Summary of Contents for MB QUART Nautic NKF116
- Page 1 NAUTIC NKF116 171.2mm / 6.74” 143mm / 5.63”...
- Page 2 NAUTIC NKF692 198mm / 7.8” 148mm / 5.83” 266mm / 10.47” 216mm / 8.5”...
- Page 3 NAUTIC NWF254 270.5mm / 10.65” 237mm / 9.33” RECOMMENDED ENCLOSURE (SEALED) T/S PARAMETERS Fs: 29.13 Hz Vd: 0.31705 liters Total Internal Volume: Qms: 3.7 Qes: 0.5 1 Cubic Foot Vas: 59 liters Re: 3.2 ohms 13.5 Tall .75” MDF Cms: 298.59 um/N NomZ: 4 ohms BL: 10.7 Tm Mms: 100 g...
