PROJECTION COLOR TV
OPERATING GUIDE

TABLE OF CONTENTS

IMPORTANT SAFEGUARDS ...................................................................................................................................................2
Safety Tips .............................................................................................................................................................................4
Picture Cautions................................................................................................................................................................9
Accessories...........................................................................................................................................................................9
Remote Control Battery Installation And Replacement.......................................................................11
How To Set Up Your New Hitachi Projection Tv...............................................................................................11
Hook-Up Cables And Connectors ............................................................................................................................13
Front Panel Controls...................................................................................................................................................15
Front Panel Jacks And Connections.....................................................................................................................16
Rear Panel Jacks..............................................................................................................................................................18
Rear Speaker Terminal Connections....................................................................................................................22
Tips On Rear Panel Connections ..............................................................................................................................22
External Audio Sources..............................................................................................................................................23
Connecting External Video Sources ...................................................................................................................25
Audio System Set-Up .......................................................................................................................................................29
Picture-In-Picture (Pip) ..................................................................................................................................................36
Using The Remote To Control Vcr Functions...................................................................................................42
Using The Remote To Control Cable Box Functions.....................................................................................44
Using The Remote To Control Satellite Receiver Functions..................................................................45
Using The Remote To Control Dvd Functions ..................................................................................................47
Using The Remote To Control Additional Audio/Video Equipment ......................................................48
Cable/Satellite, Vcr, Audio And Dvd Codes (Clu-573Tsi And Clu-574Tsi) ................................................50
Vcr Brands .....................................................................................................................................................................50
Dvd Brand ........................................................................................................................................................................53
Cable Brand ...................................................................................................................................................................53
SATELLITE BRAND
Amplifier Brand ...........................................................................................................................................................54
Cd Brand...........................................................................................................................................................................55
Tape Brand ......................................................................................................................................................................55
Ultratec Osd......................................................................................................................................................................56
Set Up ......................................................................................................................................................................................59
Custom...................................................................................................................................................................................67
Auto Link ..........................................................................................................................................................................76
Video .......................................................................................................................................................................................80
Theater .................................................................................................................................................................................85
Info ..........................................................................................................................................................................................94
Care Of Your Hitachi Projection Tv And Your ................................................................................................97
Remote Control ...............................................................................................................................................................97
Reception Problems........................................................................................................................................................98
Useful Info ..........................................................................................................................................................................99
61SBX01B
CODES ......................................................................................................................................54
53SBX01B
1

Advertisement

Table of Contents
loading

Related Manuals for Hitachi 61SBX01B

Summary of Contents for Hitachi 61SBX01B

  • Page 1 IMPORTANT SAFEGUARDS ...2 SAFETY TIPS ...4 PICTURE CAUTIONS...9 ACCESSORIES...9 REMOTE CONTROL BATTERY INSTALLATION AND REPLACEMENT...11 HOW TO SET UP YOUR NEW HITACHI PROJECTION TV...11 HOOK-UP CABLES AND CONNECTORS ...13 FRONT PANEL CONTROLS...15 FRONT PANEL JACKS AND CONNECTIONS...16 REAR PANEL JACKS...18 REAR SPEAKER TERMINAL CONNECTIONS...22...

  • Page 2: Important Safeguards

    SLOT, FULLY INSERT. MODIFICATIONS: The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Hitachi America, Ltd. Home Electronics Division may void the user's warranty. POWER SOURCE: This projection television is designed to operate on 120 volts 60Hz, AC current.
  • Page 3 IMPORTANT SAFEGUARDS TO PREVENT ELECTRIC SHOCK, DO NOT USE THE TELEVISION'S (POLARIZED) PLUG WITH AN EXTENSION CORD, RECEPTACLE, OR OTHER OUTLET UNLESS THE BLADES AND GROUND TERMINAL CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. NEVER CONNECT THE TV TO 50Hz, DIRECT CURRENT, OR ANYTHING OTHER THAN THE SPECIFIED VOLTAGE.

  • Page 4: Safety Tips

    Safety is also foremost in our minds in the design of these units. To help you operate these products properly, this section illustrates safety tips which will be of benefit to you. Please read it carefully and apply the knowledge you obtain from it to the proper operation of your HITACHI television.
  • Page 5 SAFETY TIPS you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. 6 Never push objects of any kind into this television set through the television cabinet's slots as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock.
  • Page 6 SAFETY TIPS • Never expose the television to rain or water. If the set has been exposed to rain or water, unplug television from wall outlet and refer to qualified service personnel. 13 Choose a place where light (artificial or sunlight) does not shine directly on the screen. 14 Avoid dusty places.
  • Page 7 SAFETY TIPS provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. 17 An outside antenna system should not be located in the vicinity of overhead power lines or other electrical lights or power circuits, or where it can fall into such power lines or circuits.
  • Page 8 SAFETY TIPS 24 It is normal for some televisions to make occasional snapping or popping sounds, particularly when being turned on or off. If the snapping or popping is continuous or frequent, unplug the set and consult your dealer or service technician. FOR SERVICING AND MODIFICATION 25 Do not use attachments not recommended by the television manufacturer as they may cause hazards.

