- Page 2 Twist and Stow Rudder Replacement Use the following instructions to replace your twist and stow rudder. To remove the rudder that is cur- rently on the boat, bend and pull the cotter pins that are at the bottom of the rudder pin and push the pin out of the top.
- Page 3 4. WIth the line already passed though the housing, pick up the rudder section and feed the line though the upper most hole located along the circular drum. You will notice two Phillips heads screws very close to one another. Loosen the screws a few turns and pull the line up and around the forward most Phillips head screw and tighten it down.
- Page 4 8. Now you are ready to trim the up/down control. With the rudder in the down position, loosed the forward most screw to free up the down control line. By pulling on this line, you will stretch the Bungee cord in the hull (you may need to pull a little on the down control line exposed on the deck to help you stretch the Bungee).
