Interface Module
for selected BMW/Mini Cooper vehicles
Installation & Operation
Serial Number:
Date of Purchase:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iPod Interface Module and is the answer not in the manual?

Questions and answers

Related Manuals for Rockford Fosgate iPod Interface Module

Summary of Contents for Rockford Fosgate iPod Interface Module

  • Page 1 ® Interface Module for selected BMW/Mini Cooper vehicles Installation & Operation Serial Number: Date of Purchase:...

  • Page 2: Table Of Contents

    Warranty ..............11 Introduction and Precautions Thank you for purchasing the Rockford Fosgate Interface Module for iPod. The Interface Module was designed and manufactured to seamlessly integrate with your vehicle’s factory system. To get the best performance from this device, read this manual before doing any type of installation.

  • Page 3: Supported Ipod Models

    Supported iPod Models iPod Firmware For proper operation of the interface module, ensure your iPod is updated with the latest fi rmware. Free updates can be downloaded from http:/www.apple.com/ipod/ download/. The directions on the site will guide you through the update process.

  • Page 4: Pre-System Setup

    Pre-System Setup Interface Module DIP Switch Settings Proper identifi cation of your system and correct setting of the DIP switches will ensure the interface module operates properly when installed. Interface Module iPod DIP Switch Positions Switch Switch NOTE: If you change the positions of the DIP switches after the module is installed, turn off the vehicle ignition, disconnect the ‘Vehicle Harness’...

  • Page 5: Installation

    Installation It is recommended that installation only be performed by a qualifi ed professional. Beware of sharp edges to avoid injury and exercise caution when removing trims as they may break. The module should be placed at an accessible location to allow an AUX cable to be connected, such as in the glove box, the center console or under the front seat.

  • Page 6: Operation

    Installation 10. Route the remainder of the interface harness in the best possible manner (e.g. under the door sill or under the drivers seat) and connect it to the Vehicle connector on the interface module. NOTE: When routing harnesses or cables, ensure they are secured away from sharp edges and moving parts by the use of cable ties.

  • Page 7: Operating Controls

    Operation iPod Hierarchy Playlist By default, the interface creates a Playlist having a name that is the same as the name of the iPod. This Playlist is the very fi rst on the list of Artist Playlists shown while browsing in Playlist mode. This Playlist contains all Album the songs on the iPod.
  • Page 8 Operation Mode Selection – Browsing Interface Module set to ˝Radio˝ Once the iPod is connected and selected as the audio source, you can browse through the modes by selecting the appropriate DISC button. Change Tracks within that mode by pressing the TRACK button (depending on model, the Jog Dial can be rotated for this function).

  • Page 9: Auxiliary Audio Source

    Auxiliary Audio Source Connecting The interface is equipped with a 1/8” AUX jack input to connect an auxiliary device, such as an MP3 player, DVD player or other audio source. NOTE: We recommend to only connect to the interface module when the vehicle ignition is turned off.

  • Page 10: Troubleshooting

    Troubleshooting Problem Solution Check DIP switch settings (refer to Cannot select the interface. Pre-System Setup). With the ignition OFF disconnect vehicle harness from module for one (1) minute and reconnect. Verify that the correct button is used to access the interface. Select DISC 5 and ensure it is set Radio/NAV display only shows DISC to Track 01.

  • Page 11: Warranty

    Warranty The Rockford Fosgate iPod Interface Module has a warranty of 1 Year. This warranty covers only the original purchaser of Rockford product purchased from an Authorized Rockford Fosgate Dealer in the United States. In order to receive service, the purchaser must provide Rockford with a copy of the receipt stating the customer name, dealer name, product purchased and date of purchase.
  • Page 12 Rockford Fosgate Rockford Corporation 600 South Rockford Drive Tempe, Arizona 85281 U.S.A. In U.S.A., 480-967-3565 Customer Service 1-800-669-9899 12/08 B.M. 1230-55530-01 Printed in U.S.A...
