  • Page 1 User Manual...

  • Page 2: Copyright Regulations

    Your ADVC-1000 options are covered by a limited warranty when you register your Grass Valley product. This warranty is for a period of one year (or two years in European Union countries) from the date of purchase from Grass Valley or an authorized Grass Valley agent. This warranty applies only to the original purchaser of the Grass Valley product and is not transferable, Grass Valley warrants that for this period the product will be in good working order.
  • Page 3 Notices & W Notices & W Notices & W Notices & W Notices & Warranties arranties arranties arranties arranties Protect against static electricity An electrostatic discharge may damage components of this product. Do not directly touch any of the connectors or component surfaces. Static electricity can be generated on clothing and on people.

  • Page 4: Fcc Notice

    Do not cover the ADVC-1000 ventilation Do not use the ADVC-1000 covered with a cloth or in an ill-ventilated room. Covering the vent may cause heat inside of the product resulting in fire or product malfunction. Precautions for use of AC adapter The supplied AC adapter and power cord are for exclusive use of this product.

  • Page 5: Product Notes

    7. Canopus, as written in both English and Japanese, and its logo are registered trademarks of Canopus Co., Ltd. 8. ADVC is registered trademark of Canopus Co., Ltd.

  • Page 6: About The Documentation

    About the Documentation About the Documentation This document is the ADVC-1000 User Manual. Information not listed in this document may be listed elsewhere. In cases where there is a difference between a description in this documents and an actual opera- tion method, the actual operation method takes precedence.
  • Page 7 Chapter 1 T able of Contents Hardware Installation...

  • Page 8: Table Of Contents

    Chapter 1 Introduction Chapter 1 Introduction Chapter 1 Introduction Chapter 1 Introduction ......1 1-1 Package Contents ................2 1-2 Features of the ADVC-1000 .............. 2 Chapter 2 Basic Instructions Chapter 2 Basic Instructions Chapter 2 Basic Instructions Chapter 2 Basic Instructions Chapter 2 Basic Instructions ....

  • Page 9: Chapter 1 Introduction Chapter 1 Introduction

    Chapter 1 Chapter 1 Introduction Hardware Installation Thank you for purchasing the ADVC-1000 Advanced DV/SDI Converter. Before you start using your system, please read this manual and follow the installation instructions. This will ensure that you have a trouble-free setup. If you...

  • Page 10: Package Contents

    SDI (serial digital interface) signals are the standard sig- nal for professional digital video, and DV (digital video) signals have a high PC compatibility. The ADVC-1000 uses a proven Canopus DV codec, ensuring that converted signals have a solid quality.

  • Page 11: Chapter 2 Basic Instructions Chapter 2 Basic Instructions

    Chapter 2 Chapter 1 Basic Instructions Hardware Installation This chapter explains the part names and functions and other basics of the ADVC-1000. - Part names and functions - Connecting devices - Setting Menu - Specifications...

  • Page 12: Part Names And Functions

    Names and F unctions ADVC-1000 Front Panel The front panel of the ADVC-1000 contains the following controllers and indicators: 1. POWER switch -- Turns the ADVC-1000 power ON/OFF. 2. Select key --------- Move up/down to select menu items, and left/ right to change settings.
  • Page 13 SDI video signal, SDI embedded audio signal or AES/EBU audio signal to a DV signal. When only the “DV SDI” LED is lit, ADVC-1000 converts the DV signal to an SDI video signal, SDI embedded audio signal and AES/EBU audio signal. STATUS LED Off: ......

  • Page 14: Advc-1000 Rear Panel

    Basic Instructions Basic Instructions Basic Instructions ADVC-1000 Rear Panel The rear panel of the ADVC-1000 contains the following connectors 1. MONITOR OUT --------- Output connectors for video monitor, speakers. 2. REF ------------------------- Input connectors receiving sync signal. The LED lights red when sync signal input is detected.