  • Page 9: Picture Cautions

    • Continuous on-screen displays such as video games, stock market quotations, computer generated graphics, and other fixed (non-moving) patterns can cause permanent damage to projection television receivers. Such "PATTERN BURNS" constitute misuse and are NOT COVERED by your HITACHI Factory Warranty.
  • Page 10 ACCESSORIES CLU-574TSI CLU-573TSI 1. Remote Control Unit CLU-573TSI ( Part No. HL01323) or CLU 574TSI (Part No. HL01324). 2. Two "AA" size, 1.5V batteries (For Remote Control Unit).

  • Page 11: Remote Control Battery Installation And Replacement

    VIEWING The major benefit of the HITACHI Projection Television is its large viewing screen. To see this large screen at its best, test various locations in the room to find the optimum spot for viewing.

  • Page 12: How To Set Up Your New Hitachi Projection Tv

    HOW TO SET UP YOUR NEW HITACHI PROJECTION TV During daylight hours, reflections from outside light may appear on the screen. If so, drapes or screens can be used to reduce the reflection or the TV can be located in a different section of the room.

  • Page 13: Hook-Up Cables And Connectors

    HOOK-UP CABLES AND CONNECTORS HOOK-UP CABLES AND CONNECTORS Most video/audio connections between components can be made with shielded video and audio cables that have phono connectors. For best performance, video cables should use 75- Ohm coaxial shielded wire. Cables can be purchased from most stores that sell audio/video products.
  • Page 14 HOOK-UP CABLES AND CONNECTORS When both VHF and UHF antennas are connected Attach an optional antenna cable mixer to the TV antenna terminal, and connect the cables to the antenna mixer. Consult your dealer or service store for the antenna mixer.

  • Page 15: Front Panel Controls

    FRONT PANEL CONTROLS FRONT PANEL CONTROLS FRONT VIEW MENU Button This button allows you to enter the MENU, making it possible to set TV features to your preference without using the remote. INPUT/EXIT button Press this button to select the current antenna source, VIDEO: 1, 2, 3, or alternate antenna source.

  • Page 16: Front Panel Jacks And Connections

    FRONT PANEL JACKS AND CONNECTIONS NOTES: Your HITACHI Projection TV will appear to be turned OFF if there is no video input when VIDEO: 1, 2 or 3 is selected. Check the Power Light to make sure the TV is turned off when not in use.
  • Page 17 FRONT PANEL JACKS AND CONNECTIONS NOTE: Completely insert connection cord plugs when connecting to front panel jacks. If you do not, the played back picture may be abnormal. If you have a S-VHS VCR, use the S-INPUT cable in place of the standard video cable. If you have a mono VCR, insert the audio cable into the left channel jack of your TV.

  • Page 18: Rear Panel Jacks

    REAR PANEL JACKS REAR PANEL JACKS Antenna Input/Output The remote control allows you to switch between two separate 75-Ohm RF antenna inputs, ANT A and ANT B. ANT A input can be displayed as a main picture or sub-picture. ANT B can only be displayed as a main picture.
  • Page 19 REAR PANEL JACKS used for another stereo system amplifier. With this connection, the audio can be controlled by the television's main volume and also by an independent volume feature found in the THEATER-WIRELESS SOUND menu. (5) AUDIO TO HI-FI These jacks provide variable audio output to a separate stereo amplifier. With this connection, the audio to the stereo can be controlled by the television's main volume.
  • Page 20 REAR PANEL JACKS NOTES: DO NOT connect standard VIDEO or S-VIDEO to INPUT 2 when using Y-CB-CR input. When using the Y-CB-CR input jacks, connect your components audio output to the TV's INPUT 2 Left and Right Audio input jacks. Your component outputs may be labeled Y, B-Y, and R-Y.
  • Page 21 REAR PANEL JACKS Typical full feature setup. Follow connections that pertain to your personal entertainment system.

  • Page 22: Rear Speaker Terminal Connections

    REAR SPEAKER TERMINAL CONNECTIONS REAR SPEAKER TERMINAL CONNECTIONS CONNECT AFTER TURNING THE POWER TO THE TV OFF. Press the Right Speaker red button and insert the positive (+) lead wire into the hole next to the button. Once the wire is in place, pull the red button back to original position and the wire is locked into place.

