Hitachi CP-X2510N Series Specification Sheet

CP-X2510N Series
My Image / Campus Notification System

Key Features

• 2,600 ANSI Lumens
• Native XGA Resolution
• 2000:1 Contrast ratio
• 8.8 lbs.
• 2 RGB Inputs / 1 RGB Output
• Component / Composite /
S-Video Inputs
• 16 Watt Audio Output
• Network Control, Maintenance,
& Security
• Network Bridge
(RS-232 Pass Through)
Screen Size 4:3
Diagonal* Width*
30 24
60 48
80 64
100 80
120 96
150 120
200 160
300 240
Throw Ratio: 1.5-1.8:1 (distance : width)
*Measured in inches
For sales information, please call 800.225.1741
Printed 05.09
Closed Captioning
• Approx. 6,000 Hours (Eco Mode)*
• Security Bar & Transition Detector
• 29 dBA (Eco Mode)
• Easily Accessible Hybrid Filter
(5,000 Hours between maintenance)
• PJ Setup
• Network Messenger
• Audio Pass Through
• Template Function
• Power Saving Mode
Specifications
Model Name
Liquid Crystal Panel Structure
Number of Pixels
Resolution
Colors
Aspect Ratio
Lens
Throw Ratio (distance : width)
Lamp
Brightness
Expected lamp Life
Contrast Ratio
Speaker Output
Power Supply
Power Consumption
Operating Temperature
Input Signals
Acoustic Noise Level
H-Sync
V-Sync
Vertical Keystone
Approvals
RGB Input
RGB Output
Video Input
Audio
Ethernet
Control Terminals
Other
Dimensions (W x D x H)
Weight
Closed Caption
Throw Distance
Additional Features
Min* Max*
34 41
Supplied Accessories
70 83
Lamp
94 112
Remote Control
Filter
118 140
142 168
177 211
237 281
356 422
AMX Device Discovery
CP-X2510N Series
0.63" Polysilicon Active-matrix TFT x 3
786,432 Pixels
Video 540 TV lines
RGB 1024 dots x 768 lines
16.7 million colors
Native 4:3 / 16:9 compatible
manual zoom x 1.2
1.5 - 1.8 : 1
210W UHP
2,600 ANSI lumens
Approximately 3,000 hours (normal) 6,000 hours (Eco mode)*
2000 : 1
16W (2 Speakers)
AC100 - 120V / AC220 - 240V 50/60 Hz Power
330W
5˚C - 35˚C (41˚F - 95˚F)
RGB VGA, SVGA, XGA, SXGA, SXGA+, UXGA, MAC13", MAC16"
Composite Video NTSC, NTSC4.43, PAL, SECAM, PAL-M, PAL-N
Component Video
480i, 576i, 480p, 720p, 1080i, 1080p
35 dBA (29 dBA in Eco mode)
15 kHz - 106 kHz
50 kHz - 120 kHz
+ / - 30˚
UL, C-UL, FCC, CE, RoHS
Analog RGB 15-pin D-sub connector x 2
RGB
15-pin D-sub connector x 1
S-Video Mini DIN 4-pin connector x 1
Composite Video RCA jack x 1
Component Video
RCA jack x 3
Input Stereo mini jack x 2, RCA (L/R) x 1 pair
Output RCA (L/R) x 1 pair
RJ-45 port / 100 base-T
9-pin D-sub connector x 1 (RS-232 control)
USB connector (USB mouse) x 1
12.5" x 11.3" x 4.6"
8.8 lbs.
CC1, CC2, CC3, CC4, T1, T2, T3, T4
Kensington Slot, Digital Gamma Correction, Whiteboard /
Blackboard Mode, Input Source Naming, MyMemory / My-
Screen / MyButtons / MyText, Auto V Keystone,
Serial Number on Side
Remote Control, Batteries (AA), RGB cable, US Power Cord,
Multiple language operator / Safety Manual
CPX2010LAMP (DT01021)
HL02483
MU06481
All specifications subject to change without notice
