Casio 5063 Operation Manual

MA1101-EA
About This Manual
Button operations are indicated using the letters A through D shown in the
illustration.
Hand Functions
z z Hour Hand
x x Second Hand
c c Minute Hand
v v Day
This User's Guide uses numbers shown above to identify watch hands and
indicators.
E-2
3. Set the current time.
To set the time using a time calibration signal
See "To get ready for a receive operation" (page E-14).
To set the time manually
See "Confi guring Current Time and Date Settings Manually" (page E-24).
The watch is now ready for use.
For details about the watch's radio controlled timekeeping feature, see "Radio Controlled Atomic
Timekeeping" (page E-11).
E-4
E-28 Checking the Current Time in a Different Time Zone
E-28 To search for a city
E-29 To check whether a time zone time is AM or PM
E-29 To change the STD/DST setting of a particular city code
E-29 To check the STD/DST setting for a World Time mode city
E-30 Auto Correction of Hand Home Positions
E-31 To trigger auto correction of hand home positions
E-32 Adjusting Home Positions Manually
E-33 To adjust home positions manually
E-35 Troubleshooting
E-40 Specifi cations
E-6
Operation Guide 5063 (OC)
Congratulations upon your selection of this CASIO watch.
This watch does not have a city code that corresponds to the UTC offset of –3.5 hours. Because of
this, the radio-controlled atomic timekeeping function will not display the correct time for Newfoundland,
Canada.
Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss suffered by
you or any third party arising through the use of this product or its malfunction.
Things to check before using the watch
1. Hold down C at least two seconds to enter regular timekeeping, and then observe the
movement of the x Second Hand.
Is the x Second Hand moving smoothly at one-second intervals?
NO
Is the x Second Hand moving at two-second intervals
or is it stopped completely?
YES
Power is low. Charge the watch by placing it in a
location where it is exposed to light. For details, see
"Charging the Watch" (page E-7).
2. Check the Home City and the daylight saving time (DST) setting.
Use the procedure under "To confi gure Home City settings" (page E-21) to confi gure your Home City and
daylight saving time settings.
Important!
Proper time calibration signal reception and World Time settings depend on correct Home City, Home
Time, and Home Date settings. Make sure you confi gure these settings correctly.
Contents
E-2 About This Manual
E-3 Things to check before using the watch
E-7 Charging the Watch
E-10 To recover from the sleep state
E-11 Radio Controlled Atomic Timekeeping
E-14 To get ready for a receive operation
E-16 To perform manual receive
E-17 To check the result of the latest receive operation
E-18 Mode Reference Guide
E-18 To determine the watch's current mode
E-18 To return to the regular timekeeping mode from another mode
E-19 To select a mode
E-20 Timekeeping
E-21 Confi guring Home City Settings
E-21 To confi gure Home City settings
E-23 To check the current Home City STD/DST setting
E-24 Confi guring Current Time and Date Settings Manually
E-24 To change the current time setting manually
E-25 To change the current date setting manually
Charging the Watch
The face of the watch is a solar cell that generates power from light. The generated power charges a
built-in rechargeable battery, which powers watch operations. The watch charges whenever it is exposed
to light.
Charging Guide
Whenever you are not
wearing the watch, leave
it in a location where it is
exposed to light.
Best charging
performance is achieved
by exposing the watch to
light that is as strong as
possible.
Warning!
Leaving the watch in bright light for charging can cause it to become quite hot. Take care when
handling the watch to avoid burn injury. The watch can become particularly hot when exposed to
the following conditions for long periods.
On the dashboard of a car parked in direct sunlight
Too close to an incandescent lamp
Under direct sunlight
ENGLISH
E-1
YES
The watch is charged suffi ciently. For details
about charging, see "Charging the Watch"
(page E-7).
NEXT
Go to step 2.
E-3
E-5
When wearing the watch, make
sure that its face is not blocked
from light by the sleeve of your
clothing.
The watch may enter a sleep
state (page E-10) if its face is
blocked by your sleeve even
only partially.
E-7