  • Page 23: External Audio Sources

    EXTERNAL AUDIO SOURCES Refer to the operating guide of your other electronic equipment for additional information on connecting your hook-up cables. A single VCR can be used for VCR #1 and VCR #2, but note that a VCR cannot record its own video or line output.
  • Page 24 EXTERNAL AUDIO SOURCES NOTES: To prevent damage to the speaker and distorted sound, set the volume control of the audio amplifier lower and adjust the sound using the remote control fo the TV set. Do not connect speakers simultaneously to the REAR SPEAKER terminal of the Projection TV and an external amplifier.

  • Page 25: Connecting External Video Sources

    CONNECTING EXTERNAL VIDEO SOURCES CONNECTING EXTERNAL VIDEO SOURCES The exact arrangement you use to connect the VCR, camcorder, laserdisc player, DVD player or HDTV Set Top Box to your TV set is dependent on the model and features of each component.
  • Page 26 CONNECTING EXTERNAL VIDEO SOURCES...
  • Page 27 CONNECTING EXTERNAL VIDEO SOURCES CONNECTING A STEREO VCR OR STEREO LASERDISC PLAYER 1. Connect the cable from the AUDIO OUT of the VCR or the laserdisc player to the INPUT (VIDEO) jack on the TV set below. 2. Connect the cable from the AUDIO OUT R of the VCR or the laserdisc player to the INPUT (AUDIO/R) jack.
  • Page 28 CONNECTING EXTERNAL VIDEO SOURCES 3. Connect the cable from the CR or R-Y OUT or B-Y of the Laserdisc or the DVD player to the INPUT 2 (CR) jack, as shown on the TV set below. 4. Connect the cable from the AUDIO OUT R of the Laserdisc or DVD player to the INPUT 2 (AUDIO/R) jack.

  • Page 29: Audio System Set-Up

    AUDIO SYSTEM SET-UP AUDIO SYSTEM SET-UP Match the numbers below to the diagrams for speaker placement and refer to the table on page 21 for the different surround sound requirements. (See page 59 for SURROUND functions.) The television's internal speakers. The television's internal center channel speakers, which are on only when the television is in SURROUND-PRO LOGIC, or SURROUND-DOLBY 3 STEREO mode.
  • Page 30 AUDIO SYSTEM SET-UP MATRIX (1) (4) DOLBY (1) (2) (4) PRO LOGIC DOLBY (2) (3) (4) PRO LOGIC* (TV AS CENTER) DOLBY 3 (1) (2) STEREO (NORMAL) DOLBY 3 (2) (3) STEREO (TV AS CENTER) Left and right speakers are connected ( (3) ), and the internal speakers ( (1) ) can be disabled, creating better separation between left, center and right channels.
  • Page 31 AUDIO SYSTEM SET-UP THE GENIUS REMOTE CONTROL (CLU-573TSI and CLU-574TSI) In addition to controlling all the functions on your HITACHI Projection TV, the new remote is designed to operate different types of VCRs, CATV (Cable TV) converters, satellite receivers, DVD players, and other audio/video equipment with one touch. Basic operation keys are grouped together in one area.
  • Page 32 AUDIO SYSTEM SET-UP Click here for CLU-573TSI. Click here for CLU-574TSI. (1) POWER Button Press this button to turn the TV set on or off when the remote is in TV mode. (See page 22 for instructions on how to set the remote control to TV mode.) If a SPECIAL EVENT REMINDER is set, it will be displayed when the TV is first turned on.
  • Page 33 AUDIO SYSTEM SET-UP (2) TV button When the TV button is pressed, it will blink, to indicate the remote is in TV mode. (3) VCR button When the VCR button is pressed, it will blink to indicate the remote is in VCR mode. (See page (4) CABLE button When the CABLE button is pressed, it will blink to indicate the remote is in CABLE mode.
  • Page 34 AUDIO SYSTEM SET-UP pressed while the timer is set, it will reset to the original condition. (11) LAST CHANNEL (LAST CH) button Use this button to select between the last two channels viewed. (Good for watching two sporting events, etc.) (12) INPUT button The INPUT button will select between antenna signal and the three sets of video input jacks each time the button is pressed.
  • Page 35 AUDIO SYSTEM SET-UP (14) COMMERCIAL SKIP (S.C.) button Press the this button repeatedly to select channel skip time (30-180 seconds) when no menu is displayed and the TV will tune to the last channel viewed when the selected amount of time is up.

