System upgrad by using FF or button. 4. By pressing play button, upgrade and font download will be stand by. 5. By connecting the set into a PC using USB cable, the picture like right side will be shown on the LCD.
  • Page 42 4) Be ready to get installation.
  • Page 43 5) Press a <Next> button. 6) Press <Next> button. (To change the directory of installation, press <Browse...> button as below and set the directory) 7)Press <Next> button, file will be copied.

  • Page 44: P L A Y B A C K T H E R E C O R D E D F I L E

    8)Press <Finish> button to finish the installation. After installation, Basic screen is as belows. Detailed usage descriptions are followed in “ “ button placed the right top side of Express Media Player.

  • Page 45: S P E C I A L U T I L I T Y

    1) All running programs should be closed before installation 2) Select ‚Special Utility’ of installation program menu in the CD, installation will start. 3) Preparing to install 4) Press <Next> button (To change the directory of installation, press <Browse...> button as below and set the directory)
  • Page 46 5) Press <Next> button, then, the installation will be completed after file copy.

  • Page 47: S P E C I A L U T I L I T Y E X E C U T I O N

    1.The icon „Express Special Utility“ will be created on the PC background when the instalation is completed. 2. Double click the icon and execute it, the icon will show up in System Tray. 1. If player is connected to PC, the state icon will be changed like below : Before : After Note : In case of using Windows 98, please install the driver refering to the...
  • Page 48 Using Screen Saver Editor Edit the picture to make user selected picture be displayed on the LCD. Screen Saver Editor will be executed when select „Screen Saver Editor“ in state icon menu. 1) Opening Image File Import the file to be edited by pressing button 2) Preview Window Preview the file to be displayed on the LCD.
  • Page 49 <Before Adjusting> <After Adjusting> 4) Image Size Adjusting Adjust the image size what user want. - Actual Size : Adjust the size as same with original one. - Best Fit in Canvas : Adjust the size same with Canvas window. - Best Fit in LCD : Adjust the size same with Preview window.
  • Page 50 - Delete : Delete the selected image from the Image List. - Changing Order : Change the order of selected images in Image List. 10) Saving Save the edited image list in palyer.

  • Page 51: S P E C I F I C A T I O N

    Item Description Channel Stereo Frequency Range 20Hz ~ 20KHz Audio Earphone output 10mW + 10mW(16 ohm) Speaker output 180mW(16ohm) S/N Rate 90dB (MP3) Model 64MB 128MB 256MB 512MB Description 1Hrs. 05Min 2Hrs.10Min 4Hrs.25Min 8Hrs. 50Min 2Hrs. 10Min 4Hrs. 25Min 8Hrs. 50Min 17Hrs.

  • Page 52: T R O U B L E S H O O T I N G

    Note : It depends on the battery type and the using condition(Above data is according to the manufacturer’s standard) Problem Cause Action * Check the battery * Replace with a new battery. voltage * Some problem exists * Do upload and playback in Manager program No stable sound on file itself.
