Summary of Contents for MULTIQUIP Mikasa Series MVH306GH
Page 1
OPERATION AND PARTS MANUAL SERIES MODEL MVH306GH REVERSIBLE PLATE COMPACTOR (HONDA GX270K1SMX2 GASOLINE ENGINE) Revision #8 (01/31/14) To find the latest revision of this publication, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
, 2006 Order via Internet (Dealers Only) Best Deal! If you have an MQ Account, to obtain a Username Order parts on-line using Multiquip’s SmartEquip website! and Password, E-mail us at: parts@multiquip. ■ View Parts Diagrams com. ■ Order Parts To obtain an MQ Account, contact your ■...
SAFETY INFORMATION Do not operate or service the equipment before reading Potential hazards associated with the operation of this the entire manual. Safety precautions should be followed equipment will be referenced with hazard symbols which at all times when operating this equipment. may appear throughout this manual in conjunction with Failure to read and understand the safety safety messages.
Page 7
NEVER use accessories or attachments that are not NEVER operate this equipment when not recommended by Multiquip for this equipment. Damage feeling well due to fatigue, illness or when to the equipment and/or injury to user may result.
Page 8
SAFETY INFORMATION COMPACTOR SAFETY WARNING DANGER DO NOT place hands or fingers inside engine compartment when engine is running. NEVER operate the equipment in an explosive atmosphere or near combustible materials. An NEVER operate the engine with heat shields or explosion or fire could result causing severe guards removed.
Page 9
SAFETY INFORMATION FUEL SAFETY BATTERY SAFETY (ELECTRIC START ONLY) DANGER DANGER DO NOT add fuel to equipment if it is placed inside truck DO NOT drop the battery. There is a possibility that the bed with plastic liner. Possibility exists of explosion or battery will explode.
Page 10
SAFETY INFORMATION TRANSPORTING SAFETY CAUTION NEVER allow any person or animal to stand underneath the equipment while lifting. NOTICE Before lifting, make sure that the equipment parts (hook and vibration insulator) are not damaged and screws are not loose or missing. Always make sure crane or lifitng device has been properly secured to the lifting bail (hook) of the equipment.
DIMENSIONS Figure 3. MVH306GH Reversible Plate Compactor Dimensions . n i . n i PAGE 12 — MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14)
GENERAL INFORMATION Plate Compactor Frequency/Speed The Mikasa MVH306GH is a walk behind, reversible plate The compactor's vibrating plate maximum frequency is 4400 compactor designed for the compaction of sand, clay and vpm (vibrations per minute). The forward and reverse travel speed asphalt.
COMPONENTS Figure 4. MVH306GH Reversible Plate Compactor Components Figure 4 illustrates the location of the major components for the Belt Cover – Remove this cover to gain access to the V- MVH306GH Reversible Plate Compactor. The function of each belts. NEVER run the compactor without the V-belt cover. If component is described below: the V-belt cover is not installed, the possibility exist that Hand Grip –...
BASIC ENGINE Figure 5. Honda GX270 Engine Components INITIAL SERVICING The engine (Figure 5) must be checked for proper lubrication and Choke Lever – Used in the starting of a cold engine, or in filled with fuel prior to operation. Refer to the manufacturers engine cold weather conditions.
INSPECTION CAUTION 4. If the oil level is low (Figure 7), fill to the edge of the oil filler hole with the recommended oil type (Table 4). Maximum oil NEVER operate the compactor in a capacity is 1.16 quarts (1.10 liters). confined area or enclosed area structure that does not provide ample free flow of air .
Page 17
INSPECTION CAUTION DANGER DO NOT overfill hydraulic oil tank. This could cause oil EXPLOSIVE FUEL! leaks and sluggish operation. Clean cap and surrounding Motor fuels are highly flammable and can area before opening to prevent dirt from entering oil tank. be dangerous if mishandled.
OPERATION CAUTION DO NOT attempt to operate the compactor until the Safety, General Information and Inspection sections of this manual have been read and thoroughly understood . This section is intended to assist the operator with the initial Figure 13. Handle Adjustment start-up of the compactor.
Page 19
OPERATION 3. Place the choke lever (Figure 16) in the " OPEN " position if starting a cold engine. Figure 19. Starter Grip 7. If the engine has started, slowly return the choke lever (Figure 17) to the CLOSED position. If the engine has not started repeat steps 1 through 6.
Page 20
OPERATION 3. To make the compactor move in the forward direction push the travel lever ( Figure 21) forward. Figure 23. Engine ON/OFF Switch (OFF) Figure 21. Travel Lever 4. To make the compactor move in the reverse direction pull the travel lever ( Figure 21) backwards.
MAINTENANCE Inspection and other services should always be carried out on NOTICE hard and level ground with the engine shut down. Fuel piping and connections should be replaced every 2 years. Inspection and Maintenance Service Tables. 1. To make sure your plate compactor is always in good working condition before using, carry out the maintenance inspection in accordance with Tables 5 through 7.
Page 22
MAINTENANCE Air Filter Spark Plug 1. Remove and clean the spark plug (Figure 26). 1. Remove the air cleaner cover and foam filter element as shown in Figure 28. 2. Adjust the spark gap to 0.028 ~0.031 inch (0.6~0.7 mm). This unit has electronic ignition, which requires no adjustments.