  • Page 36: Picture-In-Picture (Pip)

    (20) These buttons are not used on Remote Control CLU-574TSI. PICTURE-IN-PICTURE (PIP) Your HITACHI Projection TV incorporates Dual Tuner technology designed for improved viewing enjoyment. This Dual Tuner feature allows you to view antenna inputs on both the main picture and sub-picture simultaneously, with separate tuning control for each. The Dual Tuner can operate with only one input (ANT A only) or two inputs (ANT A and ANT B).
  • Page 37 PICTURE-IN-PICTURE (PIP) (1) PIP button Press the PIP button and a sub-picture will appear in one of the three different modes (SINGLE, SPLIT or SURF), depending on the last selection of the PIP mode. To change the PIP mode use the THUMB STICK and the new selection will appear the next time the PIP function is used.
  • Page 38 PICTURE-IN-PICTURE (PIP) NOTES: 1. Since ANT B source cannot be viewed as a sub-picture, only SPLIT mode PIP is possible when ANT B is selected as the main channel. 2. When ANT B is selected as a main channel, the SWAP feature is disabled. 3.
  • Page 39 PICTURE-IN-PICTURE (PIP) NOTES: 1. The SWAP button will only operate when SINGLE PIP mode or SPLIT PIP mode is chosen. 2. The SWAP function will not operate if ANT B input is set as the main channel (ANT B input cannot be displayed as a sub-picture.
  • Page 40 PICTURE-IN-PICTURE (PIP) SINGLE FREEZE Press the FREEZE button to freeze the picture you are currently viewing. Press this button again or PIP to return to normal viewing. SPLIT FREEZE Press the FREEZE button to freeze the picture you are currently viewing. (Only the left sub- picture will freeze).
  • Page 41 PICTURE-IN-PICTURE (PIP) THEATER-WIRELESS SOUND mode and use the WIRELESS OUT outputs on the rear panel. (see page 62) Each freeze frame is delayed about 0.1 (1/10) second. The FREEZE function will display blank sub-pictures when the COMPONENT VIDEO: Y-CB- CR INPUT 2 source is set as main channel.

  • Page 42: Using The Remote To Control Vcr Functions

    USING THE REMOTE TO CONTROL VCR FUNCTIONS USING THE REMOTE TO CONTROL VCR FUNCTIONS Operating the precoded function for your VCR. This remote is designed to operate different types of VCRs. You must first program the remote to match the remote system of your VCR. (refer to page 34 for pre-codes) 1.
  • Page 43 USING THE REMOTE TO CONTROL VCR FUNCTIONS NOTE: Refer to instruction manual of the VCR for operation of the buttons exclusively for the VCR.

  • Page 44: Using The Remote To Control Cable Box Functions

    USING THE REMOTE TO CONTROL CABLE BOX FUNCTIONS USING THE REMOTE TO CONTROL CABLE BOX FUNCTIONS Operating the precoded function for your cable box. This remote is designed to operate different types of cable boxes. You must first program the remote to match the remote system of your cable box.

  • Page 45: Using The Remote To Control Satellite Receiver Functions

    USING THE REMOTE TO CONTROL SATELLITE RECEIVER FUNCTIONS NOTES: 1. If your cable box cannot be operated after performing the above procedures, your cable box code has not been precoded into the remote. 2. In the unlikely event that your cable box cannot be operated after performing the above procedures, please consult your cable box operating guide.
  • Page 46 USING THE REMOTE TO CONTROL SATELLITE RECEIVER FUNCTIONS the remote control is programmed for your Satellite receiver. If the Satellite receiver does not turn off, try a different two digit preset code. 6. The remote will now control your Satellite receiver. NOTES: 1.

  • Page 47: Using The Remote To Control Dvd Functions

    USING THE REMOTE TO CONTROL DVD FUNCTIONS USING THE REMOTE TO CONTROL DVD FUNCTIONS Operating the precoded function for your DVD player. This remote is designed to operate different types of DVD players. You must first program the remote to match the remote system of your DVD player. (refer to page 34 for precodes) 1.

  • Page 48: Using The Remote To Control Additional Audio/Video Equipment

    USING THE REMOTE TO CONTROL ADDITIONAL AUDIO/VIDEO EQUIPMENT NOTES: 1. If your DVD player cannot be operated after performing the above procedures, your DVD player code has not been precoded into the remote. 2. In the unlikely event that your DVD player cannot be operated after performing the above procedures, please consult your DVD player operating guide.
  • Page 49 USING THE REMOTE TO CONTROL ADDITIONAL AUDIO/VIDEO EQUIPMENT 5. Aim the remote at the Audio/Video component and press the POWER button. The remote will turn off your AUDIO/VIDEO EQUIPMENT when the correct two digit preset code is entered. When this occurs, the remote control is programmed for your AUDIO/VIDEO EQUIPMENT.

