Instructions Yukon Mobile Player / Recorder
WARNING
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
Attention
The electromagnetic fields at the specific frequencies may influence the picture of the recorder.
Be sure to read the following before using the recorder Trial recording
Before you record one-time events, you may want to make a trial recording to make sure
that the recorder is working correctly. Notes on image data compatibility
Playback of moving images recorded with your recorder on other equipment and playback
of moving images recorded or edited with other equipment on your recorded are not guaranteed.
Do not shake or strike the recorder
In addition to malfunctions and inability to record moving images, this may render the SD
card unusable of image data breakdown, damage or loss may occur.
LCD screen
Be careful when placing the camera near a window or outdoors. Exposing the LCD screen to
direct sunlight for long period may cause malfunctions.
Back up recommendation
To avoid the potential risk of data loss always copy data to a disk.

Table of Contents

Identifying the parts of the
recorder.............................................
indicators................................................................. ......................... 5
supply...........................................................
card......................................................................
Basic Operations
Recording............................................................
Cycle Video........................................................
Recording with the digital NV Ranger
5x42.................................
set.........................................
Playback moving images.........................................
computer.........................
screen........................................
files....................................................................
language............................................................
........................ 4
......................... 6
........................ 7
........................8
.........................9
......................... 10
....................... 11
....................... 11
......................... 11
......................... 13
........................ 13
....................... 14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 27041 and is the answer not in the manual?

Questions and answers

Summary of Contents for Yukon 27041

  • Page 1: Table Of Contents

    Instructions Yukon Mobile Player / Recorder WARNING To prevent fire or shock hazard, do not expose the unit to rain or moisture. Attention The electromagnetic fields at the specific frequencies may influence the picture of the recorder. Be sure to read the following before using the recorder Trial recording Before you record one-time events, you may want to make a trial recording to make sure that the recorder is working correctly.
  • Page 2 8. [  ] REV / Select key 9. SD Card Slot 10. [ / M] Return / Menu key 11. LED Indicators 12. [] Power key Package contents • Yukon Mobile Player/Recorder • AV Cable • AV IN cable • USB cable...
  • Page 3: Getting Started

    • Rechargeable battery • AC Charger • SD card • User Manual For improvement purposes, design of this product is subject to change. Getting Started LCD screen indicators Playback Mode Recording Mode (1) Playback icon (2) Recorded Files (3) Recording symbol (4) Date/Time indicator (5) Battery indicator (6) Pixels Logo D1: 720x576 720x480 VGA: 640x480...
  • Page 4: Motion Detection Recording

    Insert SD card with the "" mark facing the SD slot as illustrated. Recording time of memory capacity SD card 720 X 576 720 X 480 640 X 480 capacit Approx. 45 mins Approx. 55 mins Approx. 65 mins Approx. 90 mins Approx.
  • Page 5: Recording Moving Images From Tv Set

    Recording with the digital night vision monoculars Ranger 5x42 and Ranger Pro 5x42 a. Connect the plug of the Ranger's AV cable to the Ranger's "AV out" port (see connection scheme below). b. Connect the yellow plug of the recorder's AV cable to the yellow jack of the Ranger's AV cable. c.
  • Page 6: Playback Moving Images

    Yellow: video Red: Left channel audio White: Right channel audio Playback moving images а. Slide [ R/P ] key toward the position of [P] b. Turn on the recorder. c. Select the desired moving image with the [ ] or [ ] key. ...
  • Page 7: Setting Operations Setting The Language

    DELETE b. Select " YES " to delete the current file or select " NO " to cancel the operation Setting Operations Setting the language a. In the state of preview, press the [/ M] button to enter "Setup" b. Press [ ] or [ ] to select "Language", and press [ /►||] to enter setup ...
  • Page 8: Setting The Cycle Recording

    setting Operations Setting the cycle recording a.In the state of preview, press the [/ M] button to enter "Setup" b.Press [ ] or [ ] to select "CYCLE", and press [ /►||] to enter setup    c.Select YES " or "NO" and press [ /►||] (as illustrated) ...
  • Page 9: Setting The Lcd Off

    b. Press [ ] or [ ] to select "DATE TIME", and press [ /►||] to enter setup    c. select "Date Format", and press [ /►||] to enter setup (as illustrated)  d. select Y/M/D" or "D/M/Y" and press [ /►||] (as illustrated) ...
  • Page 10: Setting The Power Off

     d. Select "YES " or "NO" and press [ /►||] (as illustrated)  Attention: Format will delete all the data and non-recoverable. Specifications Model# 27041 Digital Screen 2.0° TFT LCD Color System PAL/NTSC (Auto) LCD Resolution 960 X 240...
  • Page 11: Warranty

    Motion Activated 640 X 480 (30FPS) Cycle Recording Real-time Stamp Video Time LCD Off 10/30/60Mins Auto Power Off 1/5Mins/Never 1/5Mins/Never Storage Playback Video (YES) Audio (YES) Frame Rate 30fps/25fps Built-in Flash Memory 70MB USB jack High-speed USB2.0 DC Input DC 5V1A Power Supply 5V150mAh Battery pack capacity...
