Technical Specification
Specifications:
Physical
1U 19" Rack Mount
Power
External: 24 VDC @ 325 mA
POE: 802.3af, class 3
Networking
10/100 Mbps Ethernet port
Manual or Dynamic Host Configuration Protocol
(DHCP) IP address setup.
Time and date synchronization using NTP
Protocols
IETF SIP (RFC3261)
IETF IGMP version 3 (RFC3376)
IETF RTP (RFC1889)
IETF RFC2833
Digest Authentication
Audio Specifications
Local Music Source Input Impedance: 8 to 600 Ohms
Local Music Input Level: -10dBm nominal
Output Impedance: 50 Ohms
Output Level: - 10dBm nominal
Relay Specifications
Relay Current: 1 AMP @ 24VDC
Valcom, Inc.
5614 Hollins Road Roanoke, Virginia 24019 Phone: 540-563-2000 Fax: 540-362-9800
E-Mail: info@valcom.com
SIP PAGING SERVER
Environment
Temperature: 0 to +40° C
Humidity: 0 to 85% non-precipitating
Feature Highlights
1 Audio Analog Outputs
2 Form C relay closures
8 SIP Identities (Station Mode)
100 SIP Identities (Trunk Mode)
Programmable Feedback elimination
Audio supervision
Night Ring
DIMENSIONS AND WEIGHT
DIMENSIONS:
1.75 "H x 16.6 "W x 5.4 "D (4.445 cm x 42.164 cm x 13.716 cm)
Weight: 4.65 lbs. (2.10 kg)
Shipping Weight: 6.5 lbs (2.925 kg)
www.valcom.com
MODEL VIP-201
REV.308
4