  • Page 50: Cable/Satellite, Vcr, Audio And Dvd Codes (Clu-573Tsi And Clu-574Tsi)

    Cybernex Daytron Electrohome Emerex 04,23,40,46 Goldstar 24,25,43 Harley Davidson Harwood Hi-Q AV1___________________ AV2___________________ AV3___________________ Aiko Akai Asha Beaumark Brandt Calix Capehart Colt Curtis Mathes Daewoo Dynatech Electrophonic Emerson Gerrard Gradiente Harmon/Kardon Headquarter Hitachi 02,47,48 09,30 02,23,46 07,09,17,37 01,09,13,16,24,27,28, 33,36,41,47,49,50 02,03,04,05...
  • Page 51 CABLE/SATELLITE, VCR, AUDIO AND DVD CODES (CLU-573TSI and CLU- 574TSI) Jensen 09,24 Lloyd Logik Magnavox 15,23,29,31,35 02,14,26 Kenwood 02,25,26 Kodak 23,24 Lloyd’s Magnin...
  • Page 52 CABLE/SATELLITE, VCR, AUDIO AND DVD CODES (CLU-573TSI and CLU- 574TSI) Marantz 23,31 Matsushita Memorex 01,15,18,19,20,23,24, 32,44 MGN Technology Mitsubishi 16,26,39,47,48 01,44 02,06,25,26,32 Noblex Optimus 20,24,32 Panasonic 11,12,23,38,51 Pentax 03,04,05 Phillips 23,29,31 Pioneer Protec Quarter Quasar Radix 03,04,05,35,40,46 Ricoh Samsung 17,44 Sansui 02,26 Scott...

  • Page 53: Dvd Brand

    Sony Yamaha CABLE BRAND 01,07,08,17,18,20,36, 37,49 Archer 11,24,39 Cable Star Citizen Comtronics 25,28 Dae Ryung Electricord Focus Gemini 05,38,43,51 Goldstar 10,25 Hitachi Jasco Macom Memorex 29,33,38 Panasonic 02,03,09 Pioneer 06,10,19 Pulsar Realistic Regal 04,22,34 Rembrandt 01,38 Samsung 10,25 Signal 25,51...

  • Page 54: Amplifier Brand

    Texscan Toshiba TV 86 United Artists Universal 11,24,31,32,34,39 Viewstar 15,28,29,40 Zentek SATELLITE BRAND Echostar Hughes Sony AMPLIFIER BRAND Aiwa 05,06 Casio Denon Hitachi Kenwood 14,15,17,18 Magnavox 01,06,09 Onkyo Panasonic 01,06 Pioneer Realistic Sanyo Sony 02,16,23,24,25 Victor 03,04,05,07,20,21 Yamaha Stargate Starsight...

  • Page 55: Cd Brand

    07,17 01,21 Rotel Sansui Sony 05,18 Victor TAPE BRAND Aiwa 11,12 Jerrold 13,14 Kenwood Panasonic Scientific Atlanta Starcom Aiwa Carver Fisher Hitachi 01,07,08,09,10,11,12 Kenwood 06,14,15 Magnavox Optimus 05,07,17 Philips Proton Quasar Realistic Scott Technics 03,19,20 Hitachi 01,02,03,04 Optimus Pioneer Sony...

  • Page 56: Ultratec Osd

    ULTRATEC OSD ULTRATEC OSD 1. Press MENU on the remote control to display the different features on your HITACHI Projection TV. 2. Press the THUMB STICK to highlight a different feature. 3. Press EXIT on the remote control to quickly exit from a menu.
  • Page 57 ULTRATEC OSD MENU LANGUAGE PLUG & PLAY SIGNAL SOURCE Select Antenna or Cable TV. AUTO CHANNEL SET CHANNEL MEMORY CHANNEL LIST Check channel name, scan, and child lock. CLOCK SET Set before using timer features. MAGIC FOCUS white. CHANNEL ID VIDEO ID Label video inputs VCR1, DVD1, etc.
  • Page 58 ULTRATEC OSD RESET ADVANCE SETTINGS THEATER MODES Picture and sound are automatically set. SURROUND GRAPHIC EQ. WIRELESS SOUND SUP WOOFER SPECIAL EVENT REMINDER CALENDAR Check day, month, year, and special events. Set AUDIO settings to factory preset. Improve sound performance. Special sound effects, including Dolby Pro Logic.