Page 23
MAINTENANCE Vibrator Oil Level Check Checking and Replacing the V-Belt and Clutch 1. After 200 hours of operation, remove the belt cover to check NOTICE the V-belt tension (Figure 30). Tension is proper if the belt Always clean the area around the vibrator oil level check plug bends about 3/8”(10 mm) when depressed strongly with before removing oil check plug.
Page 24
MAINTENANCE CAUTION Make sure hydraulic oil is at a normal safe operating level. DO NOT over fill. Over filling (excessive oil) will cause excess oil to blow out of breather plug. 3. Loosen bleeder plug located at top of hydraulic cylinder on side of vibrator (Figure 35).
TROUBLESHOOTING diagnosis based on the Engine Troubleshooting (Table 8) Practically all breakdowns can be prevented by proper handling and maintenance inspections, but in the event of a information shown below. If the problem cannot be remedied, please leave the unit just as it is and consult our company's breakdown, please take a remedial action following the business office or service plant.
Page 26
MVH306GH—TROUBLESHOOTING TROUBLESHOOTING r i A r i a e l c o l f s u j , t n - e r d l i l e v . r o " " r e i s s i f s i .
TROUBLESHOOTING MVH306GH—TROUBLESHOOTING diagnosis based on the Compactor Troubleshooting (Table 9) Practically all breakdowns can be prevented by proper information shown below. If the problem cannot be remedied, handling and maintenance inspections, but in the event of a please leave the unit just as it is and consult our company's breakdown, please take a remedial action following the business office or service plant.
A blank entry generally indicates that the item is not sold assembly/kit that can be purchased, or is not available separately or is not sold by Multiquip. Other entries will for sale through Multiquip. be clarified in the “Remarks” Column.
NAMEPLATE AND DECALS NAMEPLATE AND DECALS Shell Tellus Oil Shell Tellus Oil NPA-748 OPERATIONAL CAUTION Do not move travel lever if engine stops NPA-1106 V BELT HDPF-5370 NPA-537 J 0PERATIONAL CAUTION Prior to OPERATION, check the engine oil and fuel levels. If not enough, add to proper levels. Warm up engine at low speed for 3-5 minutes.
Page 31
NAMEPLATE AND DECALS NAMEPLATE AND DECALS PART NO. PART NAME QTY. REMARKS 920201950 DECAL: OIL SAE 10W-30 ......1..NPA-195 920110370 DECAL: MODEL LOGO 920209620 DECAL: CAUTION ........1..NPA-962 920207480 DECAL: SHELL TELLUS OIL 46 ....1..NPA-748 920204580 DECAL: FULL THROTTLE ......
BASE AND ENGINE ASSY. BASE AND ENGINE ASSY. PAGE 34 — MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14)
Page 35
BASE AND ENGINE ASSY. BASE & ENGINE ASSY. PART NO. PART NAME QTY. REMARKS 464117850 BASE 912227003 ENGINE ASSY., GX270K1SMX2 (HONDA) 0105051045 BOLT 10X45 T 030210250 WASHER, LOCK M10 031110160 WASHER, FLAT M10 464216580 BELT COVER (IN) 001121025 BOLT 8X25 T 030210250 WASHER, LOCK M10 031110160...
Page 36
MVH306GH — BASE AND ENGINE ASSY. (CONTINUED) BASE AND ENGINE ASSY. BASE AND ENGINE ASSY. (CONTINUED) PAGE 36 — MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14)
Page 37
MVH306GH — BASE AND ENGINE ASSY. (CONTINUED) BASE AND ENGINE ASSY. BASE AND ENGINE ASSY. (CONTINUED) PART NO. PART NAME QTY. REMARKS 459010060 UNION TIP, DRAIN 459010070 DRAIN HOSE 459010090 HOSE BAND 459010080 GASKET(OIL DRAIN) 0401140030 PLUG 464457380 DRAIN JOINT 014208020 BOLT 8X20 T 030208200...
HAND PUMP ASSY. HAND PUMP ASSY. O-RING PAGE 44 — MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14)
Page 45
HAND PUMP ASSY. HAND PUMP ASSY. PART NO. PART NAME QTY. REMARKS 4649-10040 ACCUMLATOR 464910080 O-RING DUST,SEAL,SET ......1 ..... INCLUDES ITEMS W/# 464010040 CONTROL SHAFT 464010050 BUSH 464010060 464010070 STOPPER 099205005 SOCKET HEAD SCREW 5X5 T 464010080 PLUG 464010090 PIN,STOPPER 464010100 PLUG 458010080...
GX270K1SMX2 — CONTROL ASSY. CONTROL ASSY. PAGE 52 — MVH306GH PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #8 (01/31/14)
Page 53
GX270K1SMX2 — CONTROL ASSY. CONTROL ASSY. PART NO. PART NAME QTY. REMARKS 16551ZE2000 ARM, GOVERNOR 16555ZE2000 ROD, GOVERNOR 16561ZE2000 SPRING, GOVERNOR 16562ZE2000 SPRING, THROTTLE RETURN 16570ZE2W10 CONTROL ASSY.(REMOTE) ..... 1 ...... INCLUDES ITEM W/ 16571ZE2W00 LEVER, CONTROL 16574ZE1000 LEVER SPRING 16575ZE2W00 WASHER,CONTROL LEVER 16576891000...