  • Page 15: Lcd Screen Displays

    Basic Instructions Basic Instructions Basic Instructions Basic Instructions Basic Instructions LCD Screen Displays There are three main screens, switched by moving the Select key up/down. Move the Select key left/right to switch between the error status screen and the main screens. Pressing the MENU key displays the Settings Menu screen.
  • Page 16 Basic Instructions Basic Instructions Basic Instructions Basic Instructions Basic Instructions 9-pin remote control deck status (Lower left on the screen) If blank ....9-pin remote control is not in use. NoDevice ....Can't find deck. Check cable connection. NoCASETTE ..No tape in deck. STOP ....
  • Page 17 Basic Instructions Basic Instructions Basic Instructions Basic Instructions Basic Instructions DV audio input (Upper left on the screen) 32kHz/4ch > both 00:00:03;22 48kHz/2ch ..... DV audio input is 48 kHz/ 16 bits/ 2 channels. Digital audio output CH3 and CH4 are copies of CH1 and CH2. 32kHz/4ch .....
  • Page 18 Basic Instructions Basic Instructions Basic Instructions Basic Instructions Basic Instructions DV input time code (Lower right on the screen) 32kHz/4ch > both 00:00:03;22 00:00:03:22 ..For PAL/NTSC NDF (Non Drop Frame) * A colon is used between seconds and frames as a delimiter.
  • Page 19 The video standard is set by DIP TC source:DVITC NTSC switch SW4 on the bottom of the unit, or by the menu option "19 NTSC ....ADVC-1000 operates in NTSC mode. video standard". (See "DIP switch settings" on p.15 PAL ......ADVC-1000 operates in PAL mode.
  • Page 20 Basic Instructions Basic Instructions Basic Instructions Basic Instructions Basic Instructions Main Screen 3 This screen shows information on the current settings. External synchronization enabled/disabled (Upper side on the screen) GENLOCK:enable REMOTE:enable disable ....External synchronization function is disabled. enable ....External synchronization function is enabled.
  • Page 21 Basic Instructions Basic Instructions Basic Instructions Basic Instructions Basic Instructions Error Status Screen This screen shows error messages. Error Status Screen When error has occurred Time code (Upper side on the screen) LTC ......LTC was selected for time code input, and time code signal can't be detected from TC connector during SDI DV mode.
  • Page 22 CH4 used for DV encoding can't be detected. Other Errors Variation in input signal exceeded ADVC-1000's jitter attenuation function tolerance limit. Change the setting of menu item 62 ("jit- ter attenuator") to "off". When the DV audio encoding setting is 32 kHz, the "selected au- dio"...

  • Page 23: Dip Switch Settings

    Allow you to set various modes. SW3, SW4 may differ depending on CAUTION your point of purchase. Make sure to turn off the power of the ADVC-1000 unit before making any changes for DIP switch settings. DIP switches 5, 6, 7 and 8 should be set to OFF.

  • Page 24: Connecting Devices

    2-2 Connecting Devices 2-2 Connecting Devices CONNECTING THE ADVC-1000 UNIT (STANDARD) Connect the ADVC-1000 unit to your system. The diagram below illustrates the typical connection of the ADVC-1000. CAUTION DV editing software is required to playback or capture AVI video files for use on a PC or to record t h e f i l e d a t a o n t o t a p e .

  • Page 25: Connecting The Advc-1000 (System Integrated)

    Basic Instructions Basic Instructions Basic Instructions Basic Instructions Basic Instructions CONNECTING THE ADVC-1000 UNIT (SYSTEM INTEGRATED) Quick Setting Mode Setting item Settings Ref. page 22 DVITC insert line Selecting line No. or off 31 ext. sync disable, enable, advanced 11 DV audio encode 48kHz CH1/2, 32kHz CH1234,...

  • Page 26: Importing Sdi Data To Your Pc

    Basic Instructions Importing SDI data to your PC Import the material of the tape on VCR into a PC. 1. Press the [Mode] switch on the front panel of the ADVC-1000 to switch the mode to the “SDI DV” mode.

