REVERSE OSMOSIS SYSTEM
LUX-106UV-P
USER'S MANUAL
01
02
03
04
05
06
07
08
09
10
11
13
14
15
Thank you very much for selecting Pure-Pro Water Corp.
In order to bring the best use of your system, please read
the user's manual carefully before installation and follow
the regulations.
URE
DRINKING WATER SYSTEM
Introduction of LUX-106UV-P
What is reverse osmosis
Components & Selected filters
The parts of LUX-106UV-P
Cartridge filters
Ultraviolet Water Sterilizer
Tubing connection diagram
Installation diagram
Change filters
Change membrane
Operation regulation
FAQ
Maintenance checking list
Memo
Advertisement
Table of Contents
Related Manuals for PurePro LUX-106UV-P
Summary of Contents for PurePro LUX-106UV-P
- Page 1 DRINKING WATER SYSTEM REVERSE OSMOSIS SYSTEM LUX-106UV-P USER'S MANUAL Introduction of LUX-106UV-P What is reverse osmosis Components & Selected filters The parts of LUX-106UV-P Cartridge filters Ultraviolet Water Sterilizer Tubing connection diagram Installation diagram Change filters Change membrane Operation regulation...
-
Page 2: Specifications
New Euro-Luxury faucet - supreme quality with elegant design. Feed water connector. Drain Saddle Valve. Four Color Coded 1/4 inch Tubing for System Connection. Completely Assembled. PurePro label with USA Flag. 100% Factory Tested and Sterilized Ready for Installation. Installation Instruction. ¨Specifications Membrane: 100 GPD / 378 LPD... -
Page 3: What Is Reverse Osmosis
What is reverse osmosis Reverse osmosis was originally designed to make sea water drinkable for the navy. It is ideal for anyone on a low sodium diet. An R.O. membrane has a pore size much smaller than bacteria virus, or the cryptosporidium parasite. When functioning properly it will remove all microorganisms from tap water and produce sterile water. -
Page 4: Components & Selected Filters
Components & Selected filters ¨Components New Euro-Luxury faucet 3.2G water storage tank Housing wrench Deliver-valve Water supply connector Drain saddle Tank ball shut-off valve Tubing ¨Selected filters Alkaline Mineral Alkaline filter Mineral filter Infra-Red Infra-Red filter Luxury pump RO system DRINKING WATER SYSTEM... -
Page 5: The Parts Of Lux-106Uv-P
The parts of LUX-106UV-P UV water sterilizer Post carbon filter To the faucet To the tank RO membrane housing Input water The 3rd stage housing The 1st stage housing The 2nd stage housing Front view Flow restrictor Auto shut-off valve... -
Page 6: Cartridge Filters
Cartridge filters Cartridge Filters Filter Description Service Life Stage 1 6 Months This 5micron sediment filter is made of 100% pure polypropylene fibers. High capacity filter 5 Micron removes dusts, particles and rusts. Sediment Filter Stage 2 This block carbon filter is composed of high- 6 Months performance carbon that removes free chlorine, Block Carbon Filter... -
Page 7: Ultraviolet Water Sterilizer
Ultraviolet Water Sterilizer stainless steel 1gpm uv system The knack of 1gpm PUREPRO UV system lies in employing the 254nm ultraviolet rays (UV-C) to caused immediate death for organisms or wipe out their ability to survive and reproduce. Install UV lamp : 1. -
Page 8: Tubing Connection Diagram
Tubing connection diagram CONNECTING THE COLOR TUBING: A. Connect the WHITE tubing to the water supply connector. B. Connect the BLUE tubing to the sink top faucet. C. Connect the BLACK tubing to the drain saddle. D. Connect the RED tubing to the storage tank. Faucet Tank Drain... -
Page 9: Installation Diagram
Installation diagram Input water : Install water tank : Tank ball shut- off valve Water supply connector To RO system Hand tighten To RO system plastic shut-off valve to tank. Then connect color tubing. To water source pipe Deliver valve Install faucet : Install drain saddle : Faucet... -
Page 10: Change Filters
Change filters Prepare a housing Turn off water Switch off water tank. wrench. source. To RO system FULL FLUSH PROCESS SOURCE POWER Micro Computer Controller Unplug electricity. Open housings clockwise with a wrench. Put the replacement filters in the Drain out 1 Gallon of water to housings and double O' ring. -
Page 11: Change Membrane
Change membrane Unplug electricity. Turn off water source. Switch off water tank. To RO system Loose the Jaco fitting anticlockwise. Remove the membrane housing cap anticlockwise. Jaco Remove the membrane by a pincer. Install the membrane by carefully pushing the spigot end into the socket at the far end of the housing until completely in. -
Page 12: Operation Regulation
Operation regulation Plug in electricity. Turn on water source. To RO system Switch on water tank. Pump starts to function. Pump Let the water run for at least 30 minutes. This flushes the carbon filters on first time use. Luxury pump RO system DRINKING WATER SYSTEM... - Page 13 Operation regulation A.With everything connected, turn on the water check for leaks. B.Make sure the storage tank shut-off valve is "OFF". Open the sink top faucet. C.Within a few minutes (up to 15) the water will start to run from the faucet slowly.
- Page 14 Q: What does the PurePro series drinking water taste like? The taste of the PurePro water depends on the amount of contaminants in the tap water originally. If 95% of dissolved minerals and chemicals are removed, the R.O.
-
Page 15: Maintenance Checking List
Maintenance checking list Filters 1st stage 2nd stage 3rd stage 4th stage 5th stage 6th stage Date Luxury pump RO system DRINKING WATER SYSTEM... - Page 16 Memo Type of product Date of purchase Name Address Luxury pump RO system DRINKING WATER SYSTEM...
