Outlaw OSB-1 Quick Start Manual

1
What's in the Box?
1 OSB-1 Outlaw Sound Bar
1 Mounting Template
2
Where should you locate your sound bar?
The OSB-1 can be used as a set-top or shelf-mounted speaker. Self-adhesive
rubber feet are included to prevent vibration, protect the mounting surface
and serve to angle the speaker up or down if needed.
Side view
Use the 4 Small
round rubber spacers
for level placement
Adhesive side
Use taller feet for up or down tilt
OSB-1 Outlaw Sound Bar
Quick Start Guide
For cabinet or shelf mount-
ing, orient the speaker with
Control Pod on the top.
Rubber feet
Use the 2 large rect-
angular feet with 2
of the small round
rubber spacers for
angled placement
Instruction Manual 2 tall feet
AC Power Supply
1 Optical Cable
You may also simply mount the speaker to the wall using the built-in keyhole
brackets or attach it to a suitably equipped articulating flat-panel TV wall
mount via the threaded inserts on the rear panel of the OSB-1.
Side view
Adhesive side
OSB-1 rear
16" (406mm)
24VDC 4A IR IN
9
4 short feet Remote Control
(with battery)
Power Supply Cable
Inverse Control Panel Label
SPEECH
BASS
SOURCE MODE S1 IN
TREBLE
For wall mounting (or
mounting on a TV bracket),
orient the speaker with
Control Pod on the bottom
Use 2 of the small
round rubber spacers
to isolate the speaker
from the wall
Rubber foot
S2 IN S3 IN S4 IN S5 IN analog SUB OUT ON/OFF
digital L R
optical
coaxial
4 ⁄ "
15
16
(125mm)
⁄ " (251mm)
7
8
MUTE
MODE
SOURCE SPEECH
•2-CHANNEL
•3-CHANNEL
•5-CHANNEL
•5-EXPANDED
BASS TREBLE
VOLUME
