Model No. NTL07707.1
Serial No.
Write the serial number in the space
above for reference.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or if parts are missing,
PLEASE DO NOT CONTACT
THE STORE; please contact
Customer Care.
IMPORTANT: You must note the
product model number and
serial number (see the drawing
above) before contacting us:
CALL TOLL-FREE:
1-888-825-2588
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.nordictrackservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
With Universal Dock for iPod
®
USER'S MANUAL
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for NordicTrack NTL07707.1
Summary of Contents for NordicTrack NTL07707.1
- Page 1 With Universal Dock for iPod ® Model No. NTL07707.1 USER'S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete cus- tomer satisfaction. If you have...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. .2 IMPORTANT PRECAUTIONS . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and in- structions in this manual and all warnings on your treadmill before using your treadmill. ICON as- sumes no responsibility for personal injury or property damage sustained by or through the use of this product. - Page 4 20. Never leave the treadmill unattended while it 24. Inspect and properly tighten all parts of the is running. Always remove the key, unplug treadmill regularly. the power cord, and switch the reset/off cir- DANGER: cuit breaker to the off position when the Always unplug the power treadmill is not in use.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the revolutionary NordicTrack ® ing this manual, please see the front cover of this man- C2155 treadmill with Universal Dock for iPod. The ual. To help us assist you, note the product model C2155 treadmill offers a selection of features designed number and serial number before contacting us. -
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. - Page 7 1. Make sure that the power cord is unplugged. With the help of a second person, carefully tip the treadmill onto its left side. Partially fold the Frame (56) so that the treadmill is more stable; Hole do not fully fold the Frame yet. Remove and discard the two indicated bolts (A) and the shipping bracket (B).
- Page 8 4. Set the Right Upright Spacer (79) on the Base (83). Be careful not to pinch the Upright Wire (38). With the help of a second person, insert two 3/8" x 5" Bolts (6) with two 3/8" Star Washers (9) into the Right Upright (78) and set the Right Upright into the Right Upright Spacer.
- Page 9 7. Set the console assembly face down on a soft surface to avoid scratching the console assem- bly. Hold the Right Handrail (95) near the con- sole assembly. Next, insert the console wire into Console the large hole in the Right Handrail and out of Wire the top as shown.
- Page 10 10. Identify the Storage Latch (53). Remove the tie from the end of the tube. Make sure that the sleeve has been slid over hole 1 and that the Latch Knob (54) is locked into the indicated hole. Pull on the sleeve to make sure that it is locked into place.
- Page 11 12. Press the Left Accessory Tray (99) and the Right Accessory Tray (106) into the Console Base (91). 13. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of clear plastic on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the tread- mill.
-
Page 12: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT tric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. Plug the power cord into a surge suppressor, Your treadmill features a walking belt coated with high- performance lubricant. - Page 13 CONSOLE DIAGRAM FEATURES OF THE CONSOLE front cover of this manual. iFIT cards are also available at select stores. The treadmill console offers an impressive array of features designed to help you get the most from your You can even listen to your favorite workout music or workouts.
- Page 14 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before turning on the power. If you do not See HOW TO TURN ON THE POWER to the left.
- Page 15 4. Change the incline of the treadmill as desired. • Your heart rate. Note: Your heart rate can be displayed only while you use the handgrip To change the pulse sensor. incline of the treadmill, press • The display can also show an animation of a the Incline in- road.
- Page 16 7. Turn on the fan if desired. 6. Measure your heart rate if desired. Before using the The fan features low, high, and auto speed set- handgrip pulse tings. Press the Fan button repeatedly to select a sensor, remove fan speed or to turn off the fan. When the auto the clear plastic mode is selected, the speed of the fan will auto- film from the...
- Page 17 HOW TO USE A PRESET WORKOUT At the end of the first one-minute 1. Insert the key into the console. segment of the workout, a series See HOW TO TURN ON THE POWER on page of tones will sound. If a differ- ent speed setting and/or incline setting is pro- 2.
- Page 18 HOW TO USE AN IFIT CARD During the workout, a personal trainer will guide you 1. Insert the key into the console. through the workout. You can select an audio setting for your personal trainer (see THE INFORMATION See HOW TO TURN ON THE POWER on page MODE on page 19).
-
Page 19: Adjusting Cushioning System
HOW TO USE THE STEREO SOUND SYSTEM You can select an audio setting if desired. When you use an iFIT card, a personal trainer will guide you This product has been designed specifically to work through your workouts. If you select the “On” setting, with iPod and has been certified by the developer to the personal trainer will give you detailed instructions. -
Page 20: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If you do not do this, you may damage the treadmill when you fold it. Remove the key and unplug the power cord. -
Page 21: How To Lower The Treadmill For Use
HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand. Pull the latch knob to the left and hold it. It may be neces- sary to push the frame forward as you pull the knob to the left. -
Page 22: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a. - Page 23 Remove the three #8 x 3/4" Screws (1) and care- fully pivot the Hood (61) off. Locate the Reed Switch (71) and the Magnet (50) on the left side of the Pulley (51). Turn the Pulley until the Magnet is aligned with the Reed Switch. Make sure that the gap between the Magnet and 1/8 in.
- Page 24 PROBLEM: The walking belt is off-center or slips when walked on SOLUTION: a. If the walking belt is off-center, first remove the key and UNPLUG THE POWER CORD. If the walking belt has shifted to the left, use the hex key to turn the left rear roller bolt clockwise 1/2 of a turn;...
-
Page 25: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy. -
Page 26: Part List
PART LIST—Model No. NTL07707.1 R0907B To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual. Key No. Qty. Description Key No. Qty. Description #8 x 3/4" Screw Front Roller/Pulley #8 x 1" Tek Screw 15 1/2"... - Page 27 Key No. Qty. Description Key No. Qty. Description Console Ground Wire Frame/Roller Ground Wire iFIT Universal iPod Connector 5/32" Hex Key Filter Wire – 6" Blue Wire, 2F Lift Motor Spacer – User’s Manual #8 x 2" Screw *These parts are not illustrated. Right Accessory Tray Specifications are subject to change without notice.
-
Page 28: Exploded Drawing
EXPLODED DRAWING A—Model No. NTL07707.1 R0907B... - Page 29 EXPLODED DRAWING B—Model No. NTL07707.1 R0907B...
- Page 30 EXPLODED DRAWING C—Model No. NTL07707.1 R0907B...
- Page 31 EXPLODED DRAWING D—Model No. NTL07707.1 R0907B...
-
Page 32: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
