N150 Wireless Router
Package Contents:
N150 Wireless Router
Router stand
Ethernet cable
Power adapter
Attach the stand to the router:
1. Place the stand on a level surface.
2. Slide the router onto the stand.
Step 1:
Installation Guide
Unplug the power to turn off your modem.
Internet
Step 3:
Plug in, then turn on your modem.
DSL
or cable
Power On/Off
Modem
Wait about 2 minutes until your
modem turns on.
If your modem has a battery backup,
first remove and reinsert the battery
before connecting your
modem to power.
Step 2:
Connect one end of the yellow Ethernet cable (
your modem and the other end to the Internet port.
(not included)
Step 5:
Power On/Off
Connect your computer
to the router (
Use an Ethernet cable (not included)
to establish a wired connection.
Or connect wirelessly by using the
N150 Wireless Router
preset wireless security settings
located on the bottom label.
Step 4:
Connect the power adapter
to the router and plug it into
an outlet. Wait for the Wireless
LED (
) to light.
If no LEDs light, make sure
the Power On/Off button is in
the on position (pushed in).
) to
Laptop or desktop
computer
).
Step 6:
Open a web browser.
Your browser automatically
connects to your router so
you can set it up. See the
instructions on the other side.
