- Page 1 Installation Instructions AdEdge Residential Drinking Water System OPERATION MANUAL AdEdge Technologies, Inc. 5152 Belle Wood Court, Suite A Buford, GA 30518...
- Page 2 CONTENTS Description Description INSTALLATION INSTRUCTIONS ...... 2 INSTALLATION STEPS ........2 1. Faucet installation ........2 COMPONENTS ........... 2 2. Mounting the faucet ....... 4 Cartridges ............ 2 3. Feed water valve and tube installation 4 Filter housings ..........2 4.
- Page 3 Installation Instructions System location Residential Drinking Water Models Your drinking water system may be installed under DWS-2S-2710-01 a sink, in a basement or other location, depending Your Drinking Water System has been tested to on available space. Do not install unit where ensure it will operate correctly.
- Page 4 To make the faucet mounting hole (if sprayer or 5. Drill porcelain / enamel using spring loaded second hole is used), check below to make sure the porcelain cutter, making certain a complete ring drill does not interfere with anything below. has been cut through the porcelain / enamel to the metal base.
- Page 5 Procedures: Self-taping feed water saddle valve installation 1. Center punch small indent for hole. 2. Drill the required pilot hole. Installation procedures using soft copper tubing: 3. Set-up the chassis punch per instructions and tighten nut to cut the desired hole size. 1.
- Page 6 ☺ Tubing should follow contour of the cabinets. operation. (Please see page 2 for cartridge ☺ Cut tubing to desired length using square cuts information) and proper cutting devise. ☺ Make no sharp bends. Note: Change-out procedures may be amended, ☺...
- Page 7 Conventional fittings If John Guest fittings are not used, it is essential to install inserts at the ends of all tube connections when conventional fittings are used. Model DWS-2S-2710-01 This model includes a sediment cartridge, arsenic cartridge (AD2710S), two filter housings, faucet, feed water saddle valve, tubing, fittings and a water meter which will count gallons and automatically shut off the system once 1000 gallons has been filtered.