  • Page 59: Set Up

    SET UP SET UP Select INITIAL SETUP when setting your TV up for the first time. Use the THUMB STICK on the remote to highlight the function desired. NOTE: To see an auto-demonstration of the on-screen displays with HELP text displayed, press and hold the POWER button on the TV set for approximately five seconds.
  • Page 60 SET UP PLUG & PLAY This graphic guide function will help you to properly set up your TV or Home Theater System. Simply answer three questions and a graphic will be displayed, showing you the optimum setup for your personalized system. Press THUMB STICK to highlight the correct answers to all three questions.
  • Page 61 SET UP SIGNAL SOURCE Select ANTENNA if you are using an indoor or outdoor antenna. Select CATV if you have cable TV. Press THUMB STICK Press EXIT to quit MENU or THUMB STICK RECEPTION BAND to highlight and select the correct SIGNAL SOURCE mode. to return to previous menu.
  • Page 62 SET UP AUTO CHANNEL SET This feature will automatically store active TV channels in CHANNEL MEMORY. This will allow you to skip unused channels when using the CHANNEL UP ( ) or DOWN ( If the EXIT button is pressed while the AUTO CHANNEL SET function is engaged, programming will stop.
  • Page 63 SET UP Add or erase additional channels while still in CHANNEL MEMORY using CHANNEL or the number buttons to change the channel. Press EXIT to quit menu or THUMB STICK to return to previous menu.
  • Page 64 SET UP CHANNEL LIST This function allows you to review which channels are labeled in CHANNEL ID (ID)., which have been added to CHANNEL MEMORY (SCAN), and which are protected by PARENTAL CONTROL (LOCK). Press THUMB STICK to review more channels. Press EXIT to quit menu or THUMB STICK to return to previous menu.
  • Page 65 SET UP Use THUMB STICK to set the time, date, and year. Press THUMB STICK to change position. Press EXIT to quit menu or THUMB STICK to return to previous menu when the CURSOR is in the first position.
  • Page 66 SET UP MAGIC FOCUS Your HITACHI Projection TV has three color projection tubes: one for red, one for green, one for blue. When mixed together in the proper proportion, the output of these three colors tubes can produce any color. To produce these colors, however, the beams must be precisely aligned over each other so that the colors can be mixed.

  • Page 67: Custom

    CUSTOM CUSTOM This selection contains advanced features which will make TV viewing easier and more enjoyable. CHANNEL ID Use this feature to give up to 20 channels a name when ANTENNA signal source is selected and up to 60 channels a name when CATV1 signal source is selected. Press THUMB STICK to select CHANNEL LIST.
  • Page 68 CUSTOM If ANT A and ANT B are in the same SIGNAL SOURCE mode (see page 39), the CHANNEL ID for both antenna inputs will be the same. CHANNEL ID will be displayed only when channel is displayed as main picture.
  • Page 69 CUSTOM VIDEO ID. Use this feature to give a name to any of the two video inputs. Press THUMB STICK to select VIDEO LIST. Press THUMB STICK to select preset VIDEO LIST. Press THUMB STICK Press THUMB STICK to select desired VIDEO ID. To customize VIDEO ID, select CUSTOM.
  • Page 70 CUSTOM you can rename. A total of 42 channels can be stored in the FAMILY FAVORITES function. Channel stored with AUTO CHANNEL SET will automatically be stored in FAMILY FAVORITES. To rename the categories, use the THUMB STICK buttons to highlight the category you would like to rename.
  • Page 71 CUSTOM FAMILY FAVORITES (OPERATION) Use this function to display FAMILY FAVORITES selections as sub-pictures or to tune the main picture to a desired favorite channel. Select a category using THUMB STICK Press MENU and the category will be displayed as sub-pictures at the right edge of the screen. This is useful for previewing a category.
  • Page 72 CUSTOM PARENTAL CONTROL This function will block out the picture and sound of the selected channel or video input. It can be used to keep the TV from being viewed for a scheduled amount of time that you set. The code to enter PARENTAL CONTROL is a four digit secret code number. The factory preset code is 0000.
  • Page 73 CUSTOM To change the secret code number, select CHANGE SECRET CODE. Enter a new four digit dey number you prefer. If you forget your secret code, use the factory code 7777 to erase your key number. This will reset the key number back to the factory preset 0000. Press EXIT to quit menu or THUMB STICK to return to the previous menu.
  • Page 74 CUSTOM EVENT PROG. This function will automatically turn the TV on and off, one time only, every day or once a week. Press THUMB STICK to select PROGRAM 1, 2, 3, or 4. Press THUMB STICK Use THUMB STICK to change position. Press THUMB STICK mode ONCE (TV will turn on/off one time only) or mode DAILY (TV will turn on/off at the same time every day), WEEKLY (TV will turn on/off at same time every week) OFF (to disable this...
  • Page 75 CUSTOM NOTE: 1. The OFF Timer will only activate if the TV was turned on or tuned with the ON Timer, and no channel selection was made after this time. If you change the channel after the ON Timer has been activated, the OFF Timer will deactivate. 2.