  • Page 27: Setting Menu

    Basic Instructions Basic Instructions Basic Instructions Basic Instructions Basic Instructions 2-3 Setting Menu 2-3 Setting Menu 2-3 Setting Menu 2-3 Setting Menu 2-3 Setting Menu Data Conversion Process Menu Press the MENU key. Menu items are displayed on the LCD screen. Move the Select key up/down to select the desired menu item, then left/right to change the setting of the selected item.
  • Page 28 Basic Instructions Basic Instructions Basic Instructions Basic Instructions Basic Instructions 11 DV audio encode Lets you select any of the following settings below related to the DV audio format used for DV encoding. LCD Display Setting Description 48kHz CH1/2 48 kHz/2 channels; encode CH1 and CH2 audio inputs.
  • Page 29 LCD Display Setting Description Doesn’t stop SDI output. Info (Factory default) When the ADVC-1000’s SDI Stops SDI output. connectors (IN and OUT) are connected to the SDI connectors (IN and OUT) of your device while the external sync signal is not...
  • Page 30 Stops DV output if there is no SDI input and no AES/EBU input. Doesn’t stop DV output. 17 DVout aspect info Sets an aspect ratio for the DV stream that ADVC-1000 outputs in DV mode (DV encoding). LCD Display For NTSC...
  • Page 31 SMPTE. Info For PAL See the "Outputting component signals (p. 33) on how to connect Setting Description ADVC-1000 to output component composite/s-video Outputs Composite signal and S-video signal. signal. (Factory default) component (EBU) Outputs Component signal with the signal level compliant to EBU.
  • Page 32 Basic Instructions Basic Instructions Basic Instructions Basic Instructions Basic Instructions 21 TC input source Lets you select any of the following settings related to the method used to read the time code from the deck in SDI DV mode (during DV encoding). LCD Display Setting Description...
  • Page 33 Basic Instructions Basic Instructions Basic Instructions Basic Instructions Basic Instructions 22-2 encode line 2 Sets line (line 2), at which to insert DVITC in SDI output, in SDI mode (during DV decoding). Setting Description Line selection NTSC: 10 to 20 (Factory default: 16) PAL: 6 to 22 (Factory default: 21)
  • Page 34 33 ext. sync conf. Lets you set the amount to increase/decrease (in unit of 37 nano- seconds) the ADVC-1000 video output delay relative to the exter- nal sync input. * Pressing the ENTER key switches the screen to the mode for editing the value.

  • Page 35: Audio Delay

    34 audio delay Lets you set the amount to increase/decrease (in milliseconds) the ADVC-1000 audio output delay relative to the video output, when an external sync is enabled. * Pressing the ENTER key switches the screen to the mode for editing the value.
  • Page 36 Basic Instructions Basic Instructions Basic Instructions Basic Instructions Basic Instructions 42 local disable Lets you enable or disable the Mode switch. LCD Display Setting Description Permits operation mode switching by front panel controls. (Factory default) Prohibits operation mode switching by front panel controls.
  • Page 37 Lets you enable or disable the SDI output jitter reduction function. Info LCD Display Inputting nonstandard signal may cause abnormal SDI outputs and analog monitor video outputs exceeding the ADVC-1000’s jitter attenuation function tolerance Setting Description limit. (The relevant error is Disables jitter attenuation function.
  • Page 38 Basic Instructions 63 cycle master Lets you enable or disable cycle master acquisition. Info If this menu is set to off, you can LCD Display connect ADVC-1000 units each other using IEEE1394 cable. Setting Description Acquires cycle master. (Factory default)
  • Page 39 Basic Instructions Basic Instructions Basic Instructions Basic Instructions Basic Instructions 66 data rate cap. Lets you set the maximum communication speed of the "dr cap" Info field of "iMPR/oMPR" at the time of booting and setting change. When the hardware is used with the DIP switch SW1 (PHY SPEED, LCD Display see p.15) set to ON (S200), please...

  • Page 40: Specifications

    Supplementar Supplementar Supplementary y y y y Supplementar Supplementar 2-4 Specifications 2-4 Specifications 2-4 Specifications 2-4 Specifications 2-4 Specifications...

  • Page 41: Outputting Component Signals (Optional)

    Outputting Component signals (optional) Outputting Component signals (optional) Outputting Component signals (optional) When you connect the ADVC-1000 with the conversion cable (optional), component signal can be output. (Functions exclusively) For questions regarding the conversion cable, please contact your local Grass Valley office, distributor or the store that you have pur- chased this product.
  • Page 42 memo memo...
  • Page 43 memo memo...
  • Page 44 memo memo...
