- Page 1 Feel Design User Guide User Guide User Guide Instruction manual Instruction manual Instruction manual MEDIADISK MEDIADISK LX Series LX Series...
-
Page 2: Table Of Contents
USER GUIDE 1. SAFETY AND OTHER INSTRUCTIONS............1 2.REMARKS..................... 2 3. PRODUCT PERFORMANCES..............2 4. ACCESSORIES.................... 3 5. PRODUCT USE.................... 5 6. SYSTEM SETUP ..................8 7.FAQ ....................... 9 8.OTHER INSTRUCTIONS ................9... -
Page 3: Safety And Other Instructions
1. SAFETY AND OTHER INSTRUCTIONS Please use Mediadisk LX Series carefully and read following instructions. >>> Copyright >>> Water / Moisture Software, audio, video or any intellectual Do not contact the MEDIADISK LX SERIES properties are protected by copyright and with water or liquid. -
Page 4: Remarks
3.Video: MPEG-1（AVI，MPG），DAT， MPEG-2 (AVI, MPG,VOB)，MPEG-4(AVI, XviD) 4. Image: JPEG, JPG Compatible USB host : when Mediadisk LX Series is connected to a PC, The USB host is deactivated. Output Mode: Composite video + L&R audio channels, HDMI, interlaced scan video component and Digital coaxial output. -
Page 5: Accessories
4. ACCESSORIES N° Item Quantity HD Media Player Remote Control AV Cable Power cable USB Cable Power Adapter Screws several Quick Starter Guide Battery - 3 -... - Page 6 Remote Control functions : Function POWER Turns the unit on/off MUTE Turns the sound on/off SETUP Opens configuration menu ZOOM Zoom on images MODE While watching slides, this function changes the transition mode between photos. When playing music, it changes the pre-equalized modes. ANGLE Rotates images.
-
Page 7: Product Use
5. PRODUCT USE 5.1 Device Connection Connect the device as indicated in the pictures, switch on the power and follow these steps: 1. AV(CVBS) mode: press INPUT CHOICE key of the TV, and turn to AV INPUT MODE. If no image appears, press VIDEO key of the Media player remote control and wait for a few seconds until it turns to CVBS mode, then menu appears on TV. - Page 8 3. HDMI output mode: press VIDEO button on remote control of media player to choose the HDMI output mode. The menu then appears on the TV. HDMI Output 4. Coaxial output mode: Connect the product to external device with coaxial input through coaxial cable.
- Page 9 “MEMUP” to the e:\MEMUP folder from DVD disc or the HD. c. Unplug the USB cable. Connect AV cable to the TV. d. Enter the file manager and select “MEMUP” folder. Press the DVD PLAY button to start it playing.
-
Page 10: System Setup
For the first usage, put power on Mediadisk LX Series and connect it to computer by a USB cable. The installation process will be initialized on the computer. Once finished, a green arrow will appear right below on the system tray. -
Page 11: Faq
7. FAQ (FREQUENTLY ASKED QUESTIONS) Q： When connecting the new device to the system, there is no disk icon but the green icon appears. A： It may because the device is not correctly formatted, so go ahead and format it. Q: The portable hard disk works fine under Windows 2000 / Windows XP operation system, but not with Windows 98 system.