  • Page 76: Auto Link

    CUSTOM AUTO LINK Use this function to automatically turn the TV on and tune to VIDEO: 1, 2 or 3 when it detects a VIDEO input. Use THUMB STICK to to select Video input. Use THUMB STICK , then press down on THUMB STICK to change AUTO LINK setting.
  • Page 77 CUSTOM DISPLAY: ON/OFF will turn the MODE: C.C. (Closed Caption) is for the program you are viewing. TEXT is for additional information such as news reports or a TV program guide. This information covers the entire screen and viewing the TV program is not possible. TEXT may not be available with every CHANNEL: 1 is used for the primary language (usually English).
  • Page 78 CUSTOM MENU BACKGROUND This function allows you to choose from three menu backgrounds. Use THUMB STICK Press EXIT to quit menu or THUMB STICK Select CLEAR and no background is visible, select GRAY and a gray background is visible (no picture can be seen behind menu screen), select SHADED and a light background is visible.
  • Page 79 CUSTOM NOTE: 1. When TV set is turned on, the FIRST TIME TOUR will always appear if it is set to 2. To exit during the FIRST TIME TOUR, press the MENU button.

  • Page 80: Video

    VIDEO VIDEO Select VIDEO to adjust picture settings and improve picture quality. Use the THUMB STICK Press the THUMB STICK Press EXIT to quit menu. NOTE: 1. If CONTRAST is selected, you are adjusting CONTRAST. The additional menu items BRIGHTNESS, COLOR, TINT, and SHARPNESS can be selected and adjusted in the same manner.
  • Page 81 VIDEO Use this function to adjust the amount of fine detail in the picture. RESET When RESET is selected, press down on THUMB STICK to return video adjustments to factory preset conditions.
  • Page 82 VIDEO ADVANCED SETTINGS Your HITACHI Projection TV has an Ultra AI (Artificial Intelligence) function which will automatically adjust picture settings to produce the highest quality picture possible. When AI is highlighted, press down on THUMB STICK to turn the AI on or off.
  • Page 83 VIDEO SUPER CONTRAST Turn on SUPER CONTRAST to improve picture detail in areas of high brightness. COLOR TEMPERATURE Set this to WARM for hotter colors with more red, or set to COOL for less intense colors with more blue. Select AUDIO to adjust the TV to your preference and to improve the sound quality. Use THUMB STICK Press THUMB STICK Press EXIT to quit menu.
  • Page 84 VIDEO listening conditions. Press THUMB STICK to highlight the function. Press THUMB STICK to change the function setting. When the function has an "X" in the box, it is ON. MTS MODE Multi-Channel Television Sound will allow you to select STEREO (a stereo broadcast), MONO (monaural sound) used when receiving a weak stereo broadcast or SAP (second audio program) which may be a secondary language, weather report, etc.

  • Page 85: Theater

    THEATER PERFECT VOLUME This function will automatically adjust volume so each channel has the same average volume level. (This function will automatically be disabled when SURROUND-DOLBY PRO LOGIC or SURROUND DOLBY 3 STEREO are selected, to ensure correct DOLBY SURROUND sound decoding.) (see page 60) DYNAMIC BASS This function allows you to enjoy spectacular bass sound that would normally be heard only...
  • Page 86 THEATER Use THUMB STICK to change THEATER MODES settings. When TV mode is chosen, the following are automatically set: CONTRAST almost maximum, SUPER CONTRAST-OFF, COLOR TEMP. - COOL, LOUDNESS-ON, PERFECT VOLUME- ON, DYNAMIC BASS-ON. When MOVIE mode is chosen, the following are automatically set: CONTRAST almost center, SUPER CONTRAST-OFF, COLOR TEMP.
  • Page 87 THEATER SURROUND The following surround settings will reproduce the "live" sound you would hear in concert halls, sports stadiums, movie theaters, etc. when you set up your speaker system as shown in the section on audio system setup on pages 20-21. The surround system is most effective with movie and other stereo material that is Dolby Surround encoded, and played on a stereo VCR.
  • Page 88 THEATER The maximum volume allowed for the CENTER and REAR will depend on how loud the MAIN volume is set. SURROUND OFF Use this for normal stereo/mono broadcasts. MATRIX SURROUND Listener is surrounded by many sound sources such as a sporting event. NOTE: Some TV systems do not transmit optimum audio channel separation which can reduce the effectiveness of the MATRIX SURROUND function.
  • Page 89 THEATER DOLBY PRO LOGIC Dolby Pro Logic provides four separate sound channels: front left, center, front right, and surround. For properly encoded programs marked the center sound channel contains the dialogue for the program viewed. The left and right channels produce sound effects that will match the action on the TV screen.
  • Page 90 THEATER TEST TONE A test sound is generated allowing the listener to balance volume from each channel. Adjust the volume levels until all channels are equal. DOLBY PRO LOGIC Press THUMB STICK TONE. Automatic scanning of applicable speakers for your chosen Surround mode will occur. Simply wait until the speaker you wish to adjust is highlighted (static noise will be heard from this speaker), then use THUMB STICK by adjusting Front L and Front R volume control.)
  • Page 91 THEATER CURSOR is in the first position. NOTE: When this function is used or adjusted, the AUDIO SETTINGS functions BASS and TREBLE will be disabled and LOUDNESS will be set to off.
  • Page 92 THEATER IRELESS SOUND This feature allows you to choose between two possible variable audio outputs for a separate set of wireless speakers or another stereo amplifier. The audio output may be either MAIN TV AUDIO or PIP AUDIO. Press THUMB STICK Press THUMB STICK to select the function.
  • Page 93 THEATER Press THUMB STICK to select volume adjustment bar. Press THUMB STICK to adjust SUB WOOFER volume. Press EXIT to quit menu or THUMB STICK to highlight VOLUME, then THUMB STICK return to previous menu. NOTE: The SUB WOOFER volume will increase or decrease when main volume is adjusted.

