Summary of Contents for Rosewill Striker RK-6000
-
Page 2: Table Of Contents
RK-6000 User Manual Contents ..........................2 PACKAGE CONTENTS ......................... 2 SYSTEM REQUIREMENTS ..............................2 FEATURES ............................... 2 WARRANTY ..........................2 TECHNICAL SUPPORT ..................2 HARDWARE AND SOFTWARE INSTALLATION ....................3 SOFTWARE INSTALLATION VERIFICATION ........................4 KEYBOARD CUSTOMIZATION UI CONFIGURATION GUIDE ........................4 .............................. -
Page 3: Package Contents
APC White switch Programmable Keys via software interface WARRANTY Please register your keyboard at Rosewill.com This keyboard comes with a 1 year limited warranty. TECHNICAL SUPPORT Please contact our Customer Service about any issues related to this keyboard. -
Page 4: Software Installation Verification
RK-6000 User Manual ※Please do not connect keyboard to any other USB ports after installation of drivers and application. If connecting to any other USB ports, re-installation of software may be needed. SOFTWARE INSTALLATION VERIFICATION To verify installation is complete, use Device Manager Please right click the “My Computer”... -
Page 5: Keyboard Customization
RK-6000 User Manual KEYBOARD CUSTOMIZATION APPLICATION USER INTERFACE (UI) OVERVIEW The picture below shows the main interface that allows you to customize key functions. UI CONFIGURATION GUIDE UI main interface includes up to 10 profiles. Each Profile contains 3 Layers. Each Layer is classified by colors. -
Page 6: Advanced
RK-6000 User Manual After a key has successfully been configured, the key will be surrounded by a silver frame to distinguish it from a non-programmed key Clicking on the “?” icon will open the manual Clicking the “Reset Layer” icon will reset the current Layer to default settings. A dialogue window will pop up to confirm you wish to proceed. -
Page 7: Custom Personal Quick Switch Key Combination
RK-6000 User Manual However, if you prefer a different key combination to enable Quick Switch, click on the Custom Personal Quick Switch field to bring up the below pop up window. Customize Personal Quick Switch Key Combination Users can choose to use Shift, Ctrl, Alt or any alphabet keys to customize personal quick switch. To avoid key conflict, please be sure to use key combinations that are not already in use within Windows or your selected application. -
Page 8: Profile Selection
RK-6000 User Manual PROFILE SELECTION To modify current settings, please click “PROFILE SELECTION” to activate panel and choose profile from list. After modification complete, please click “OK” or “Apply” to execute. Otherwise, please click “Cancel” to undo the changes. Profiles can be Imported or Exported. -
Page 9: Linked Application
RK-6000 User Manual Linked Application Allows you to execute profiles or activate “Auto Switch”. Linking an Application 1. Double left click on the blank space within the Linked Application column associated to the Profile you wish to edit to open up the window to choose your selected application to link. -
Page 10: Key Assignments
RK-6000 User Manual KEY ASSIGNMENTS Single Key This will a llow users to swap the input of a single key when pressed. One key press = one key output. You will receive an error if you try to have a single key press have multiple outputs similar to below. -
Page 11: Macro
RK-6000 User Manual Macro This allows users to set up a single key press to output a sequence of keys and/or mouse buttons. Macro Functions Macros have Behavior Assignments to give users more control as to how the input will be processed. - Page 12 RK-6000 User Manual Select All Select all events in the sequence list. Select All Delays Select all delays from sequence list. Delete : Delete an event in the sequence list. Delays time Allows users to add delays time in the Macro Ignored Delays Between Events System will not record the time difference between the actual time of “click”...
-
Page 13: Macro Limitation
RK-6000 User Manual Users can set up mouse button clicks through the sketch map display. Left click on the corresponding mouse button you wish to press. When pressed the mouse display will be highlighted to input a “press”. Left click on the highlighted mouse button again to unhighlight it to command a “release” of the key. -
Page 14: Pre-Programmed Funtions
RK-6000 User Manual Pre-Programmed Functions Internet HotKeys : Program a key to use a variety of Internet Browser operations. Office HotKeys: Program a key to use a variety of Microsoft Office basic commands. Media HotKeys : Program a key to use a variety of basic Media Player commands. -
Page 15: Additional Command
RK-6000 User Manual Additional command : Program a key to use a variety of additional Windows operating system commands. Profile Switch This allows users to switch to a designated Profile and Layer. Choose the Profile and Layer of choice using the Up or Down Arrows within the corresponding field. You can also choose to display the Profile and Layer on the screen when the Profile Switch command is activated by checking the On Screen Display(OSD) checkbox. -
Page 16: Reset Key To Default
RK-6000 User Manual Reset Key to Default: This will allow you to reset the key to default settings. Disable Button : This will allows you to disable a specific key from functioning entirely. Config Right clicking on the keyboard application icon within the System Tray (default lower right corner) will bring up a menu. - Page 17 RK-6000 User Manual Anti Key Combination...
