LG ARNU073CEA2 Specifications

Job Name/Location:
Date:
PO No.:
Architect:
Engr:
Rep:
(Company)
ARNU073CEA2
Multi V™ Floor Standing (with case)
7,500 Btu/h Indoor Unit
Performance:
Total Cooling Capacity (Btu/h)
Heating Capacity (Btu/h)
Power Input¹ (W)
Cooling Nominal Test Conditions:
Indoor: 80°F DB/67°F WB
Outdoor: 95°F DB
Electrical:
Power Supply (V/Hz/Ø)
Rated Amps (A)
Piping:
Refrigerant:
Liquid Line (in, OD)
Vapor Line (in, OD)
Condensate:
Condensate Line (in, OD)
Factory Installed Pump
Controls Features:
•Auto changeover
(Heat Recovery only)
•Auto opera on
•Auto restart
•Child lock
•Dual thermistor control
•Group control
•E.S.P. control
Optional Accessories:
Wireless Handheld Remote Controller (PQWRHDF0)
7‐Day Programmable Controller (PQRCUSA)
Simple Controller with Mode (PQRCUCS0C)
Simple Controller without Mode (PQRCFCS0C)
Dry Contact Unit (PQDSB1, PQDSBC)
Wall Mounted Temperature Sensor (PQRSTA0)
LG Electronics USA, Inc. 1000 Sylvan Ave, Englewood Cliffs, NJ 07632/www.lg‐vrf.com
For continual product development, LG reserves the right to change specifications without notice.
For:
File
Approval
GC:
Mech:
(Project Manager)
7,500
8,500
30
Heating Nominal Test Conditions:
Indoor: 70°F DB
Outdoor: 47°F DB/43°F WB
208‐230/60/1
0.1
1/4 Flare
1/2 Flare
3/4
No
•Hot start
•Self diagnos cs
•Sleep mode
•Timer (on/off)
•Weekly schedule
•So dry (dehumidifica on)
•Fan speed control
²
Tag #:
Resubmit
Other
Entering Mixed Air:
Cooling Max³ (°F WB)
Heating Min (°F DB)
Unit Data:
Refrigerant Type
Refrigerant Control
Sound Pressure⁴ dB(A) (H/M/L)
Filter
Net Unit Weight (lbs)
Shipping Weight (lbs)
Fan:
Type
Quantity
Motor/Drive
Airflow Rate H/M/L (CFM)
Standard Features:
•Limited Warranty with LG Cer fied Installa on
•Two Year Functional Parts Warranty
Notes:
1.The Power Input is rated at high speed.
2.Requires a 7‐Day programmable controller.
3.See Engineering Manual for sensible and latent capaci es.
4.Sound Pressure levels are tested in an anechoic chamber under ISO Standard 1996.
5.All communica on cable to be minimum 18 AWG, 2‐conductor, stranded, shielded and must
comply with applicable local and national code.
6.Power wiring cable size must comply with the applicable local and na onal code.
7.This unit comes with a dry nitrogen charge.
8.This data is rated 0 above sea level, with 25 of refrigerant line per indoor unit and a 0
level difference between outdoor and indoor units. All capacities are net with a combination ratio
between 95 – 105%.
9.Must follow installa on instruc ons in the applicable LG installa on manual.
R410A
35/33/31
Washable Pre‐filter
Sirocco
Brushless Digitally Controlled/Direct
300/265/229
VRF‐SB‐DL‐001‐US 011H15 Page 1 of 2
76
59
EEV
60
69
1