  • Page 94: Info

    INFO INFO This function allows your TV to assist you with your busy day-to-day schedule. SPECIAL EVENT REMINDER Use this function to set up to six special events into memory. These events can then be viewed in CALENDAR mode. Press THUMB STICK to select EVENT 1 to 6.
  • Page 95 INFO appear at the selected time. 2. Each special event message can be a maximum of 20 characters. 3. When the RECALL button is pressed. a special icon appears on the right bottom corner of the screen and indicates a SPECIAL EVENT REMINDER message. Press the RECALL button again to display the SPECIAL EVENT REMINDER message.
  • Page 96 INFO CALENDAR Use this function to check the day, month, and year. Dates programmed in SPECIAL EVENT REMINDER will appear blinking and special event message will be displayed. Press THUMB STICK to change the month. Press EXIT to quit menu or THUMB STICK to return to previous menu.

  • Page 97: Care Of Your Hitachi Projection Tv And Your

    CARE OF YOUR HITACHI PROJECTION TV AND YOUR CARE OF YOUR HITACHI PROJECTION TV AND YOUR REMOTE CONTROL Dust the screen and cabinet with a soft cloth. Clean the screen with a soft cloth moistened with warm water and dry with a soft cloth. A mild soap may be used if the screen is extremely dirty.

  • Page 98: Reception Problems

    RECEPTION PROBLEMS RECEPTION PROBLEMS • IGNITION NOISE: Black spots or horizontal streaks may appear, picture may flutter or drift. Usually caused by interference from automobile ignition systems, neon lamps, electrical drills and other electrical appliances. • GHOSTS: Ghosts are caused by the television signal following two paths. One is the direct path and the other is reflected from tall buildings, hills or some other objects.

  • Page 99: Useful Info

    No color Poor color HITACHI Projection Television incorporates advanced power surge protection technology designed to protect against component or circuit damage due to external or internal voltage power surges. IF YOUR TELEVISION SHOULD APPEAR TO HAVE A LOSS OF POWER, PLEASE FOLLOW THIS PROCEDURE: 1) Press the power switch (ON/OFF switch) once.
  • Page 100 USEFUL INFO Features: • Superfine Picture Quality 1000 Line Horizontal Resolution • Pure Green and Red Filter Lenses • Artificial Intelligence System • Remote (Controls many VCR brands, cable boxes, satellite boxes, and other audio equipment) • High Definition On-Screen Display (UltraTEC BIT-MAP) •...
  • Page 101 USEFUL INFO Inputs: • Power Input...AC 120V, 60Hz • Power Consumption (operating 53SBX01B 161W 61SBX01B 161W • Power Consumption (maximum) 53SBX01B...210W 61SBX01B...210W • Antenna input impedance...75 Ohm • Channel coverage...181 ch. VHF-Band...2 ~ 13 UHF-Band...14 ~ 69 CATV Mid Band...A-5 ~ A-1 ...
  • Page 102 USEFUL INFO • Weight (lbs)
  • Page 103 Hitachi America, LTD Home Electronics Division Hitachi has made every effort to assure you hours of trouble free operation from your unit. However, should you require service, a network of Hitachi Authorized Service Facilities has been established in all 50 states and Puerto Rico. Each facility will provide you with convenient and expedient assistance.
  • Page 104 NOTES NOTES (blank page for consumer notes)
  • Page 105 Back cover Back cover HITACHI...

This manual is also suitable for:

53sbx01b

Table of Contents
