Page 1: User Manual
MAX1301/MAX1301-TV USER MANUAL CREATOR Electronics MAX1301/MAX1301-TV SCALER SWITCHER USER MANUAL Please read this manual carefully before using the system... -
Page 2: Table Of Contents
MAX1301/MAX1301-TV USER MANUAL Content table 1.Function............................5 2.Connection..........................5 3.Front Panel..........................6 4.Real Panel........................... 6 5.Description for Video part ......................7 6.Description for S-Video part ..................... 7 7.TV Function Guide........................7 8.Problems solving & Maintenance ..................12... - Page 3 The TV function of MAX1301-TV is only for Chinese market for temporary. All product function is valid till 2006-6-30...
-
Page 4: Operation Notice
MAX1301/MAX1301-TV USER MANUAL Operation Notice Equipment In order to ensure the credibility use of the product and the user’s safety, please comply with the following items during installation and maintenance: The system must be earthed properly. Please do not use two blades plugs and ensure the alternating power supply ranged from 100v to 240v and from 50Hz to 60Hz. -
Page 5: Function
MAX1301/MAX1301-TV USER MANUAL 1.Function MAX1301/MAX1301-TV is a scale switcher designed for multi-signal processing, signals of Composite VIDEO, S-VIDEO, VGA, TV and microphone can be scaled to high-resolution VGA format and switched out. CVBS composite video, and S-Video can be switched to VGA signals with following... -
Page 6: Front Panel
MAX1301/MAX1301-TV USER MANUAL 3.Front Panel ①LCD displayer ②Signal Source selection, working with ④ to select the input Signal Source (VGA, Composite Video, S-Video ,TV etc.) VGA Signal: Mainly for PC or NOTEBOOK Composite Video: CVBS, such as DVD，VCD，VCR ,etc. S-Video: super DVD, VCD or video card, etc. -
Page 7: Description For Video Part
MAX1301/MAX1301-TV USER MANUAL 5.Description for Video part Press Video for 3 seconds under Video mode to enter the setting mode. 5.1 function_1: 1 CV brightness, brightness adjustment, work with parameter+, parameter_. 5.2 function_2: 2 CV Contrast, Contrast adjustment, work with parameter+, parameter_. - Page 8 MAX1301/MAX1301-TV USER MANUAL ＿ 2.1 FUNCTION 1: AUTO SEARCH CHANNEL : Search all TV channels and save them. Press ENTER again to start this function, after which press ENTER again to start manual operation, at this time, channels found will also be saved and covered the original ones.
- Page 9 MAX1301/MAX1301-TV USER MANUAL Please select the right system before searching. PARAMETER±: Parameters up/down, this function should be used with the options of FUNCTION, keep pressing it to up/down continuously, PARAMETER± is defaulted to relate with channel frequency when the front panel is under TV mode.
- Page 10 MAX1301/MAX1301-TV USER MANUAL Contrast adjustment key used together with Color adjustment key used together with Restore luminance, contrast, color to default value. This key should be used with . Press once to enter this function, than press again to start this function.
- Page 11 MAX1301/MAX1301-TV USER MANUAL 03*01! VGA3 with audio switch out 04*01! VGA4 with audio switch out 05*01! S-Video 1 with audio switch out 06*01! S-Video 2 with audio switch out 07*01! S-Video 3 with audio switch out 08*01! S-Video 4 with audio switch out...
-
Page 12: Problems Solving & Maintenance
MAX1301/MAX1301-TV USER MANUAL 06#07! TV frequency -- a unit. 07#07! Select the TV standard: CHINA (PAL D/K) 08#07! Select the TV standard: (NTSC M/N ) 09#07! Select the TV standard: ITALY (PAL B/G) 10#07! Select the TV standard: HONG KONG...
